Summary of Contents for Christie Sapphire 4K40-RGBH

  • Page 1 Installation and Setup Guide 020-103979-01 Christie Sapphire 4K40-RGBH...
  • Page 2 Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied warranties of fitness for a particular purpose.

  • Page 3: Table Of Contents

    Leveling the projector..........35 Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 4 Connecting 12G, 6G, 3G, or HD SDI video source......68 Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 5 Connecting Christie Link video source........
  • Page 6 Environmental........... . 86 Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 7: Introduction

    For complete Christie Sapphire 4K40-RGBH product documentation and technical support, go to www.christiedigital.com. Product documentation For installation, setup, and user information, see the product documentation available on the Christie website. Read all instructions before using or servicing this product. 1. Access the documentation from the Christie website: •...

  • Page 8: Important Safeguards

    Read all safety and warning guidelines before installing or operating the projector. This projector must be operated in an environment that meets the operating range specification. Use only the attachments and/or accessories recommended by Christie. Use of others may result in the risk of fire, shock, or personal injury.

  • Page 9: Installation Safety And Warning Guidelines

    • ELECTRICAL and BURN HAZARD! Use caution when accessing internal components. • Only Christie qualified technicians are authorized to use the tools provided in the toolbox. AC power precautions Read all safety and warning guidelines before connecting to AC power.

  • Page 10: Laser Safety Precautions

    Possible hazardous optical radiation emitted from this product. (Risk group 3) • Only Christie qualified technicians who are knowledgeable about the hazards associated with laser use, high-voltage, and high temperatures generated by the product are authorized to assemble, install, and service the Christie Laser Projection System.
  • Page 11 E—Represents the top view of the projector. • F—Represents the side view of the projector. The following table lists the hazard distance for the Christie projector lens with the zoom adjusted to its most hazardous position. Christie Sapphire 4K40-RGBH 2D at 110V (limited power mode) configuration:...
  • Page 12 3.89-5.43:1 zoom 163-122106-XX Hazard distance Throw ratio High brightness lenses Ultra high contrast lenses Christie Sapphire 4K40-RGBH 3D right eye or left eye at 110V (limited power mode) configuration : Projection lens Part number Hazard distance (m) Category Fixed high brightness Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev.
  • Page 13 See hazard distance graph below 2.71-3.89:1 zoom 163-121105-XX 3.89-5.43:1 zoom 163-122106-XX Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 14 Introduction Hazard distance Throw ratio High brightness lenses Ultra high contrast lenses Christie Sapphire 4K40-RGBH 2D YNF at 220 VAC (full power mode, highest brightness configuration): Projection lens Part number Hazard distance Category Notes Fixed high brightness 0.38:1 fixed 144-136101-XX —...
  • Page 15 163-120103-XX — 2.71-3.89:1 zoom 163-121105-XX — 3.89-5.43:1 zoom 163-122106-XX — Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 16 Introduction Hazard distance Throw ratio High brightness lenses Ultra high contrast lenses Christie Sapphire 4K40-RGBH 3D right eye or left eye configuration at 220 VAC (full power mode): Projection lens Part number Hazard distance (m) Category Fixed high brightness 0.38:1 fixed 144-136101-XX 0.72:1 fixed...
  • Page 17 163-119102-XX 1.95-3.26:1 zoom 163-120103-XX 2.71-3.89:1 zoom 163-121105-XX 3.89-5.43:1 zoom 163-122106-XX Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 18 For three or more projectors, if the distance between the adjacent lenses is not the same, take the shortest distance. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 19 Permanent show installations containing Risk Group 3 laser-illuminated projectors must meet the following conditions: • Installed by Christie or by Christie-authorized and trained installers. Refer to the EXTERNAL - Laser safety awareness training (Course code: CS-ELSA-01) on the http://www.christieuniversity.com site.

  • Page 20: Product Labels

    Learn about the labels that may be used on the product. Labels on your product may be yellow or black and white. General hazards Hazard warnings also apply to accessories once they are installed in a Christie product connected to power. Fire and Shock Hazard To prevent fire or shock hazards, do not expose this product to rain or moisture.

  • Page 21: Mandatory Action

    SHOCK HAZARD! Disconnect all power sources before performing maintenance or service procedures. Consult the service manual. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 22: Electrical Labels

    Indicates Class 4 laser radiation when open. Avoid eye or skin exposure to direct or scattered radiation. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 23: Additional Safety Hazards

    Contact your dealer Record the information about your projector and keep this information with your records to assist with the servicing of your projector. If you encounter a problem with your Christie projector, contact your dealer. Purchase record...

  • Page 24: Key Features

    0.72:1 fixed 144-110103-XX — 0.9:1 fixed 144-111014-XX — Zoom high brightness Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 25 250 V/32 A IEC309 3.0 m cord—Europe 108-429106-XX 250 V/30 A IEC309 3.0 m cord—Japan 108-398101-XX Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 26: Interconnection And Line Drawings

    Line drawings provide projector dimensions and sizes for installation. To download the latest interconnect diagram or line drawings: Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 27: Technical Support

    2. Sign into the Partner Portal. 3. Navigate to your projector model. 4. Switch to the Downloads tab and expand Line drawings section. Technical support Technical support for Christie Enterprise products is available at: • North and South America: +1-800-221-8025 or Support.Americas@christiedigital.com •...

  • Page 28: Installation And Setup

    Installation and setup Learn how to install, connect, and optimize the projector display. Site requirements To safely install and operate the Christie Sapphire 4K40-RGBH projectors, the installation location must meet these minimum requirements. Physical operating environment • Ambient temperature (operating) 5 to 40°C (41 to 104°F) up to 457.2 meters (1,500 feet) •...

  • Page 29: Power Requirements

    Installation and setup Power requirements Learn the power requirements for Christie Sapphire 4K40-RGBH. Parameter Requirement Rated voltage 100-120 VAC limited power mode 200-240 VAC full power mode Rated current 12A maximum limited power mode 20A maximum full power mode Line frequency...

  • Page 30: Display Panel Components

    Installation and setup Component Description Service door Provides access to the fold mirror, optical zoom/focus, and digital micromirror device (DMD) convergence adjustments as well as the tools for Christie qualified technicians. Display panel Displays the projector menus and status. Keypad interface Controls the projector.

  • Page 31: Ir/Wired Remote Keypad

    The remote also offers a connector for wired connections to the projector. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 32 Selects an active or inactive input on any slot. Not supported. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 33: Required Tools

    • Adjustable wrench • Step stool • Powder-free N-DEX gloves Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 34: Preparing The Installation Site

    If space is limited, aim the projector slightly off-center and use lens offset to center the image on the screen. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 35: Projector Sides

    1. To adjust the vertical position of the projector, extend or retract the adjustable feet on the bottom of the projector using the adjustable knobs on the feet. Christie recommends adjusting the feet from the side or rear of the projector and not the front to avoid exposure to the output light.

  • Page 36: Installing The Projector Lens

    Installing the projector lens Only use lenses designed for Christie Sapphire 4K40-RGBH projectors. Installing a lens not designed for Christie Sapphire 4K40-RGBH, results in a warning that the lens is not present. 1. Turn off the lasers.

  • Page 37: Calibrating The Lens Motor

    Use the correct method of removing the lens. 1. Turn off the lasers. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 38: Installing The Ultra Short Throw Projector Lens

    When using the ultra short throw lens and switching between dark and bright content, focus drift can occur. To help to mitigate this issue, Christie recommends reducing brightness and focusing the content on what you primarily want the projector to focus on, or creating different profiles for the dark and light content.
  • Page 39 6. Manually adjust the corner focus of the image using the focus ring on the lens. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 40: Installing An Intelligent Filter Holder (Ifh)

    Follow these steps to install an intelligent filter holder (IFH), which can be either a color comb 3D or 2D aperture filter, in a Christie Sapphire 4K40-RGBH projector. Warning! If not avoided, the following could result in death or serious injury.
  • Page 41 7. If necessary, use standard optic cleaning practices to clean the optic (for example, gloved hands, isopropyl alcohol, and optical wipe). Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 42: Connecting The Projector To Power

    If the the optical filter calibration was previously performed on a different inlet line voltage (110V vs 220V). Christie Sapphire 4K40-RGBH automatically stores LiteLOC calibrations on a filter-by-filter type basis, and an AC voltage basis. Calibration data is not lost or discarded when changing filters.
  • Page 43 9. Remove the four screws securing the blue plug. The knockout plate is provided. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 44: Connecting Power With A Line Cord

    2. Plug the line cord into AC power and the opposite end to the projector as shown in the image below. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 45: Turning On The Projector

    Use a minimum of 12 AWG copper wire, grounding included, for the connection of the AC power supply to the projector's ground lug. When Christie Sapphire 4K40-RGBH is turned on for the first time, a Hawkeye calibration is performed and this is considered the factory-level calibration. Subsequent calibrations are considered field-level calibrations.

  • Page 46: Projector Led Shutter Indicators

    2. To turn off power to the projector, turn off the projector breaker switch and wait 10 seconds for the electrical charge to dissipate. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 47: Disposing Of The Product Packaging

    Installation and setup 3. Disconnect the power supply cord. Disposing of the product packaging Once the product has been installed and set up, Christie recommends reusing or recycling the product packaging according to your local regulations. Completing the installation checklist Complete the provided installation checklist (P/N: 020-103137-XX) and return it to Christie.

  • Page 48: Aligning The Image

    Realign the lens to the home position after the lens has been offset and out of alignment. 1. Select LENS OFFSET. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 49: Selecting A Test Pattern

    4. To confirm your selection, select Enter. Running a Hawkeye calibration When Christie Sapphire 4K40-RGBH is turned on for the first time, a Hawkeye calibration is performed and this is considered the factory-level calibration. Subsequent calibrations are considered field-level calibrations.

  • Page 50: Adjusting Boresight

    These instructions must be performed after replacing a light engine, fold mirror, relay optics, and zoom/focus assembly or when doing preventative maintenance. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 51 9. From the Test Pattern menu, select the Integrator Rod test pattern. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 52 11. Adjust the Integrator Rod Focus paddle until the edges of the image look sharp as shown in the second image below. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 53 As the zoom is adjusted, the focus may require additional adjustment. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 54: Adjusting The Fold Mirror

    4. Unlock the fold mirror screws to unlock the adjustment knobs. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 55 6. To make vertical adjustments, use the purple knob labeled Vertical. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 56: Aligning The Image With Lens Zoom And Focus

    For best convergence results, Christie recommends disabling all geometry and color (set the color correction mode to Max Drive) correction before adjusting convergence.

  • Page 57: Mechanically Adjusting Convergence

    If adjusting by hand without using the tool, pull out the convergence adjustment knobs to engage them. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 58: Electronically Adjusting Convergence With The Remote

    For the best stability, Christie recommends setting convergence while rotating the knobs in a clockwise direction. This may require first adjusting convergence by turning the knobs counter- clockwise, and finalizing the convergence with a clockwise approach.
  • Page 59 3. Select the corner sprite you want to adjust first. By default the top-left position is selected. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 60: Electronically Adjusting Convergence Through The Menu

    (DMD) convergence. When used in addition Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 61 Aligning the image to mechanical DMD convergence, Christie recommends completing mechanical convergence prior to making electronic adjustments. ™ ™ If warping with Christie Twist or Mystique , adjust the convergence mechanically. Do not use the electronic convergence feature. 1. Before adjusting DMD convergence, make sure the projector has reached a steady operational state.

  • Page 62: Running Auto Setup To Optimize Display Settings

    The system optimizes the active signal and displays a progress message on screen. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 63: Connecting Devices And Establishing Communication

    The Video Input panel has a variety of ports that can be used for control, 3D sync, upgrading, retrieving interrogators, and connecting audio. Video Input panel components The following table lists the video components available depending if the card cage has VOM-IF, VOM-HBI, and CAVE LP connections. Christie Sapphire 4K40-RGBH supports the CAVE LP. Port Description Applies...
  • Page 64 Wired keypad Physically connects a remote control to the projector. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 65: Configuring Video Input

    Default—Supports HDMI, DP, SDI, and ChristieLink. (Default) • SDVoE—Supports HDMI, SDVoE, and ChristieLink. 3. Select Enter. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 66: Enabling Projector Communication

    Select a port configuration before you select a video source. 1. From the display panel, select INPUT. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 67: Selecting A Video Source

    Four-port quadrants—SDI • One-port dual-input 3D (3D license-specific)—HDMI, SDI, DisplayPort, Christie Link When SDVoE is selected, the HDMI, SDVoE, and Christie Link inputs are supported for the one-port configuration. 3. To select the input, select Enter. Connecting an HDMI video source For the projector to accept digital video data from HDMI sources, plug the HDMI source directly into the Video Input panel (the B callout shows the HMID 2.0 port and the P callout shows the 2.1 port in...

  • Page 68: Connecting 12G, 6G, 3G, Or Hd Sdi Video Source

    Some video sources may not be fully compliant with the relevant SDI SMPTE standards and do not include the SMPTE 352M Payload ID information. If the picture from a 1.5G or 3G SDI source does not display as expected, contact Christie Technical Support for an command for SDI-Payload Override the specific signal type.

  • Page 69: Connecting Christie Link Video Source

    Christie Link video loop-out enables signals received on the Christie Link input (labeled Christie Link 1 on the Video Input panel (on page 63)) to be passed through to the Christie Link output (labeled Christie Link 2 on the Video Input panel (on page 63)). The loop through connection is automatically established whenever active Christie Link QSFP modules are plugged into the respective connectors on the projector's Video Input panel.

  • Page 70: Determining If Sdvoe Is Supported

    Connecting devices and establishing communication Input configuration Description One-Port Enables 2D or 3D connection from an SDVOE source (such as the Christie Terra Transmitter). For supported video formats for your projector model, see TruLife+ Supported Video Formats technical reference (P/N: 020-104081-XX).

  • Page 71: Setting Up The Ethernet

    Connecting devices and establishing communication VOM-HBI: 2. When using the Christie serial protocol over Ethernet, connect to port 3002. 3. For applications or equipment using serial communications, use the Christie proprietary serial protocol or Art-Net protocol to communicate with the Ethernet port on the Video Input panel.
  • Page 72 There are 512 channels per universe. Christie Sapphire 4K40-RGBH specifies 24 channels. Christie Sapphire 4K40-RGBH has multiple methods of being controlled in addition to Art-Net. If a setting is changed through another interface, the DMX controller can re-assert control by changing the value on the appropriate DMX channel.
  • Page 73 15 to 24 Reserved Reserved for future use. — — Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 74 One-port, dual-input 3D L:SDI2, R:SDI3 One-port, dual-input 3D L:VOM-DP0, R:VOM-DP1 Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 75: Configuring The 3D Sync In/3D Sync Out Interface

    HBI) is a micro 75 ohm BNC connector. Configuring the RS232 port Configure the RS232 port to send Christie serial commands using a standard RS232 serial cable (the R callout in the Video Input panel image). For more details (including image and callouts) on the Video Input panel, see Video Input panel (on page 63).

  • Page 76: Gpio Connector

    1. Connect the remote cable in the Wired keypad port on the Video Input panel. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 77 4. To enable a wired version of the remote, select Wired Keypad Enabled and select Enter. By default this feature is enabled. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 78: 3D Setup

    3D source material. Hardware requirements Understand the hardware requirements for stereo 3D applications. • Christie Sapphire 4K40-RGBH projector with a Mirage license • 3D stereo sync cable for direct-input 3D (and frame doubled) • A source, usually a computer with a 3D graphics card(s) •...

  • Page 79: Active Stereo 3D Configuration

    3D shutter glasses. This synchronizes the active glasses to alternatively open and close for the active stereo 3D applications. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 80: Passive Stereo 3D Configuration

    The direct-input 3D video stream may be supplied by a One-Port input video configuration (such as one cable supplying the entire frame). Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 81: Setting Up A Single Projector To Display 3D Content

    7. Adjust the slider or enter the dark interval value as required. 8. To confirm your selection, select Enter. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 82: Configuring The Projector For The 3D Source

    IR Emitter for active glasses or a polarization device for passive glasses. Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 83: Color Comb 3D Setup

    Two projectors using one of the two configurations: • Two Christie Sapphire 4K40-RGBH projectors • One or two Christie Sapphire 4K40-RGBH projectors and one Griffyn 4K35-RGB or Griffyn 4K50-RGB projector • 3D stereo sync cable for direct-input 3D (and frame doubled) •...

  • Page 84: Software And Content Requirements

    E—Christie Sapphire 4K40-RGBH or Griffyn Series projector • F—Screen • G—Color comb 3D glasses Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.

  • Page 85: Regulatory

    CISPR 35/EN 55035 Electromagnetic compatibility of multimedia equipment - Immunity requirements Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
  • Page 86 EU Directive (94/62/EC) on packaging and packaging waste • China packaging recycling mark standard (GB18455-2001) Christie Sapphire 4K40-RGBH Installation and Setup Guide 020-103979-01 Rev. 1 (02-2025) © Copyright 2025 Christie Digital Systems USA, Inc. All rights reserved. If printed, please recycle this document after use.
