LEDs
• Switch Chassis LEDs, on page 51
• Chassis LEDs, on page 52
• Uplink Module LEDs, on page 53
• Fan Module LEDs, on page 53
• Power Supply LEDs, on page 54
Switch Chassis LEDs
The BCN, STS, and ENV, LEDs are located on the left side of the front of the switch. The port LEDs appear
as triangles pointing up or down to the nearest port.
LED
BCN
STS
(port)
(GPS)
Color Status
Flashing blue The operator has activated this LED to identify this switch in the chassis.
Off This switch is not being identified.
Green The switch is operational.
Flashing amber The switch is booting up.
Amber Temperature exceeds the minor alarm threshold.
Red Temperature exceeds the major alarm threshold.
Off The switch is not receiving power.
Green Port admin state is 'Enabled', SFP is present and the interface is connected (that is, cabled,
and the link is up).
Amber Port admin state is 'Disabled, or the SFP is absent, or both.
Off Port admin state is 'Enabled' and SFP is present, but interface is not connected.
GPS interface provisioned and ports are turned on. ToD, 1PPS, 10MHz are all valid.
Green
Off Either the interface is not provisioned, or the ports are not turned on. ToD, 1PPS, 10MHz
are not valid.
