Installing the Chassis
Installing the Chassis in a Four-Post Rack
Before you install the chassis, be sure that the rack is fully secured to the data center floor.
The table lists the items contained in the rack-mount kit.
Quantity
2
18
2
2
2
1
Note
Rack-Mount the Chassis in a 4-Post Rack
This section describes how to install the Cisco N9364E-SG2-Q with kit 8K-2RU-KIT-S/8K-2RU-KIT-L.
Caution
Slide the chassis onto the bottom-support rails so that the power supply end locks onto the chassis stops at
the end of the rails and so that the front-mount brackets on the chassis come into contact with the front-mount
rails on the rack.
Warning
Warning
This switch does not support port-side exhaust configuration.
If the rack is on wheels, ensure that the brakes are engaged or that the rack is otherwise stabilized.
Statement 1074 Comply with Local and National Electrical Codes
To reduce risk of electric shock or fire, installation of the equipment must comply with local and national
electrical codes.
Statement 1032 Lifting the Chassis
To prevent personal injury or damage to the chassis, never attempt to lift or tilt the chassis using the handles
on modules (such as power supplies, fans, or cards); these types of handles are not designed to support the
weight of the unit.
Cisco Nexus 9364E-SG2 (N9364E-SG2-Q) NX-OS-Mode Switch Hardware Installation Guide
Installing the Chassis in a Four-Post Rack
Part Description
Rack-mount brackets
M4 x 6 mm Phillips flat-head screws
M4 x 6 mm Phillips pan-head screws
Rack-mount guides
Rack-mount guide rails, 2 lengths for different 4-post depths
Grounding lug and screws
