- Page 1 TV UNIT 4 DOORS ASSEMBLY INSTRUCTIONS AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
-
Page 2: Assembly Requirements
Please do not drag and pull your furniture. ASSEMBLY REQUIREMENTS Equipment: phillips head screwdriver, flat head screwdriver 2 x adults required 2m x 2m assembly space required 1.5 hour assembly time approx. 2 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234... - Page 3 NEVER allow children to stand, climb or hang on drawers, doors, or shelves. ALWAYS secure your television with an anchor device or mount the television on a wall. 3 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 4 Quickfit head should be in the centre of the cam lock when the two panels are joined. Turn cam lock clockwise to tighten. Cam lock should be inserted before quickfit. 4 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
-
Page 5: Hardware List
2 x P Shelf Pin Leg Support Hinge Scerw 4 x Q 1 x R 2 x S 2 x T Magnet Allen Key Screw Wall Bracket 5 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234... -
Page 6: Parts List
2 PCS 1 PC 1 PC 2 PCS 2 PCS 4 PCS 4 PCS 2 PCS 2 PCS 4 PCS 2 PCS 2 PCS 1 PC 6 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234... - Page 7 Fix wall brackets (T) to part 1 using screws (P). Fix magnets (Q) to part 1 using screws (E), as shown. E x 8 P x 2 Q x 4 T x 2 7 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 8 ASSEMBLY INSTRUCTIONS STEP 2 Fix quickfit screws (A) to part 2. A x 14 8 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 9 Insert cam locks (B) to parts 3, 4, 5 and 6. Attach parts 3, 4, 5 and 6 to part 1, as shown. C x 10 Turn cam locks clockwise to tighten. 9 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 10 ASSEMBLY INSTRUCTIONS STEP 4 Insert parts 7 and 8 into grooves between parts 1, 3, 4, 5 and 6, as shown. 10 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 11 STEP 5 Fix part 16 to part 2 using screws (G). G x 2 Fix leg (N) to part 16 turning clockwise, as shown. N x 1 11 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 12 ASSEMBLY INSTRUCTIONS STEP 6 Insert wooden dowels (C) to parts 3, 4, 5 and 6, as shown. C x 10 12 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 13 ASSEMBLY INSTRUCTIONS STEP 7 Fix part 2 to assembled unit using screws (G), as shown. G x 10 13 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 14 Turn cam locks clockwise to tighten. B B B B B B C C C B B B C C C C C C C C C B B B 14 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 15 F F F F F F F F F F F F F F F F F F F F F F F F F F F 15 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 16 K K K J J J J J J J J J K K K L L L J J J K K K K K K 16 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 17 ASSEMBLY INSTRUCTIONS STEP 11 Insert shelf pins (M) to parts 3, 4, 5 and 6. M x 16 Insert parts 11 to assembled unit, as shown. 17 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 18 Fix hinges (O) to parts 9 and 10 using screws (D). D x 24 Fix handles (I) to parts 9 and 10 using screws (D), as shown. I x 4 O x 8 18 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 19 To adjust the gap from the door to the main frame turn the screw clockwise or anti-clockwise as needed. 19 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 20 To adjust the gap from the door to the main frame turn the screw clockwise or anti-clockwise as needed. 20 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 21 ASSEMBLY INSTRUCTIONS STEP 15 To secure parts 7 and 8, fix wedges (H) using screws (E), as shown. E x 16 H x 16 21 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 22 Should you choose not to affix the product to the wall, serious injury may be caused if the product tips over. Please consider the wall mounting & fixing guide when securing your TV unit. WALL 22 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
- Page 23 ASSEMBLY INSTRUCTIONS STEP 17 Maximum recommended weight is 30kgs on top and 5kgs on per shelf. Your TV unit is ready for use. 23 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
-
Page 24: Tips And Tricks
TV & HiFi than the plasterboard. Always check the speakers and satellite dishes, etc. fixing is secure to the retaining wall. 24 of 24 AFTER SALES SUPPORT ASSEMBLY INSTRUCTIONS 1300 777 137 UH11232 UH11233 UH11234...
