OWNER'S MANUAL
For The UPS/OSCILLATOR
BBG‐1500VA‐UPS‐OSC‐400
For Installation on the Royal Saudi Naval Forces
(RSNF) Schoolhouse and PCG and PGG Class Vessels
Submitted To:
VSE Corporation
6348 Walker Lane
Alexandria, VA. 22310
Submitted By:
BBG Incorporated
1708 South Park Court
Chesapeake, VA 23320
(757) 366-9211 Voice
(757) 366-9170 Fax
bbg@bbginc.com
Date of Submission: 28 September 2017
Approved by: ____________________
Date: ____________________
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Falcon BBG-1500VA-UPS-OSC-400
Summary of Contents for Falcon BBG-1500VA-UPS-OSC-400
- Page 1 OWNER’S MANUAL For The UPS/OSCILLATOR BBG‐1500VA‐UPS‐OSC‐400 For Installation on the Royal Saudi Naval Forces (RSNF) Schoolhouse and PCG and PGG Class Vessels Submitted To: VSE Corporation 6348 Walker Lane Alexandria, VA. 22310 Submitted By: BBG Incorporated 1708 South Park Court Chesapeake, VA 23320 (757) 366-9211 Voice (757) 366-9170 Fax...
- Page 2 BBG-1500VA-UPS-OSC-400 The BBG-1500VA-UPS-OSC-400 is a modified version of the ED-1500RM-1 manufactured by Falcon Electric Incorporated. The rear panel is configured with one type L515R connector as shown below. L515R outlet The standard ED-1500RM-1 Owner’s Operating Manual follows.
-
Page 3: Uninterruptible Power Supply
5106 Azusa Canyon Road Irwindale, CA 91706 Tel. 626-962-7770 Fax. 626 962-7720 he information contained herein is the property of FALCON ® ELECTRIC INC., is proprietary, confidential, and not to be disclosed, disseminated or used except for the purpose provided. -
Page 4: Table Of Contents
Operational Mode Table . Chapter 6, Maintenance & Technical Support Care & Maintenance Battery Life vs. Temperature Battery Replacement Storing the UPS and Batteries . FCC . Technical Support & RMA Procedure . Requesting Technical Information or Support. FALCON Web Support... -
Page 5: Important Safety Instructions (Read First)
CAUTION This UPS utilizes voltage that may be hazardous. Do not attempt to disassemble. This unit contains no user replaceable parts. Refer all servicing to Falcon Electric, Inc. CAUTION This UPS is not intended to be used in conjunction with life support or operating room equipment. -
Page 6: Chapter 1, Ed Series Ups Overview
ED Series represents one of the smallest and most compact units of the FALCON ® UNINTERRUPTIBLE POWER SYSTEM (UPS) product line. In the tradition of all FALCON ® products, it maintains the highest reliability and the most complete on-line, sinewave power protection available. An on- line, sinewave UPS is the only total solution to virtually any power problem. -
Page 7: Block Diagram
If the unit is overloaded, will shutdown completely if the overload is not corrected within 15 seconds. FIGURE 1: FALCON ED SERIES BLOCK DIAGRAM EMERGENCY BYPASS LINE... -
Page 8: Model Selection Guide
MODEL SELECTION GUIDE U N I T N AM E ED 1500R M - 1 ED 2000R M - 1 ED 2400R M - 1 ED 2500R M - 1 N om i nal VA 1500 2000 2400 2500 C ur r ent - I nput C ur r ent - O ut put R M S 8. -
Page 9: Chapter 2, Installation
To file a claim for shipping damage or concealed damage: 1) File with the carrier within 15 days of receipt of the equipment; 2) Send a copy of the damage claim within 15 days to the Falcon ® Service Department. -
Page 10: Chapter 3, Controls, Displays & Functions
UPS is overloaded or has failed. Should this occur, check the load level and correct any overload condition if present. During this condition, UPS load outlets will be powered by filtered utility bypass power. Should the unit not be overloaded, call FALCON ® support for further assistance. -
Page 11: Rear Panel Diagram & Description
TYPICAL UPS REAR PANEL LAYOUT DB-9F CONTACT CLOSURE INTERFACE This connector gives access to the UPS contact closure status interface. Please reference page 8 of this manual for details. Inlet for Input Line Cord is permenently attached to ED1500RM-1, ED2000RM-1, ED2400RM-1 and ED2500RM-1. COOLING FANS (2) Cooling fans draw cool air from the outside of the rear panel and exhaust it out through slots in the UPS front panel. -
Page 12: Chapter 4, Communications Interface
CHAPTER CHAPTER DB-9 COMMUNICATIONS INTERFACE... -
Page 13: Chapter 5, Operation
CHAPTER CHAPTER OPERATION The FALCON ® ED unit is very simple to use. Verify the power cord is plugged into the correct voltage power source. Activate the power switch to the "ON" position. The green AC LED illuminates. The green INV LED illuminates. -
Page 14: Operational Mode Table
To escape this condition, the problem must first be corrected. Then turn the UPS power switch "OFF", then back "ON". It is recommended that you leave the ED unit power switch "ON" at all times and switch your devices "OFF" individually. This will insure that your batteries are always at a maximum charged state. -
Page 15: Chapter 6, Maintenance & Technical Support
C. Spent batteries must be recycled in accordance with all Federal, State and local laws. To locate a recycling center near you, contact the Falcon service department. CAUTION A. -
Page 16: Storing The Ups And Batteries
The following precautions should be observed by a qualified technician when working with batteries. Remove watches, rings, or other metal objects. Use tools with insulated handles. Wear rubber gloves and boots. Do not lay tools or metal parts on top of batteries Storing the UPS and Batteries Should you need to store the UPS for a long period, fully recharge the battery just prior to storage and recharge the battery every 6 months by plugging the... -
Page 17: Technical Support & Rma Procedure
You may request technical information or support by email or telephone. Please send your technical or support questions by email to: SUPPORT@FALCONUPS.COM You may contact a FALCON support engineer directly by calling the FALCON support line between 9:00 am and 4:00 pm PST. 800-842-6970 FALCON Web Support Product data sheets, specification and owner’s guides are available in Adobe...
