Installing the Chassis
• M4 screws to fix brackets (16).
• M4 screws to fix a ground lug (2).
Switch Accessory Kit
This table contains the switch accessory kit product identifications (PIDs). The switch accessory kit contains
the rack mount kit and the ground lug kit. The rack mount kit present in the accessory kit contains the screws
and brackets required for installation.
Switch
Cisco Nexus N9364E-SG2-Q
Planning How to Position the Chassis in the Rack
The switch is designed so that you can have coolant air flow through the switch in one direction: port-side
intake airflow. Enter the port side and exhaust out the power supply side (port-side intake airflow).
For port-side intake airflow, the switch must have port-side intake fan and AC power supply modules with
one or more of these colorings:
• Red coloring on fan modules and AC power supplies
Plan the positioning of the switch so that its ports are located close to ports on connected devices or so that
the fan and power supply modules are conveniently located in a maintenance aisle. Order the modules that
move coolant air in the appropriate direction from the cold aisle to the hot aisle.
Note
Attaching Center-Mount Brackets to the Chassis
Attach a right-angled bracket to each side of the chassis. This bracket centers the chassis and secures it in
place on a two-post rack.
All fan and power supply modules in the same switch must operate with the same direction of airflow. The
air intake portion of the switch must be located in a cold aisle.
Cisco Nexus 9364E-SG2 (N9364E-SG2-Q) NX-OS-Mode Switch Hardware Installation Guide
Accessory Kit
8K-2RU-KIT-S
8K-2RU-KIT-L
Switch Accessory Kit
Items in Accessory Kit and Rack
Depth Range
2RU chassis rail kit
2RU chassis rail kit
19
