Summary of Contents for Charder MS4200
- Page 1 Infant Scale& Stand-on Floor Scale USER MANUAL MS4200.MS4202L Infant Scale & Stand-on Floor Scale Please keep the instruction manual at hand and follow instruction for use.
-
Page 3: Table Of Contents
II. Installation ............. 15 A. Inserting Batteries ........... 15 B. Using Adapter ..........16 C. Attaching tray (MS4200) ........17 D. Height Measure Attachment (MS4200) ....18 III. Indicator ............... 19 IV. Using Device ............20 A. Basic Operation ..........20 B. -
Page 4: Explanation Of Graphic Symbols On Label/Packaging
Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
- Page 6 This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.
-
Page 7: Safety Notes
I. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. - Page 8 Intended patient profile (a) Age: no restrictions (subject to size limitations of device and maximum capacity) (b) Weight: no restrictions within device weight capacity (c) Patient Conditions: require measurement of body weight. Can fit upon device. Intended user profile (a) At least 20 years old (b) Minimum knowledge: - To be able to read at a high-school level and understand Arabic numerals (e.g.
- Page 9 Improper installation will render the warranty null and ◼ void. Observe permissible ambient temperatures for use ◼ Maintenance Please contact your local Charder distributor for regular ◼ maintenance calibration, regular checking accuracy is recommended; frequency to be determined by level of use and state of device.
-
Page 10: Incident Reporting
All maintenance, technicalinspections, and repairs should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty. -
Page 11: Emc Guidance And Manufacturer's Declaration
B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Emission test Compliance... - Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance Electromagnetic test level environment-guidance...
- Page 13 Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance Electromagnetic level level environment-guidance...
- Page 14 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.
-
Page 15: Installation
II. Installation Device can be used once batteries are installed (or adapter) is plugged in. A. Inserting Batteries 1. Locate battery cover on bottom of device 2. Remove battery cover. Insert batteries. Ensure polarity is correct. -
Page 16: Using Adapter
3. Insert all batteries. Close cover and turn scale right-side B. Using Adapter Device can be powered via adapter using port located at rear of device. Plug adapter into device before plugging into mains. -
Page 17: Attaching Tray (Ms4200)
C. Attaching tray (MS4200) 1. Slide tray onto device 2. Turn device upside down. Secure tray to device by turning knob on each side of tray. (turn clockwise to tighten, turn counter-clockwise to loosen) 3. Device can now be used for measurement. -
Page 18: Height Measure Attachment (Ms4200)
D. Height Measure Attachment (MS4200) 1. Attach bracket to device and baby tray, and fasten screws using screwdriver. Bracket 2. Connect height measure attachment to bracket.A clicking noise will be heard. -
Page 19: Indicator
III. Indicator Indicator and Key Functions Key Functions 1. On/Zero/Off: Turn device on and off. Zero scale (± 2% of full capacity). Press and hold for 3 seconds to enter settings. 2. Hold/BMI: Determine stable weighing value - used when weight is unstable. -
Page 20: Using Device
IV. Using Device A. Basic Operation Switch on the device using [On/Zero/Off] key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press [On/Zero/Off] key to zero the device. -
Page 21: Bmi
> 40 Very High (World Health Organization adult BMI standards) V. Wireless Connection If the device has the wireless or bluetooth module installed, the indicator can transmit measurement results wirelessly. Please see Charder wireless or bluetooth software instructions for details. -
Page 22: Device Setup
VI. Device Setup When the device is switched on, press and hold the [On/Zero/Off] key until the display shows "SET" followed by"A.OFF” (first option in setting menu). In device setup menu: [Hold/BMI] to toggle menu option [Tare] to confirm selection / enter submenu Auto Power-Off: Instruct device to shut off automatically after a certain period of time. - Page 23 Wi-Fi (optional): If device has Wi-Fi module installed, Wi-Fi function can be turned on or off. Press [Hold/BMI]to toggle between on/off, and [Tare] to confirm selection. Wi-Fi Setting (optional): If device has Wi-Fi module installed, this option will appear. Press [Hold/BMI] to toggle between "Auto" and "PKEY". Press [Tare] to confirm selection.
-
Page 24: Troubleshooting
Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid. -
Page 25: Self-Inspection
Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼ Broken or damaged wires causing short circuit or faulty ◼... - Page 26 2. Indicator damage Possible hardware defects include: uneven brightness in ◼ LCD screen, blurred text, smeared rainbow screen, incorrect decimal display Unable to save or read data ◼ Indicator shows "ERRL" after device is switched on ◼ Keys not responding ◼...
- Page 27 Error Messages Error Message Reason Action Low battery Replace batteries warning Voltage of battery is too low to operate device Overload Reduce weight on Total load exceeds measurement device's maximum platform and try capacity again Error normally Counting Error caused by faulty Signal from loadcell or wiring.
-
Page 28: Product Specifications
325(W) x 310(D) x 50(H) mm Device 4.3 kg Weight MS4202L: On/Zero/Off, Hold/BMI, Key Functions Tare MS4200: On/Zero/Off, Hold, Tare Wireless module (optional) Data Transmission NOTE: Device should be connected to network by qualified distributors only Power Supply AA battery / Power adapter +5℃~+35℃... -
Page 29: Power Adapter Standards
B. Power Adapter Standards Warning The device is only compatible with themanufacturer's power adapters specified below DRAWI CE APPROVED TYPE Adapter VOLTAGE NG NO. TYPE NO. / plug MODEL NO. CD-AD- UES12LCP-120100 12V 0.5A 00044... - Page 30 Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
- Page 31 Notes ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________ ______________________________________________...
-
Page 32: Declaration Of Conformity
IX. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
