- Page 1 Stand-on Floor Scale USER MANUAL MS4203 Stand-on Floor Scale Please keep the instruction manual at hand and follow instruction for use.
-
Page 2: Table Of Contents
CONTENTS I. Explanation of Graphic Symbols on Label/Packaging.. 3 II. Copyright Notice ............5 Taichung City, 41262 Taiwan ......... 5 III. Safety Notes ............6 A. General Information ...........6 B. EMC Guidance and Manufacturer's Declaration ..9 IV. Installation ............. 13 A. -
Page 3: Explanation Of Graphic Symbols On Label/Packaging
I. Explanation of Graphic Symbols on Label/Packaging Meaning Text/Symbol Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 4 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)
-
Page 5: Copyright Notice
Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 6: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. -
Page 7: General Handling
instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user. -
Page 8: Maintenance
Charder service partner, using original Charder accessories and spare parts. Charder is not liable for any damages arising from improper maintenance or usage. Dismantlement of the device will void the warranty. -
Page 9: Emc Guidance And Manufacturer's Declaration
B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Electromagnetic Emission test Compliance... - Page 10 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Compliance IEC 60601 Electromagnetic Immunity test test level level environment-guidance...
- Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that is used in such and environment. IEC 60601 test Compliance Electromagnetic Immunity test level level environment-guidance...
- Page 12 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help prevent electromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximum output power of the communications equipment.
-
Page 13: Installation
IV. Installation Device can be used once batteries are installed (or adapter) is plugged in. A. Inserting Batteries 1. Locate battery cover on bottom of device 2. Remove battery cover. Insert batteries. Ensure polarity is correct. -
Page 14: Using Adapter
3. Insert all batteries. Close cover and turn scale right-side B. Using Adapter Device can be powered via adapter using port located at rear of device. Plug adapter into device before plugging into mains. -
Page 15: Indicator
V. Indicator Indicator and Key Functions Key Functions 1. On/Zero/Off: Turn device on and off. Zero scale (± 2% of full capacity). Press and hold to turn off. Indicator Symbols 2. Zero Indicator: Device is at zero 3. Level Indicator: Determine if device is level 4. -
Page 16: Using Device
VI. Using Device A. Basic Operation There are 2 methods to switch on the device: Auto-on 1. Step onto the device for 2 seconds to turn on device 2. Leave measurement platform 3. The device will automatically perform self-calibration. Manual switch-on 1. -
Page 17: Zero
will display "Err" prompt due to overload. B. Zero The zero function allows the user to clear the residual value of objects from the device's measurement result. Zero can be used when weight of object is ≦at/below 2% of full capacity. -
Page 18: Troubleshooting
Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid. - Page 19 Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key ◼ Broken or damaged wires causing short circuit or faulty ◼...
- Page 20 2. Indicator damage Possible hardware defects include: faded LCD screen, blurred text, smeared rainbow screen, incorrect decimal display Unable to read data ◼ Indicator shows "Err.E" after device is switched on ◼ Keys not responding ◼ Buzzer malfunction ◼...
-
Page 21: Low Battery
Error Messages Error Message Reason Action Low battery warning Replace batteries, Voltage of battery or plug in adapter is too low to operate device Overload Reduce weight on Total load exceeds measurement device's maximum platform and try capacity again Error normally Counting Error caused by faulty... -
Page 22: Product Specifications
VIII. Product Specifications A. Device Information Model MS4203 0-150 kg x 50g Capacity 150-220 kg x 100g Accuracy ± 1.5 Weight Measurement 1.0-inch LCD screen Screen (5 digits) OIML Class III 325(W) x 310(D) x 65(H) Device Dimension Device Weight 3.3 kg (Without Battery) -
Page 23: Power Adapter Standards
B. Power Adapter Standards Warning The device is only compatible with the manufacturer's power adapters specified below DRAWIN CE APPROVED TYPE TYPE Adapter VOLTAGE G NO. NO. / MODEL NO. plug CD-AD-0 UES12LCP- 12V 1A 0044 120100SPA... -
Page 24: Declaration Of Conformity
IX. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
