Charder MS4640 User Manual

Stand-on floor scale
Hide thumbs Also See for MS4640:
Table of Contents

Advertisement

Quick Links

Download this manual
Stand-on Floor Scale
USER MANUAL
MS4640
Please keep the instruction manual at hand and follow instruction for use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS4640 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charder MS4640

Summary of Contents for Charder MS4640

  • Page 1 Stand-on Floor Scale USER MANUAL MS4640 Please keep the instruction manual at hand and follow instruction for use.

  • Page 2: Table Of Contents

    CONTENTS I. Explanation of Graphic Symbols on Label/Packaging .. 3 II. Copyright Notice ..........5 III. Safety Notes ............. 6 A. General Information ........6 B. EMC Guidance and Manufacturer's Declaration ... 11 IV.SPECIFICATION ..........15 V. Installation ............16 A、Standard Accessories ........

  • Page 3: Explanation Of Graphic Symbols On Label/Packaging

    I. Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...

  • Page 5: Copyright Notice

    All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent.

  • Page 6: Safety Notes

    III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.

  • Page 7: Safety Instructions

    understand Arabic numerals (e.g. 1, 2, 3, 4...) - Basic hygiene knowledge - Trained in device's operation - Read the instruction manual (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable.

  • Page 8: Maintenance

    Always disconnect device from mains power before  cleaning. Maintenance Please contact your local Charder distributor for  regular maintenance and calibration, regular checking of accuracy is recommended; frequency to be determined by level of use and state of device.
  • Page 9 All maintenance, technical inspections, and repairs  should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Disposal This product is not to be treated as regular ...

  • Page 10: Incident Reporting

    Incident Reporting Any serious incident that has occurred in relation to  the device should be reported to the manufacturer, EU representative (if device is used in EU member state), and competent authority of user/subject's member state.

  • Page 11: Emc Guidance And Manufacturer's Declaration

    B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic...
  • Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance Electromagnetic test level environment- test...
  • Page 13 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity IEC 60601 test Compliance Electromagnetic environment- test level level...
  • Page 14 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedth eoreticallywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.

  • Page 15: Iv.specification

    IV.SPECIFICATION Model MS 4640 Display DP3710 Data transfer USB (B-type) Capacity 300kg x 0.1kg Accuracy ±0.15kg Weight Unit LCD Display 1.0 inch LCD display with 5 and 1/2 digits Dimension Platform size: 340 x 450 mm ON/OFF, ZERO, PRINT, BMI, HOLD, PRE-TARE, Key Functions TARE , CLEAR, ENTER, 0~9 , M1-5 ...

  • Page 16: Installation

    V. Installation A、Standard Accessories Accessories Item Spec. Qty. Adjustable feet M6*15 Spacer ∮6.6*∮13 Fixed plate (top) SS-4961 Fixed plate SS-4971 (bottom Tapping Screw M3*6 Plastic anchor 1”(white) Screw 4*20 USB cable...

  • Page 17: B、Power Adaptor Standards

    B、POWER ADAPTOR STANDARDS CAUTION: The device is only compatible with restricted power adaptors in dashed block below.

  • Page 18: C、Panel

    C、PANEL DP3700 DP3710 (Wireless optional) WIRELESS SYMBOL...

  • Page 19: D、Key Function

    D、KEY FUNCTION Description Turn ON/OFF the scale ON/OFF PRINT Data transmission via interface(Print-out the results) To determine Body Mass Index To determine stable weighing value in case of unstable HOLD weight. To reset the display to 0.0kg display / Zero the scale (±2% ZERO of full capacity) M1-5...

  • Page 20: E、Lcd Symbol Description

    E、LCD SYMBOL DESCRIPTION F、Definitions Stable symbol: To indicate that the weight is stable. Minus weight: Weight under zero. Zero symbols: Weight is at zero point. Low battery: Battery need to charge or replaced with new ones.

  • Page 21: G、Time Setting

    G、TIME SETTING Long press HOLD key for 3 seconds to enter the TIME SETTING mode, beginning with the top row, with the flashing digit. Press HOLD key after successful change to move to next step. EX: To input Dec 25, 2008, 8:00am. Enter year using keys from 0~9.

  • Page 22: H、Using Scale

    If a person is heavier than the scale capacity, the display will show the „Err” prompt (= overload). I、USING HOLD FUNCTION Charder Medical Scale is provided with the integrated HOLD function to determine the ‘locked’ weight by capturing the average balance weight from the fluctuation of weighing on the platform. It enables people to be weighed accurately whenever the movements on the scale platform may not be stabilized.
  • Page 23  Wait for a few seconds of blinking signal until LCD screen displays a fixed average value based on fluctuating weight, the weighing result will be a locked weight value on the LCD display.  To release the locked weight value on display simply remove the weight substance from the platform or press the [HOLD] key again and the display will return to normal mode automatically for the next new weighing.

  • Page 24: J、Using Bmi Feature

    BMI value. The weight and height can be changed whenever the weight on the platform is changed accordingly; CHARDER Scale is capable of calculating the BMI value according to the changed weight and height spontaneously.

  • Page 25: K、Using Tare Function

    K、USING TARE FUNCTION TARE allows the user to subtract the tare weight from the gross weight of a substance that contains the actual weight to be weighed (gross weight), thus giving the true weight (net weight) such as product package or person unable to take off certain clothing substance but requires to be weighed precisely.

  • Page 26: L、Using Internal Setting

    L、USING INTERNAL SETTING ↓ ↓ ← ← Switch ON the scale and long press [ZERO] key for 3 seconds. “SETUP” will display on LCD and then “A.OFF” is shown on the LCD successively for 3 mode settings. AUTO-POWER OFF TIME SETUP Press [HOLD] to enter auto-off time setting 120 sec / 180 sec / 240 sec / 300 sec / off Press [HOLD] to go through selection &...

  • Page 27: Vi.storing And Re-Calling Pre-Tare Weight

    Note: To apply the changes proceed by pressing [TARE] until “END” is displayed on the screen, and then press [HOLD] to confirm changes. VI.STORING AND RE-CALLING PRE-TARE WEIGHT This scale model can store up to 5 sets of pre-tare values, and there are two methods to store pre-tare value –...
  • Page 28 B. Enter Weight Using 0~9 Keys: DESCRIPTION EXAMPLE Press [PRE-TARE] key, the default value of 50kg will blink in the upper LCD screen.  NOTE: It will return to normal mode after seconds weighing objects are placed onto the platform loadcells. Manually enter numerical 0~9 key digits as the required pre-tare weight.
  • Page 29 Press [ENTER] to save each pre- tare weight value into the memory, thus the scale instrument will make beep sound to confirm changes. Press [Clear] to go back to normal mode & perform the next new weighing. Press [CLEAR] key to correct digits in case if mistakes are made in typing;...
  • Page 30 C. RECALL PRE-TARE VALUE DESCRIPTION EXAMPLE Long press PRE-TARE key for 3 seconds; the display will recall the memory saved for the pre-tare value starting from “m1” up to “m5”. The pre-tare value will blink. Enter numerical keys 1 ~ 5 to recall a memory pre-tare value Press [ENTER] key to perform the minus subtraction of the pre-tare weight recalled from the memory;...

  • Page 31: M、Printing Function

    HyperTerminal program in user’s computer for printer port parameters. 3. Once the HyperTerminal setting is ready, make sure the USB cable is connected properly between the user PC’s USB port and the CHARDER Scale Model again. Press PRINT button on the Scale Display Panel for...
  • Page 32 Hyper Terminal is a freeware on PC Windows XP SP3 or lower to setup the PC printer com-port with USB cable connector transmission. For use on Windows Vista or higher please download hyper terminal software program from Charder website: http://www.chardermedical.com/download/dlist-4.htm Start Hyper Terminal After taking the weight and BMI, run Hyper Terminal program from the PC’s...
  • Page 33 While the Hyper Terminal program is running, type “P” KEY on the PC keyboard to transmit a print command to printout from the thermal printer on the CHARDER scale for hard copy of weighing data & BMI. Or, press the [PRINT] button on the display panel of the CHARDER scale, the...

  • Page 34: Vii.wireless Connection

    printout presented below is the standard format print layout as well as shown on the HyperTerminal computer screen. GROSS WEIGHT 70.00kg TARE WEIGHT 0.00kg NET WEIGHT 0.00kg USER HEIGHT 170.0cm USER B.M.I. 24.2 01/01/2013 10:00 VII.WIRELESS CONNECTION Enable the Bluetooth function on user ANDROID version 4.3+ smart phone/tablet or I-Phone IOS version is an alternative wireless transmission technology to connect with Display Head DP3710 version when there is limited working space for cable wire...

  • Page 35: Viii.assembly Of Dp3700/3710 Bracket

    VIII.ASSEMBLY OF DP3700/3710 BRACKET wall Adjustable Fixed plate Fixed plate Tapping Plastic spacer Screw feet (top) (bottom) Screw anchor...

  • Page 36: Ix.instruction For Charging And Connecting

    IX.INSTRUCTION FOR CHARGING AND CONNECTING prompt displays on the LCD, please charge the scale with MS 4640 exclusive adaptor or replace the batteries. Locate adaptor plug on the right side of indicator. DP3710 display USB Connector AC Jack Connector DP3700 display USB Connector AC Jack Connector...

  • Page 37: A、Using Rechargeable Battery (Optional)

    A、USING RECHARGEABLE BATTERY (OPTIONAL) The rechargeable battery should be recharged at least every 3 months regardless if it is used or not. After a long period in storage, e.g. over 3 months, the battery should run a full cycle (charge/discharge) to allow it to restore to full capacity. Make sure the rechargeable battery housing is installed properly and insert with the...

  • Page 38: B、Instruction For Battery Installation

    B、INSTRUCTION FOR BATTERY INSTALLATION Slide-Open the battery housing cover Take out the battery housing Use either Rechargeable Battery Pack or AA-size Batteries for installation...
  • Page 39 Rechargeable Battery Housing AA-size Battery Housing Make sure all batteries are installed into the housing with correct position Install the battery housing into the compartment and make sure the right side of housing pin is facing towards inside of the connecting position...
  • Page 40 Slide back the cover to close the battery housing compartment. Then switch on the power button on the panel to see if the battery housing is correctly installed with good battery lifetime.

  • Page 41: X.error Message

    X.ERROR MESSAGE...
  • Page 42 Notes _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...
  • Page 43 Notes _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________ _________________________________________________________________________...

  • Page 44: Xi.manufacturer's Declaration Of Conformity

    XI.Manufacturer’s Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
