- Page 1 Stand-on Floor Scale USER MANUAL MS4900 Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS I.Explanation of Text/Symbols on Device Label/Packaging ..................3 II. Copyright Notice ............5 III. Safety Notes ............... 6 A. General Information ............ 6 B. EMC GuidanceandManufacturer's Declaration ....10 IV. Installation ..............14 A. Assembly ..............14 B. Inserting Batteries ............ 17 C. -
Page 3: I.explanation Of Text/Symbols On Device Label/Packaging
I.Explanation of Text/Symbols on Device Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 Device conforms to (EU) 2017/745 Regulation on Medical Devices. Fourdigit number is identifier for medical device Notified Body Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied.
-
Page 5: Copyright Notice
Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. Charder reserves the right to correct misprints in the manual without prior notice, and modify the exterior of the device for quality purposes without customer consent. -
Page 6: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. - Page 7 (c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user.
-
Page 8: Maintenance
All maintenance, technicalinspections, and repairs should be conducted by an authorized Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Disposal This product is not to be treated as regular household waste, ... -
Page 9: Incident Reporting
Warning Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction. Do not touch the power supply with wet hands. Do not crimp the power cable, and avoid sharp edges. -
Page 10: Emc Guidanceandmanufacturer's Declaration
B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic... - Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity test IEC 60601 Compliance level Electromag test level netic...
- Page 12 NOTE UT is the a.c. mains voltage prior to application of the testlevel. Guidance and manufacturer’s declaration-electromagnetic immunity Theproduct is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. Immunity test IEC 60601 test Compliance...
- Page 13 Field strengths from fixed transmitters, such as base stations for radio (cellular/cordless) telephones and land mobile radios,amateurradio,AMandFMradiobroadcastandTVbroadcastcannotbepredictedtheore ticallywithaccuracy.To assess the electromagnetic environment due to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field strength in the location in which the product is used exceedstheapplicable RF compliance level above, the product should be observed to verify normal operation.
-
Page 14: Installation
IV. Installation A. Assembly Standard Column 1. Fasten and tighten four screws at the bottom of the base. Ensure four adjustable feet and stability foot are at same level before using device. Four screws Castor wheel column 1. Fasten and tighten four screws at the bottom of the base... - Page 15 2. Ensure four adjustable feet and stability foot are at the same level before using the device. Rotate counter-clockwise to extend, clockwise to retract Adjustable feet Stability foot...
- Page 16 3. Retract stability foot before moving device using castor wheels Note: rotate counter-clockwise to extend, clockwise to retract Ensure stability foot is retracted before using castor wheels...
-
Page 17: Inserting Batteries
B. Inserting Batteries 1. Open battery housing cover 2. Remove battery housing 3. Insert batteries 4. When inserting battery housing, ensure contact with housing pins is correct. 5. Re-insert battery housing. 6. Close battery housing cover. -
Page 18: Using Adapter
C. Using Adapter 1. Connect adapter to indicator before connecting to mains power supply 2. Disconnect adapter from mains power supply before unplugging adapter pin from indicator. -
Page 19: Attaching Height Stadiometer To Column
D. Attaching Height Stadiometer to Column Standard (Narrow) Column Step 1. Attach two fixing blocks to Step 2. Attach height rod to blocks column using four flat-head using two flat-head screws screws Item Name Quantity Fixing block screws Fixing blocks Height Rod to fixing block screws... - Page 20 Castor Wheel Column 1. Attach brackets to column with 2. Attach height rod to brackets round-head screws using flat-head screws Item Name Quantity M5x0.8x11 round head screw Relief Bushing Bracket for HM200D/HM201D/HM201M Height Stadiometer (Compatible with: HM200D/HM201D/HM201M) M5x10L flat head screw Fixing block M5x0.8x11...
- Page 21 Connecting height stadiometer to indicator (HM200D/HM201D) Secure excess cable to column Digital height rod data transmission port on indicator...
-
Page 22: Attaching Thermal Printer
E. Attaching Thermal Printer Standard (Narrow) Column Washer head screw M5*0.8*15mm Cross head screw M4*0.7*6mm... - Page 23 Castor Wheel Column Print Button Printer Bracket Screws for Printer Bracket Screws for Bracket Item Parts M5*15L head screw Screws for printer bracket Printer bracket TP2100/TP2110 Thermal Printer 1 (purchased separately)
- Page 24 1. Install the side bracket 2. Install the thermal printer on the bracket...
-
Page 25: Indicator
V. Indicator A. Indicator and Key Functions (lb not available on OIML-approved model) Key Function (UNIT): Switch between units. For OIML-approved version, only kg is activated. (PRINT):When printer or PC is connected to the scale, press this key to print results. (ON/OFF/ZERO): Turn device on and off. -
Page 26: Display Layout
B. Display layout Stable Unit type Height Hold Negative Zero Gross Low battery Hold:Hold function is activated BMI: BMI function is activated kg: Current unit is kg Stable: Weight is stable. Net: Current result is net weight Negative: Weight is under zero Zero: Weight is at zero Gross: Current result is gross weight. -
Page 27: Using Device
VI. Using Device A. Basic Operation Switch on the device using key. The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg" does not display on indicator, press key to zero the device. -
Page 28: Bmi
C. BMI 1. Weigh subject normally. After "stable" symbol appears on indicator, press the key to enter BMI mode. 2. Display will show last recorded height. Left-most digit will flash. 3. Enter height using numeral keys (ex: 170 cm). Input will automatically move to next digit. -
Page 29: Device Setup
VII. Device Setup When the device is switched on, press and hold the key for about 3 seconds, until the display shows the "SEt”, followed by "A.OFF” (first option in setting menu). In device setup menu: to toggle menu option to confirm selection / enter submenu Auto Power-Off: Instruct device to shut off automatically after a certain period of time. -
Page 30: Setup Rs232 Connection To Pc
For successful connection, PC hardware must be connected to device using manufacturer's designated RS232 cable. 1. Hyper Terminalfreeware software can be used to connect the device to a PC. The software program can be downloaded from the Charder website: [LINK URL]https://www.chardermedical.com/download.htm 2. - Page 31 2. Name the connection and click 3. Select COM (1, 2, 3, 4...) under [OK]. "Connect using" dropdown menu, and press [OK]. 4. Set Port Settings as below: Baud rate: 9600 Bits per second Data bits: 8 Parity check: None ...
-
Page 32: Troubleshooting
IX. Troubleshooting Before contacting your local Charder distributor for repair service, we recommend considering the following troubleshooting procedures: Self-inspection 1. Device will not power on If battery power is depleted, replace with new batteries If batteries are not used, check if the power adapter is plugged into ... - Page 33 Faulty adapter 2. Indicator damage Possible hardware defects include: uneven brightness in LCD screen, blurred text, smeared rainbow screen, incorrect decimal display Unable to save or read data Indicator shows "ERRL" after device is switched on Keys not responding ...
-
Page 34: Product Specifications
X. Product Specifications Model MS4900 Display DP3400 0-100 kg x 0-200 kg x 0.1 kg 0.2 kg Capacity 300kg x 0.1kg 100-150 200-300 kg x 0.2 kg kg x 0.5 kg Accuracy ± 2.0e ± 1.5e Weight Measurement non-OIMLapproved OIML... -
Page 35: Standard Accessories
Warning The device is only compatible with the power adapters specified below. DRAWING NO. CE APPROVED TYPE NO. / TYPE Adapter VOLTAGE MODEL NO. plug 12V 1A CD-AD-00044 UES12LCP-120100SPA Standard Accessories Accessories Item Spec. Qty. Standard column: M6 x 20 flat head screw Castor wheel column:... -
Page 36: Declaration Of Conformity
XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
