STC-1005/1205/1505
Smart Touch Computer
User's Manual
Manual Rev.:
Revision Date:
Part No:
0.40
November 18, 2015
50-1Z203-2000
http://www.digchip.com
at this
page

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STC-1005 and is the answer not in the manual?

Questions and answers

Summary of Contents for ADLINK Technology STC-1005

  • Page 1 STC-1005/1205/1505 Smart Touch Computer User’s Manual Manual Rev.: 0.40 Revision Date: November 18, 2015 Part No: 50-1Z203-2000 Advance Technologies; Automate the World. This datasheet has been downloaded from http://www.digchip.com at this page...
  • Page 2: Revision History

    Revision History Revision Release Date Description of Change(s) 0.10 17/07/2015 Preliminary release Update COM1/2 specification; add OS support; 0.20 11/08/2015 panel mount thickness support; power switch description 0.30 05/10/2015 Add FCC statement 0.40 18/11/2015 Update safety information Revision History...
  • Page 3: Preface

    STC-1005/1205/1505 Preface Copyright 2015 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 Conventions Take note of the following conventions used throughout this manual to make sure that users perform certain tasks and instructions properly. Additional information, aids, and tips that help users perform tasks. NOTE: NOTE: Information to prevent minor physical injury, component dam- age, data loss, and/or program corruption when trying to com- plete a task.
  • Page 5 STC-1005/1205/1505 Federal Communication Commission Interference Statement This equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.
  • Page 6 This page intentionally left blank. Preface...
  • Page 7: Table Of Contents

    Pin Definitions..............10 3 Getting Started ..............15 Panel Mounting..............15 SD Card Installation............20 STC-1005 SATA Slim Drive Installation ......21 STC-1205/1505 SATA Slim Drive Installation ....22 STC-1205/1505 2.5” SATA Drive Installation ....23 Connecting Power ............. 24 Important Safety Instructions ..........
  • Page 8 This page intentionally left blank. viii Table of Contents...
  • Page 9: List Of Figures

    Figure 3-4: STC-1505 Panel Mount Cutout Dimensions....19 Figure 3-5: SD Card Installation (STC-1005 shown)......20 Figure 3-6: STC-1005 SATA Slim Drive Installation ......21 Figure 3-7: STC-1205/1505 SATA Slim Drive Installation ....22 Figure 3-8: STC-1205/1505 2.5” SATA Drive Installation ....23...
  • Page 10 This page intentionally left blank. List of Figures...
  • Page 11: List Of Tables

    STC-1005/1205/1505 List of Tables Table 2-1: USB 3.0 Port Pinout............10 Table 2-2: USB 2.0 Port Pinout............10 Table 2-3: HDMI Port Pinout............11 Table 2-4: COM1/2 Port Pinouts............. 11 Table 2-5: RJ-45 GbE Pin Definitions ..........12 Table 2-6: LAN LED Status Definitions...........
  • Page 12 This page intentionally left blank. List of Tables...
  • Page 13: Introduction

    STC-1005/1205/1505 Introduction 1.1 Overview The STC-1005/1205/1505 series of Smart Touch Computers is designed for industrial automation and other applications in harsh environments requiring an IP65 compliant front bezel with pro- jected capacitive multi-touch display. Typical applications include industrial control systems for the food and beverage industries;...
  • Page 14: Package Contents

    1.3 Package Contents Please check that your package contains the items below. If you discover damaged or missing items, please contact your vendor. STC-1005/1205/1505 Smart Touch Computer 19 VDC power adapter (input: 100-240 VAC, 1.5A, 50-60Hz) Panel mount bracket kit...
  • Page 15: Mechanical Dimensions

    STC-1005/1205/1505 1.4 Mechanical Dimensions Dimensions in mm Figure 1-1: STC-1005 Dimensions Introduction...
  • Page 16: Figure 1-2: Stc-1205 Dimensions

    Dimensions in mm Figure 1-2: STC-1205 Dimensions Introduction...
  • Page 17: Figure 1-3: Stc-1505 Dimensions

    STC-1005/1205/1505 Dimensions in mm Figure 1-3: STC-1505 Dimensions Introduction...
  • Page 18 This page intentionally left blank. Introduction...
  • Page 19: System Description

    2x GbE, RJ45 2x RS-232 (TX/RX only) 1x HDMI Port 1x audio port (line out) Webcam: 2.0M pixel 802.11 b/g/n; Bluetooth 4.0 Wireless (STC-1005/1205 internal antenna, Connectivity STC-1505 external antenna) Operating Windows Embedded Standard 7 Pre-Loaded System Windows Embedded 8.1 (optional)
  • Page 20 Environmental & Certifications Operating -20°C to 60°C Temperature Storage -20°C to 60°C Temperature Relative 10% to 90 % @ 40°C (non-condensing) Humidity Vibration 1G random 5 to 500Hz Operating Shock 10G acceleration part to part, 11ms Operating Ingress IP65 rated front panel Rating Certifications CE, FCC, CB (IEC 60950-1)
  • Page 21: I/O Panel Layout

    STC-1005/1205/1505 2.2 I/O Panel Layout System Reset Figure 2-1: STC-1005/1205/1505 Rear I/O Layout System Description...
  • Page 22: Pin Definitions

    2.3 Pin Definitions USB 3.0 Connectors Pin # Signal Name Data- Data+ RX_N RX_P TX_N TX_P Table 2-1: USB 3.0 Port Pinout USB 2.0 Connector Pin # Signal Name Data- Data+ Table 2-2: USB 2.0 Port Pinout System Description...
  • Page 23: Table 2-3: Hdmi Port Pinout

    STC-1005/1205/1505 HDMI Connector Pin # Signal Pin # Signal TMDS Data2+ TMDS Data2 Shield TMDS Data2– TMDS Data1+ TMDS Data1 Shield TMDS Data1– TMDS Data0+ TMDS Data0 Shield TMDS Data0– TMDS Clock+ TMDS Clock Shield TMDS Clock– Reserved DDC/CEC Ground...
  • Page 24: Table 2-5: Rj-45 Gbe Pin Definitions

    RJ-45 Gigabit Ethernet Connectors 10BASE- Pin # 1000BASE-T T/100BASE-TX MDI0+ MDI0- MDI1+ — MDI2+ — MDI2- MDI1- — MDI3+ — MDI3- Table 2-5: RJ-45 GbE Pin Definitions Speed Activity Speed LED Activity LED Status (Green/Orange) (Yellow) Network link is not established or system powered off Link 10 Mbps...
  • Page 25: Table 2-7: Dc Power Input Pinout

    STC-1005/1205/1505 DC Power Input Connector Table 2-7: DC Power Input Pinout System Description...
  • Page 26 This page intentionally left blank. System Description...
  • Page 27: Getting Started

    STC-1005/1205/1505 Getting Started 3.1 Panel Mounting The STC-1005/1205/1505 can be panel mounted using the 8 brackets included with the device. Make sure there is adequate space behind the panel for ventilation, and that the panel material and thickness can support the weight of the device.
  • Page 28: Figure 3-1: Panel Mount Installation

    Panel Mount Bracket M4 Screw M4 Screw Panel Mount Bracket Figure 3-1: Panel Mount Installation Getting Started...
  • Page 29: Figure 3-2: Stc-1005 Panel Mount Cutout Dimensions

    STC-1005/1205/1505 Panel Mount Cutout Dimensions Dimensions in mm Figure 3-2: STC-1005 Panel Mount Cutout Dimensions Getting Started...
  • Page 30: Figure 3-3: Stc-1205 Panel Mount Cutout Dimensions

    Dimensions in mm Figure 3-3: STC-1205 Panel Mount Cutout Dimensions Getting Started...
  • Page 31: Figure 3-4: Stc-1505 Panel Mount Cutout Dimensions

    STC-1005/1205/1505 Dimensions in mm Figure 3-4: STC-1505 Panel Mount Cutout Dimensions Getting Started...
  • Page 32: Sd Card Installation

    To install or remove the SD card, loosen the screw securing the SD card slot cover. Insert or remove the SD card as required. Figure 3-5: SD Card Installation (STC-1005 shown) Replace the slot cover and tighten the scew. Getting Started...
  • Page 33: Stc-1005 Sata Slim Drive Installation

    STC-1005/1205/1505 3.3 STC-1005 SATA Slim Drive Installation To install or replace a SATA Slim drive in the STC-1005, loosen the screws securing the drive bay bracket from the device as shown. Install the drive with the screws provided. Figure 3-6: STC-1005 SATA Slim Drive Installation...
  • Page 34: Stc-1205/1505 Sata Slim Drive Installation

    3.4 STC-1205/1505 SATA Slim Drive Installation To install or replace a SATA Slim drive in the STC-1205/1505, loosen the screws securing the drive bay bracket from the device as shown. Install the drive with the screws provided. Figure 3-7: STC-1205/1505 SATA Slim Drive Installation (STC-1205 shown) Getting Started...
  • Page 35: Stc-1205/1505 2.5" Sata Drive Installation

    STC-1005/1205/1505 3.5 STC-1205/1505 2.5” SATA Drive Installation To install or replace a 2.5” SATA drive in the STC-1205/1505, loosen the screws securing the drive bay bracket from the device as shown. Install the drive with the screws provided. Figure 3-8: STC-1205/1505 2.5” SATA Drive Installation (STC-1205 shown)
  • Page 36: Connecting Power

    3.6 Connecting Power An AC power adapter (19VDC, 65W) is included with the STC-1005/1205/1505. To connect power to the device, insert the pluggable terminal block on the end of the power supply into the DC power inlet as shown below. Secure the terminal block by tightening the two screws as indicated.
  • Page 37 STC-1005/1205/1505 Powering Up the System When DC power is turned on, the system will automatically boot up. The power switch on the IO panel is an ATX switch.To shut down the system, use the Windows shutdown procedure. To boot the system after a soft shutdown, use the ATX switch or discon- nect and reconnect DC power.
  • Page 38 This page intentionally left blank. Getting Started...
  • Page 39: Important Safety Instructions

    STC-1005/1205/1505 Important Safety Instructions For user safety, please read and follow all instructions, WARNINGS, CAUTIONS, and NOTES marked in this manual and on the associated equipment before handling/operating the equipment. Read these safety instructions carefully. Keep this user’s manual for future reference.
  • Page 40 A Lithium-type battery may be provided for backup power. Risk of explosion if battery is replaced with one of an incorrect type. Dispose of used batteries appropriately. WARNING: Equipment must be serviced by authorized technicians when: The power cord or plug is damaged; Liquid has penetrated the equipment;...
  • Page 41: Consignes De Sécurité Importantes

    STC-1005/1205/1505 Consignes de Sécurité Importantes Pour assurer la sécurité de l'utilisateur, veuillez lire et suivre toutes les directives, ainsi que les AVERTISSEMENTS, MISES EN GARDE et REMARQUES de ce manuel et indiqués sur l'équipement associé avant de manipuler ou utiliser l'équipement.
  • Page 42 N'essayez jamais de réparer l'équipement. L'équipement ne doit être réparé que par du personnel qualifié. Une pile au lithium peut être installée pour assurer l'alimen- tation de secours ou d'urgence en continu. ATTENTION! Risque d'explosion si la pile est remplacée par une autre de type incorrect.
  • Page 43: Getting Service

    San Jose, CA 95138, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-360-0222 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. Address: (201203) 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com...
  • Page 44 84 Genting Lane #07-02A, Cityneon Design Centre Singapore 349584 Tel: +65-6844-2261 Fax: +65-6844-2263 Email: singapore@adlinktech.com ADLINK Technology Singapore Pte. Ltd. (Indian Liaison Office) Address: #50-56, First Floor, Spearhead Towers Margosa Main Road (between 16th/17th Cross) Malleswaram, Bangalore - 560 055, India Tel: +91-80-65605817, +91-80-42246107 Fax:...
