- Page 1 ARCUS RFID VIDEO-DOORPHONE SET OPERATING AND INSTALLATIONS MANUAL Model: OR-VID-JS-1053/W; OR-VID-JS-1053/B...
-
Page 2: Table Of Contents
Additional information about ORNO products are available at www.orno.pl. Orno-Logistic Sp. z o.o. holds no responsibility for the results of non-compliance with the provisions of the present Manual. Orno Logistic Sp. z o.o. reserves the right to make changes to the Manual - the latest version of the Manual can be downloaded from www.orno.pl. Any translation/interpretation rights and copyright in relation to this Manual are reserved. -
Page 3: Set Characteristics
SET CHARACTERISTICS The video-doorphone is designed for installation in 1 family buildings. Functions: - talking to and observing the person at the entrance; - direct control of the electric door strike; - possibility to control the gate; - infrared diode lighting for night vision; - smooth adjustment of the monitor parameters (picture brightness, call and ringing volume);... -
Page 4: Installation
2. External panel with camera Microphone Proximity card and tags reader Reset button for ID media Camera IR illumination Call button Loudspeaker INSTALLATION We recommend that you perform a functional test of the device before making the mounting holes. To do so, connect the device for a test according to the wiring diagram. -
Page 5: Wiring Diagrams
1. External panel with camera The correct location of the outdoor panel determines the 27cm comfort of use. Remember not to choose your location with high sunshine and exposed to heavy precipitation. The camera should be installed at a height of 1.4 ~1.7 m. 1. - Page 6 While designing the wiring system, take into account the suitable cross-section of cables: up to 30 m - recommended cable XzTKMXpw 3 x 2 x 0,5 mm from 30 m to 100 m - recommended cable XzTKMXpw 3 x 2 x 0,8 mm The connection to the electromagnetic lock should be made with 2 x 1 mm .
-
Page 7: Operation
OPERATION Light up the monitor screen, Press call button which will display the picture of the caller. Automatically save the visitor's picture. To open the wicket, touch the To start the conversation press the button Wicket opening button Preview/conversation in conversation mode If the conversation is not started, the picture is automatically switched off after 60 seconds. -
Page 8: Problem Solving
2. Preview/monitoring In the monitor standby mode, use the button 3. Working time a) connection time: about 60 seconds b) talk time: about 60 seconds c) preview time: about 60 seconds 4. Remote opening of the wicket If an electric door strike is connected to the device, it is possible to open the door remotely. For this purpose, use the button on the monitor panel during conversation or viewing. -
Page 9: Cleaning And Maintenance
3. In the image, numerous interferences, no synchronicity (image blinks) a) the connection cable has a cross-section not matching the length b) connection too long - use shielded cable c) poor cable quality d) strong source of electromagnetic interference - use shielded cable 4. - Page 10 Proper handling of used equipment prevents negative consequences for the environment and human health! (11/2020) PRODUCER ORNO-LOGISTIC Sp. z o.o. ul. Rolników 437, 44-141 Gliwice, tel. 32 43 43 110, www.orno.pl...
