Switch Dimensions
Switch Dimensions
Switch
Cisco Nexus
9364E-SG2-Q
Switch and Module Weights and Quantities
Component
Cisco Nexus 9364E-SG2 Chassis (N9364E-SG2-Q)
Fan Module
– Port-side intake (burgundy) (FAN-PI-V4)
Power Supply module
– 3000-W AC/HVPI port-side intake (burgundy) (PSU3KW-HVPI)
Transceiver and Cable Specifications
To see the transceiver specifications and installation information, see
interfaces-modules/transceiver-modules/products-device-support-tables-list.html.
Switch Power Input Requirements
This table lists the typical amount of power that the switch consumes. It also lists the maximum amount of
power that you must provision for the switch and power supply for peak conditions.
Cisco Nexus 9364E-SG2 (N9364E-SG2-Q) NX-OS-Mode Switch Hardware Installation Guide
46
Width Depth
17.3 inches (43.94 cm) 24.70 inches (62.74 cm)
without fan module and
power supply module
26.26 inches (66.70 cm)
with fan module and
power supply module
System Specifications
Height
3.43 inches (8.71 cm)
Weight per Unit
34.18 lb (15.50 kg)
without Fan module and
Power supply module
44.86 lb (20.35kg) with
Fan module and Power
supply module
—
1.16 lb (1.53 kg)
—
3.02 lb (1.37 kg)
https://www.cisco.com/c/en/us/support/
Quantity
1
4
2 (1 for operations
and 1 for
redundancy)
