Section:
SCREENS
Description:
END MOUNT SCREENS
End Mount Lateral Floor Screen Glass (UNLTG), End Mount Lateral Floor
B
C
Screen Solid (UNLTS)
A1
D2
Part and Product Identification
A2
A1 - Solid Lateral Floor Screen
with Glass (C07-7280X) x 1
Date:
May 2023
1 of 5
Page No:
DIS_313
Rev. No: 2
A2 - Solid Lateral Floor
Screen (C07-7301X) x 1
B - Screen Bracket
(A16-9303X) x 2
C - Disengagement Screen Bracket
(A16-9304) x 2
D1 -Murakoshi Screw 1/4-20 x 15mm
(E01-0635) x 6
D2 - Modesty Brackets
(A16-3113) x 1
D3 - #10 x 0.875" LG. screw
(E07-0077) x 2
