1 Accessories ............................. 3 2 General Introduction ..........................4 2.1 Features and functions ........................4 2.2 Specifications ............................. 7 3 Framework ............................13 3.1 Dimensions ............................13 4 Installation ............................15 4.1 Install the speed dome ........................15 4.2 Install the speed dome in the bracket ..................16 4.3 Wall mount bracket installation ....................17 5 Menu ............................20...
2 General Introduction 2.1 Features and functions Different user rights for each group, one user belongs to one group. User Management The user right shall not exceed the group right. Data Transmission Support cable network data transmission via Ethernet. Support central server backup function in accordance with configuration and setup Storage Function in alarm or schedule setting.
Page 5
This series speed dome has the following features: - On-Screen Menu This series product menu supports multiple languages. It is easy for you to view dome information and configure dome, camera parameters. - Support multiple protocols Use various devices (such as matrix, control keyboard and DVR) and protocols to operate speed dome. - Proportional Pan and Tilt This function keeps the image from moving too fast when there is a large amount of zoom.
Page 6
- Auto Focus Auto focus allows the lens to remain in focus during zoom-in, zoom-out and motion functions to get vivid image. You can use FAR or NEAR button to adjust focus manually. - Backlight Compensation Balance the brightest and darkest sections of a scene to produce a more vivid picture. - Pan Tilt and Zoom Supports zoom in and zoom out during tilt and pan movement.
2.2 Specifications 2.2.1 Performance Specifications All digital design. All data are in the connection board. No data loss when power off occurs. - Integrated design, high stability. - Quick-installed high definition speed dome max support 255 presets. Support 8 auto touring. Each touring max has 32 presets. - Low and medium speed dome max support 80 presets.
Page 8
2.2.2 Technical Specifications Power AC 24V/3A (±10%) (Includes temperature control circuit) Camera Driver Consumption Decoder Built-in Engine Stepper motor 255 (In PELCOD, PELCOP protocol). Preset 80 (In industrial protocol) Please note the value may vary due to different protocols. Auto Tour Auto Pattern Auto Scan 8 zones in one-window.
Page 9
2.2.3 Factory Default Setup Function configuration type Item Name Default setup Date format D-M-Y Disable by default Date separator ‘/’ Time format General Setup Language English When HDD is full Overwrite Record duration 60 min Device No. Video type Channel Channel01 Encode mode H.264...
Page 10
Function configuration type Item Name Default setup RS232 com COM01 Function Console Data bit RS232 Stop bit Baud rate 115200 Parity None Ethernet Port 01 DHCP Disable IP address 192.168.1.108 Subnet mask 255.255.0.0 Gateway 192.168.0.1 Device name Device factory default name TCP port 37777 HTTP port...
Page 11
Function configuration type Item Name Default setup Event type Motion detection Channel Ch01, Disable Sensitivity Period: Start time 0:00:00 Time period setup End time:23:59:59 Period 1:enable Week: Sunday Anti-dither 5 seconds Detection Alarm out Disable Alarm latch 10 seconds Record channel Disable Record latch 10 seconds...
Page 12
Function configuration type Item Name Default setup Snapshot mode Snapshot-timing Frame rate 1 S/F Snapshot Resolution 720p Advanced Quality Auto reboot 2.00 each day Auto maintain Auto delete old Never files Channel Exposure Mode Auto Day/Night Mode Disable Backlight Compensation Disable Camera config Auto Aperture...
3 Framework 3.1 Dimensions 3.1.1 Wall mount bracket The wall mount bracket dimensions are shown as below. 3.1.2 Corner mount bracket The corner mount bracket is shown as below.
Page 14
3.1.3 Pole mount bracket The pole mount bracket is shown as below.
4 Installation 4.1 Install the speed dome Open the transparent cover and take out the packing material around the speed dome driver. Please remove the protective paster from the driver and take off the camera lens cap. - Install the quick installation port. - Twist Teflon tape around the screw thread of the quick installation port and turn it into the screw thread of the wall mount bracket.
Note : The video port is covered the heat shrink tube of high shrinking ratio. After the video connection, please heat the tube to make sure the video port is damp proof and water proof. 4.2 Install the speed dome in the bracket After you complete the above steps, please pull the integration cable and multiple-function composite cable to the wall mount bracket.
4.3 Wall mount bracket installation Wall mount bracket is shown as below. Installation requirements The wall mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments. Before the installation, please make sure: - The wall is thick enough to install the expansion bolt. - The wall can at least sustain the 4x weight of the speed dome.
Page 18
4.4 Corner mount bracket installation Corner mount bracket and its components are shown as below. Installation requirements The corner mount speed dome can be installed in the hard construction wall in the indoor or outdoor environments where there is a 90 degrees angle. Before the installation, make sure: - The wall is thick enough to install the expansion bolt.
Page 19
- Pull the cable out of the pole accessories and then use clamp to fix the pole accessories to the pole. - Finally, use glass cement to the output hole to secure waterproof. - After you installed bracket and external cover, loosen the captive screws and open the panel, pull the power cable through the hanging bracket and then fix the hanging bracket to the wall.
5 Menu 5.1 Screen Menu Index Note: ERR means current setup is invalid..means there is submenu. INITIAL INFORMATION... ADDR INFORMATION... SYSTEM TIME SETTING... SET NORTH SYSTEM INFORMATION LANGUAGE: ENGLISH FACTORY DEFAULT RESTART BACK EXIT PRESET TITLE: ON (ON/OFF) AZIMUTH DISP: ON (ON/OFF) TIME DISP: OFF (ON/OFF)
The above diagram illustrates the overall structure of the speed dome setup menu. Note: - ERR means current setup is invalid. - Please make sure all the cable connections are right. 5.2 Self-diagnosis system information ADDR: 001-H BAUD RATE: 9600 PARITY: NONE PROTOCOL:...
5.4 Menu operation In the speed dome main menu, use the left/right button on the web interface to configure the system menu. Before setup, move the cursor to the current item you want to configure. - In main menu, click confirm button to go to the sub menu or use left/right key to configure setup. - Use up/down button to select back option and then click confirm button to go back to the previous menu.
Page 23
Address Information ADDR TYPE: HARD ADDR-HARD: ADDR-SOFT: BACK EXIT -Move the cursor to SITE INFORMATION and then click confirm button. - ADDR TYPE: There are two options: soft and hard. Use the left/right button on the keyboard or in the speed dome terminal menu to set.
Page 24
- ZOOM DISP: Display speed dome zoom speed or not. Use the left/right button on the keyboard or in the speed dome terminal menu to set. - INSIDE TEMPERATURE: Display dome internal temperature or not. There are three options: °C/F/Off. Use the left/right button on the keyboard or in the speed dome terminal menu to set.
Page 25
Exposure Setting AE MODE: AUTO GAIN SETTING: AGC GAIN LIMIT: SHUTTER: 1/50 SLOW SHUTTER LIMIT: 1/25 SETTING: NOISE REDUCTION: EXPOSURE COMP: BLC : SLOW AE: WDR SETTING: SLOW SHUTTER: BACK NEXT PAGE EXIT BACK EXIT - AE MODE: Set the camera exposure mode. It includes: auto/manual/AV (iris priority)/TV (shutter priority).
Page 26
- APERTURE RESTRAIN: It can automatically control the aperture in the low illumination environments. It can reduce the noise. - DIGITAL ZOOM: You can use the left/right button to enable/disable the digital zoom function. - PICTURE FLIP: This function allows you to turn the image rotation 180 degrees. There are two options: on/off.
Page 27
Preset Setup PRESET NO: TITLE: PRESET001 SETTING CALL BACK Move the cursor to PRESET button and then click confirm button to go to set interface. - PRESET NO: Use left/right key to modify preset number. The different protocols support different preset values. The PELCOD and PELCOP support 1 to 255.
Page 28
Scan SCAN NO: SET LEFT LIMIT SET RIGHT LIMIT SCAN SPEED: STOP BACK EXIT Move the cursor to SCAN button and then click confirm button. - SCAN NO: Set auto scan number. Use the left/right button on the keyboard or in the speed dome terminal menu to set. - SET LEFT LIMIT: Set camera left address.
Page 29
Click confirm button you can exit the setup. After move the cursor to back button to go to the previous interface. - DELETE CRUISE: Delete a cruise. Input cruise number in CRUISE NO and then move the cursor to DELETE cruise, click confirm button to delete.
Page 30
Idle Motion IDLE FUNC: IDLE TIME: 010MIN IDLE ACTION: NONE PARAMETER: SAVE BACK EXIT When there is no available command for specified time, dome automatically goes on the previous set functions. - IDLE FUNCTION: There are two modes ON/OFF. Use left/right key to set. - IDLE TIME: System idle period.
Page 31
TIME ACTION 1 ALL 00:00:00:00 SC001 2 ALL 00:00:00:00 SC001 3 ALL 00:00:00:00 SC001 4 ALL 00:00:00:00 SC001 5 ALL 00:00:00:00 SC001 6 ALL 00:00:00:00 SC001 7 ALL 00:00:00:00 SC001 Next Page Move the cursor to the NEXT PAGE and then click the confirm button, you can go to the third menu to set the PTZ SPEED, SET ZERO, POWER UP and etc.
Page 32
Privacy Mask Move the cursor to PRIVACY MASK and click confirm button, system goes to privacy mask setup interface. PRIVACY NO: ACTIVATE : RESIZE: DELETE SAVE BACK EXIT Note: For security reasons, please set privacy zone a little bit larger than the privacy object size. Each time, after modifications you need to move the cursor to SAVE button and then click confirm button to get all setup activated.
Page 33
Power Up Move the cursor to the POWER UP item and then click the confirm button to go to the fourth menu. POWER UP: NONE PARAMTER: NONE BACK EXIT - POWER UP: It is to set the PTZ operation when the speed dome boots up. The option includes: NONE/AUTO/SCAN/PRESET/PATTERN/TOUR and etc.
5.5 Dome Abnormal Phenomenon Operation 5.5.1 Restore to Factory Default Setup From main menu-> SYSTEM INFORMATION, move cursor to FACTORY DEFAULT and click confirm button. Dome will reboot and all the setups restore to factory default setup. 5.5.2 PTZ Movement is not smooth From menu to SYSTEM INFORMATION, move cursor to RESTART and click confirm button.
6 Connecting to a device and opening the web application 6.1 IE options configuration for config tool and and IE This device supports web access and management via PC. System pops up warning information to ask you whether install control “webrec.cab” or not. Click “OK” button, system can automatically install the control.
6.1.1 Connection with the Search Tool Refer to chapter “5.2.1 Connecting to the device’s web interface” 6.1.2 Connection with Internet Explorer IP camera factory default setup: : - IP address: 192.168.1.108 - User name: admin - Password: admin Open Internet Explorer and input IP camera address in the address bar. For example, if your camera IP is 192.168.1.108, input http://192.168.1.108 in IE address bar.
7 Quick Configuration Tool 7.1 Introduction Quick configuration tool is used to search for current IP address, modify IP address. It can also be used to perform a software upgrade or to modify settings. This tool only applies to the IP addresses in the same network segment. Before using the Quick Configuration Tool, please check that this software is in updated version.
Page 38
2- Select “Open Device Web” item to go to the web interface: If you can’t connect, ckeck you internet explorer security settings as described in chapter 6.
7.3 Connecting with the configuration tool (to change the IP address or upgrade the device software. To find devices connected to the network, click the “Refresh” button. The tool will search for devices connected to the network and display them in the form of the list % "...
Page 40
(8) “Upgrade” button opens the interface to upgrade the device firmware: Description Select a check box of a device or several devices with same commercial references into this list. Click “Open” button and select the new firmware in the PC directory. Click “Upgrade”...
7.4 Main interface of the tool 7.4.1 Network settings Functions Description DHCP Enable Enables or disables the DHCP function. IPv4/IPv6 Select IPv4 or IPv6 in the com- bo list. The IP addresses can be changed. IP Address IP address of the device. Subnet Mask Subnet mask of the device.
7.4.3 System Upgrade Before using the Camera, please install its updated software version. Functions Description Upgrade File/Open Click here to select the file to be upgraded Current Progress/Upgrade Click here to start the upgra- ding procedure Return Return to the search inter- face Steps to upgrade the intertnal software - Click the “Open”...
