Overview
This guide covers:
PrimeSHOT 10 HDMI PTZ camera
North America – 999-30410-000 (black), 999-30410-000W (white)
n
Europe and UK – 999-30410-001 (black), 999-30410-001W (white)
n
n Australia and New Zealand – 999-30410-009 (black), 999-30410-009W
(white)
PrimeSHOT 20 HDMI PTZ camera
North America – 999-30420-000 (black), 999-30420-000W (white)
n
Europe and UK – 999-30420-001 (black), 999-30420-001W (white)
n
n Australia and New Zealand – 999-30420-009 (black), 999-30420-009W (white)
What's in this guide
This guide covers
Physical features
n
Switch settings
n
Installation
n
Initial set-up and system administration
n
Performance/behavior configuration
n
System maintenance
n
n Operation
Command reference
n
Troubleshooting
n
For your convenience, the information you need to install this product is also available in the smaller,
stand-alone Installation Guide for PrimeSHOT HDMI PTZ Cameras.
Features
n PrimeSHOT 10 HDMI: PTZ camera for small to medium spaces
PrimeSHOT 20 HDMI: PTZ camera for medium to large venues such as houses of worship and
lecture theaters
2.12 Megapixel effective, native 1080p/60 full HD image sensor
n
PrimeSHOT 10 HDMI: 10x zoom, 67° horizontal field of view (wide end)
n
PrimeSHOT 20 HDMI: 20x zoom, 55° horizontal field of view (wide end)
n Simultaneous HDMI 1.3 and IP (H.264) streaming outputs
Precise pan and tilt movements at up to 90° per second
n
Command Line Interface SHell (CLISH) and VISCA control for ease of integration
n
n Enterprise-class IT administrative capabilities with full web controls for remote management
Presenter-friendly IR remote control
n
