  • Page 1 Operating and installation instructions Video doorphone set Alerto OR-VID-MD-1084/B STOP!
  • Page 2: Table Of Contents

    TABLE OF CONTENTS 1. SAFETY INSTRUCTIONS ..........................3 2. CHARACTERISTICS OF THE SET ....................... 3 3. TECHNICAL DATA ............................4 4. SET CONSTRUCTION ..........................5 5. INSTALLATION ............................. 5 MONITOR INSTALLATION ............................5 OUTDOOR UNIT WITH CAMERA INSTALLATION ....................6 6.
  • Page 3: Safety Instructions

    Additional information about ORNO products is available at www.orno.pl. Orno-Logistic Sp. z o.o. holds no responsibility for the results of non-compliance with the provisions of the present Manual Orno-Logistic Sp. z o.o. reserves the right to make changes to the Manual - the latest version of the Manual can be downloaded from www.orno.pl Any translation/ interpretation rights and copyright in relation to this Manual are reserved.
  • Page 4: Technical Data

    3. TECHNICAL DATA MONITOR OUTDOOR UNIT...
  • Page 5: Set Construction

    4. SET CONSTRUCTION MONITOR OUTDOOR UNIT 1. Microphone 13. Microphone 2. Call forwarding 14. Twilight sensor 3. Monitoring 15. Night light 4. Gate opening 16. Camera lens 5. Wicket opening 17. LED indicator 6. Answer/end the call 18. Call button 7.
  • Page 6: Outdoor Unit With Camera Installation

    OUTDOOR UNIT WITH CAMERA INSTALLATION fig. 3 Outdoor unit placement Recommended installation height of the outdoor unit is 140-170cm. The correct location of the outdoor unit determines the comfort of working with the device. It is recommended to test the device before making mounting holes. Do not place the outdoor unit and monitor in the same room as feedback may occur.
  • Page 7: Wiring Diagrams

    6. WIRING DIAGRAMS Before drilling the installation holes, it is recommended to carry out a functional test of the device. To do this, connect the device for a test according to the wiring diagram. The first person holding the camera should use the button to call the second person who is at the monitor.
  • Page 8: Set Operation

    The video doorphone cables should not be routed in one cable with the cables of other installations such as bell, alarm, etc. Any power and telecommunication cables emitting strong magnetic fields (e.g. loudspeaker columns, TV set) in direct contact with the cables connecting the outdoor unit to the monitor may adversely affect the operation of the set. If the user has other connection cables than the recommended ones, it is allowed to use them, however, it is necessary to make a test connection of the set in order to check its correct functioning.
  • Page 9: Call Forwarding To An Additional Monitor

    Note: if only one outdoor unit is connected to the set, you can exit the monitoring mode by pressing the monitoring button again. The other devices (CAM1/DOOR2/CAM2) must be set from the settings menu to the mode of operation. Note: if you are using two monitors, you can also start monitoring mode simultaneously on another monitor. The same images will appear on both monitors.
  • Page 10: Settings Menu

    8. SETTINGS MENU Note: The settings menu can be navigated using two buttons: the menu and the up/down navigation button ��. After opening the button setting menu, the menu button serves as the confirmation button while the up/down button �� is used to navigate between categories and options in the settings.
  • Page 11: Operating Mode Settings

    OPERATING MODE SETTINGS Mode Enter the operating mode settings by selecting the tab in the main menu. Mode Designate the monitor as a main (master) or additional (slave) monitor. Door2 status Enable/disable view from second outdoor unit. Door1/Door2 Set the electric door strike release time for Door1 or Door2 (from 1 to 10 seconds). unlock time Option to enable automatic recording: Record mode...
  • Page 12: Image Settings

    IMAGE SETTINGS Enter the image settings by selecting the Image tab in the main menu. In order to get the best possible image, you can configure the parameters of each connected camera (image brightness, contrast and color saturation) by adjusting the values under the current lighting conditions.
  • Page 13: Alarm Instructions

    9. ALARM INSTRUCTIONS Cam1 and Cam2 are equipped with an alarm function. For the alarm function to work properly, it is required to connect a motion sensor to the selected camera according to the diagram below. If motion is detected, an alarm will be triggered: a bell sound will be played from the main monitor (for up to 120 seconds).
  • Page 14: Troubleshooting

    10. Scratched monitor a) check whether the protective film is removed from the screen. ORNO-LOGISTIC Sp. z o.o. ul. Rolników 437, 44-141 Gliwice, Poland tel. (+48) 32 43 43 110, www.orno.pl NIP: 6351831853, REGON: 243244254...
