STC2-AL/KL Series
Smart Touch Computer
User's Manual
Manual Rev.:
Revision Date:
Part No:
1.0
February 2, 2023
50M-00114-1000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the STC2-AL Series and is the answer not in the manual?

Questions and answers

Related Manuals for ADLINK Technology STC2-AL Series

Summary of Contents for ADLINK Technology STC2-AL Series

  • Page 1 STC2-AL/KL Series Smart Touch Computer User’s Manual Manual Rev.: Revision Date: February 2, 2023 Part No: 50M-00114-1000...
  • Page 2 Revision History Revision Release Date Description of Change(s) 2023-02-02 Initial release...
  • Page 3 STC2-AL/KL Series Preface Copyright © 2023 ADLINK Technology Inc. This document contains proprietary information protected by copy- right. All rights are reserved. No part of this manual may be repro- duced by any mechanical, electronic, or other means in any form without prior written permission of the manufacturer.
  • Page 4 California Proposition 65 Warning WARNING: This product can expose you to chemicals including acrylamide, arsenic, benzene, cadmium, Tris(1,3-dichloro-2-propyl) phosphate (TDCPP), 1,4- Dioxane, formaldehyde, lead, DEHP, styrene, DINP, BBP, PVC, and vinyl materials, which are known to the State of California to cause cancer, and acrylamide, benzene, cadmium, lead, mercury, phthalates, toluene, DEHP, DIDP, DnHP, DBP, BBP, PVC, and vinyl materials, which are known to the State of California to cause...

  • Page 5: Table Of Contents

    STC2-AL/KL Series Table of Contents Preface ..................iii List of Tables................. vii List of Figures ................ ix 1 Introduction ................ 1 Overview................1 Features................1 Packing List ................. 2 Optional Accessories ............2 2 Specifications ..............3 STC2-AL/KL Series Specifications ........3 Power...................
  • Page 6 BIOS Setup Menu.............. 59 Menu Structure ..............61 Main Menu ................. 63 Advanced Menu ..............65 Chipset................87 Security ................94 Boot ................... 95 Save & Exit ................ 98 6 Driver & Application Installation ........99 Driver Installation Order ............. 99 Chipset Driver Installation ..........

  • Page 7: List Of Tables

    STC2-AL/KL Series List of Tables Table 2-1: STC2-AL Series Specifications........3 Table 2-2: STC2-KL Series Specifications........5 Table 2-3: Power Consumption ............7 Table 3-1: External I/O Legend............15 Table 3-2: DC In Pin Definition ............16 Table 3-3: COM1 Port Pin Definition..........17 Table 3-4: COM2 Port Pin Definition..........
  • Page 8 This page intentionally left blank. viii List of Tables...

  • Page 9: List Of Figures

    STC2-AL/KL Series List of Figures Figure 2-1: STC2-10WP-AL/KL Dimensions........8 Figure 2-2: STC2-15WP-AL/KL Dimensions........9 Figure 2-3: STC2-21WP-KL Dimensions ......... 10 Figure 2-4: STC2-10/15WP-AL/KL VESA mounting ......12 Figure 2-5: STC2-21WP-KL VESA mounting........13 Figure 3-1: STC2-AL/KL Series External I/O (10WP/15WP) ... 15 Figure 3-2: STC2-AL/KL Series External I/O (21WP-KL)....
  • Page 10 This page intentionally left blank. List of Figures...

  • Page 11: Introduction

    STC2-AL/KL Series Introduction 1.1 Overview The STC2-AL/KL Series of Smart Touch Computers designed for industrial automation and other applications in harsh environments requiring an IP65-compliant front bezel with projected capacitive multi-touch display. Typical applications include industrial control systems for the food and beverage industries, automated build- ings, transportation, hospitals, factories, and leisure facilities.

  • Page 12: Packing List

    1.3 Packing List Before unpacking, check the shipping carton for any damage. If the shipping carton and/or contents are damaged, inform your dealer immediately. Retain the shipping carton and packing mate- rials for inspection. Obtain authorization from your dealer before returning any product to ADLINK.

  • Page 13: Specifications

    1x USB 3.0, Type-A Expansion 1x Mini PCIe card with PCIe and USB interface IEEE 802.11 a/b/g/n/ac and Bluetooth 4.0 (optional Wi-Fi and Bluetooth with Mini PCIe card) 4G/LTE For USA/Europe/TW/NZ/AU regions (optional) Video 1x DP Port Table 2-1: STC2-AL Series Specifications...
  • Page 14 Windows® 10 IoT Enterprise Weight 1.9 kg 3.16 kg Dimensions 256x174x44 390x239x47 (HxW xD) (mm) Packing Dimensions 355x145x288 505x155x368 (HxWxD) (mm) Gross Weight 2.5 kg 4.2 kg VESA Mount, MIS-D 75mm x 75mm, 100mm x Mounting 100mm Table 2-1: STC2-AL Series Specifications...

  • Page 15: Table 2-2: Stc2-Kl Series Specifications

    STC2-AL/KL Series 2.1.2 STC2-KL Series Specifications Model STC2-10WP-KL STC2-15WP-KL STC2-21WP-KL System Intel® Core™ i3-7100U Processor,2.4GHz,3MB,14W (2C) Processor Intel® Core™ i5-7300U Processor,2.6(3.5)GHz,3MB,15W (2C) Intel® Core™ i7-7600U Processor,2.8(3.9)GHz,4MB,15W (2C) Memory 4GB DDR3L default (up to 8GB) Storage 64GB SSD default (up to 1TB) Display Size 10.1"...
  • Page 16 Model STC2-10WP-KL STC2-15WP-KL STC2-21WP-KL Operating -10°C to 50°C (SSD) Temperature Storage -20°C to 60°C Temperature Humidity 10% to 80% @ 40°C (non-condensing) Vibration Operating: 1G random 5 to 500Hz Shock Operating: 20G/11ms IP Rating Front IP65 Certifications & CE/FCC Compliance 9-36V DC input Power Input OVP/UVP protection...

  • Page 17: Power

    STC2-AL/KL Series 2.2 Power Power supply options: 60W (12V/5A)  84W (12V/7A)  2.2.1 DC Input Options 12V DC (default) or 9-36V DC (optional) input are supported. 2.2.2 Power Consumption Power consumption is based on lab data in which 12V DC is applied and current is measured by the DC power supply.

  • Page 18: Mechanical Dimensions

    2.3 Mechanical Dimensions All dimensions are in millimeters, unless noted. NOTE: NOTE: 2.3.1 STC2-10WP-AL/KL Dimensions Figure 2-1: STC2-10WP-AL/KL Dimensions...

  • Page 19: Figure 2-2: Stc2-15Wp-Al/Kl Dimensions

    STC2-AL/KL Series 2.3.2 STC2-15WP-KL Dimensions Figure 2-2: STC2-15WP-AL/KL Dimensions...

  • Page 20: Figure 2-3: Stc2-21Wp-Kl Dimensions

    2.3.3 STC2-21WP-KL Dimensions Figure 2-3: STC2-21WP-KL Dimensions...

  • Page 21: Mounting

    STC2-AL/KL Series 2.4 Mounting This section includes details for panel and VESA mounting options. Risk of physical injuries and / or property damage: When mounting the device, use the screws to mount the VESA bracket to the rear of the device. Tighten all four screws firmly WARNING: to support the weight of the device.

  • Page 22: Figure 2-4: Stc2-10/15Wp-Al/Kl Vesa Mounting

    2.4.1 VESA Mounting The STC2-AL/KL Series can be VESA mounted from the back panel as shown. All I/O ports must face down. All dimensions are in millimeters, unless noted. NOTE: NOTE: Figure 2-4: STC2-10/15WP-AL/KL VESA mounting...

  • Page 23: Figure 2-5: Stc2-21Wp-Kl Vesa Mounting

    STC2-AL/KL Series Figure 2-5: STC2-21WP-KL VESA mounting...
  • Page 24 This page intentionally left blank.

  • Page 25: System Layout

    STC2-AL/KL Series System Layout 3.1 External I/O Connectors The STC2-AL/KL Series provides the following external I/O con- nectors. Figure 3-1: STC2-AL/KL Series External I/O (10WP/15WP) Figure 3-2: STC2-AL/KL Series External I/O (21WP-KL) 1x DC In 1x Power switch DB-9P COM1 port supports RS-232/422/485 DB-9P COM2 port supports RS-232/422/485 1x USB 3.2 Gen1 (5Gbps) Type-A 1x USB 2.0 Type-A...

  • Page 26: Table 3-2: Dc In Pin Definition

    3.1.1 DC In The DC in port supports 12V DC In with the default configuration. For flexible power options, contact your ADLINK sales representa- tive. Figure 3-3: DC In Pin Definition Signal DC + DC - DC - Table 3-2: DC In Pin Definition...

  • Page 27: Table 3-3: Com1 Port Pin Definition

    STC2-AL/KL Series 3.1.2 COM1 Port Connector The COM1 port is a D-sub 9-pin connector supporting RS-232/ 422/485 modes by BIOS setting. Figure 3-4: COM1 Port Pin Definition Signal RS-232 RS-422 RS-485 COM1_DCD-L_CN DCD# TXD422- 485DATA- COM1_RXD_CN TXD422+ 485DATA+ COM1_TXD_CN RXD422+ COM1_DTR-L_CN DTR# RXD422-...

  • Page 28: Table 3-4: Com2 Port Pin Definition

    3.1.3 COM2 Port Connector The COM2 port is a D-sub 9-pin connector supporting RS-232/ 422/485 modes by BIOS setting. Figure 3-5: COM2 Port Pin Definition Signal RS-232 RS-422 RS-485 COM2_DCD-L_CN DCD# TXD422- 485DATA- COM2_RXD_CN TXD422+ 485DATA+ COM2_TXD_CN RXD422+ COM2_DTR-L_CN DTR# RXD422- COM2_DSR-L_CN DSR#...

  • Page 29: Table 3-5: Usb 3.0 + Usb 2.0 Connector Pin Definition

    STC2-AL/KL Series 3.1.4 USB 3.0 + USB 2.0 Combo Connector USB 3.0 Gen1 (5 Gbps) Type-A + USB 2.0 Type-A connectors are provided compatible with SuperSpeed, Hi-Speed, Full-Speed, and Low-Speed USB devices suitable for USB peripherals. USB 3.2 Gen1 connector up to 5Gbps with 1600 mA power ...

  • Page 30: Table 3-6: Displayport Pin Definition

    3.1.5 DisplayPort Connector One DisplayPort connector, supporting the DP++ standard specifi- cation, can connect to VGA, DVI, HDMI, and DisplayPort with a DisplayPort to VGA adapter cable, DisplayPort to DVI adapter cable, or DisplayPort to HDMI adapter cable, or a DisplayPort cable, with DP1.4 support for resolutions up to 5120 x 3200 at 60Hz.

  • Page 31: Table 3-7: Active/Link And Speed Led Indicators

    STC2-AL/KL Series 3.1.6 Gigabit Ethernet Port Two 2.5 Gigabit Intel® Ethernet Controller i225 Series (V, IT or LM) RJ45 connectors support up to 1000/100/10 Mbit/s connec- tions (STC2-AL) or up to 2.5 Gbit/s (STC2-KL). Other combinations supported on a by-project basis. Con- ...

  • Page 32: Table 3-8: Ethernet Port Pin Definition

    Pin # 10BASE-T/100BASE-TX 1000BASE-T LAN_TX0+ LAN_TX0- LAN_TX1+ — LAN_TX2+ — LAN_TX2- LAN_TX1- — LAN_TX3+ — LAN_TX3- Table 3-8: Ethernet Port Pin Definition...

  • Page 33: Bios Setup (Stc2-Al)

    STC2-AL/KL Series BIOS Setup (STC2-AL) The Basic Input/Output System (BIOS) is a program that provides a basic level of communication between the processor and peripherals. In addition, the BIOS also contains codes for various advanced features applied to the STC2-AL. The BIOS setup program includes menus for configuring settings and enabling features of the STC2-AL.
  • Page 34 Menu Selection Bar The Menu Selection Bar is located at the top of the screen. It displays the top level menus available to the user. Main Menu  Advanced Menu  Chipset Menu  Security Menu  Boot Menu  Save &...

  • Page 35: Menu Structure

    STC2-AL/KL Series 4.2 Menu Structure This section presents the six primary menus of the BIOS Setup Utility. Use the following tables as a quick reference for the contents of the BIOS Setup Utility. The remainder of this chapter describe the sub-menus and options for each menu item. The default settings are presented in bold, and the function of each setting is described in the right hand column of the table.
  • Page 36 Boot Save & Exit - Boot Configuration - Save Changes and Exit - Discard Changes and Exit - UEFI Hard Disk Drive BBS Priorities - Save Changes and Reset - UEFI NVME Drive BBS Priorities - Discard Changes and Reset - UEFI CDROM/DVD Drive BBS Priorities - Save Options - UEFI SD Drive BBS Priorities...

  • Page 37: Main Menu

    STC2-AL/KL Series 4.3 Main Menu This menu provides read-only information about your system and also allows you to set the System Date and Time. Refer to the tables below for details of the submenus and settings. 4.3.1 Main > BIOS Information Feature Options Description...
  • Page 38 4.3.3 Main > Board Information Feature Options Description Board Information Info only Board Information Serial Number Info only Serial Number Manufacturing Date Info only Manufacturing Date Last Repair Date Info only Last Repair Date Runtime Statistics Info only Runtime Statistics Total Runtime Info only Total Runtime...

  • Page 39: Advanced Menu

    STC2-AL/KL Series 4.4 Advanced Menu This menu contains the settings for most of the user interfaces in the system. 4.4.1 Advanced > CPU Configuration Feature Options Description CPU Signature Info only Displays the CPU Signature Microcode Patch Info only Displays the Microcode Patch Max CPU Speed Info only Displays the CPU Speed...
  • Page 40 Feature Options Description C-State Auto Disabled Configure C-State Auto Demotion Demotion C1 and C3 C-State Un-demotion Disabled Configure C-State Un-demotion C1 and C3 Package C-State Disabled Enable or Disable Package C-State Demotion Enabled Demotion. 0: Disable; 1: Enable; <b>2: Auto Auto</b>...
  • Page 41 STC2-AL/KL Series Feature Options Description Auto Data format and Color Data format and Color Depth Depth VESA 24 bpp select JEIDA 24 bpp JEIDA/VESA 18 bpp LVDS Output Mode Auto Single/Dual mode select Dual LVDS bus Single LVDS bus DE Polarity Active High DE Polarity select Active Low...
  • Page 42 4.4.3 Advanced > Power Management Feature Options Description Enable ACPI Auto Disabled Enables/Disables BIOS Configuration Enabled ACPI Auto Configuration. Enable Hibernation Disabled Enables/Disables System Enabled ability to Hibernate (OS/S4 Sleep State). This option may not be effective with some operating systems. ACPI Sleep State Suspend Disabled Select the highest ACPI...
  • Page 43 STC2-AL/KL Series Feature Options Description 0x01 Wake up minute Wake up minute increase in increase hex for Dynamic RTC Wake. Range: 0x00-0x05 in increments of 0x01 (0-5 min, 1 min increments) Disabled Backup Battery Toggles battery function for Function Enabled to run device on battery power if a battery is installed.
  • Page 44 4.4.4 Advanced > Power Management > Power Con- sumption Feature Options Description Power Consumption Info only Current Input Current Info only Current Input Current Current Input Power Info only; Current Input Power CPU-Vcore Info only CPU-Vcore VGFX Info only VGFX V1P05S Info only V1P05S...
  • Page 45 STC2-AL/KL Series 4.4.6 Advanced > System Management > SEMA Fea- tures Feature Options Description SEMA Features Info only SEMA Supported Features Info only SEMA Supported Features Uptime & Power Cycles Counter Info only Uptime & Power Cycles Counter System Restart Event Info only System Restart Event 512 Bytes User-Flash Info only 512 Bytes User-Flash...
  • Page 46 4.4.7 Advanced > System Management > Flags Feature Options Description BMC Flags Info only BMC Flags BIOS Select Info only BIOS Select ATX/AT-Mode Info only ATX/AT-Mode Exception Code Info only Exception Code 4.4.8 Advanced > System Management > SEMA > Tem- perature Feature Options...
  • Page 47 STC2-AL/KL Series Feature Options Description Passive Cooling Trip Point Disabled This value is the temperature 60 C threshold of the Passive Cooling Trip 70 C Point. 80 C 4.4.9 Advanced > Watchdog Timer Feature Options Description Power-Up Watchdog Disabled Enables/Disables the Watchdog Enabled Timer Timeout...
  • Page 48 4.4.11 Advanced > Super IO Configuration > Serial Port 1 Configuration Feature Options Description Serial Port Disabled Enables/Disables Enabled the serial port (COM) Device Settings IO=3F8h; IRQ=4 Change Settings Auto Selects optimal IO=3F8h; IRQ=4 settings for Super IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 IO Device IO=2F8h;...
  • Page 49 STC2-AL/KL Series 4.4.13 Advanced > Super IO Configuration > Serial Port 3 Configuration Feature Options Description Serial Port Disabled Enables/Disables the Enabled serial port (COM) Device Settings Reset Required Change Settings Auto Selects optimal settings IO=3E8h; IRQ=7; for Super IO Device IO=3F8h;...
  • Page 50 4.4.15 Advanced > Serial Console Redirection Feature Options Description COM0 Console Redirection Disabled Enables/Disables console redirection on Enabled COM0 port. Console Redirection Sub-Menu Settings ► COM1 Console Redirection Disabled Enables/Disables console redirection on Enabled COM1 port. Console Redirection Sub-Menu Settings ► 4.4.16 Advanced >...
  • Page 51 STC2-AL/KL Series Feature Options Description Parity None A parity bit can be sent with the data Even bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in Mark the data bits is even. Space Odd: parity bit is 0 if num of 1's in the data bits is odd.
  • Page 52 4.4.17 Advanced > Console Redirection > COM 1 > Con- sole Redirection Settings Feature Options Description Terminal Type VT100 Emulation: VT100Plus ANSI: Extended ASCII character set. VT-UTF8 VT100: ASCII character set. ANSI VT100Plus: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
  • Page 53 STC2-AL/KL Series Feature Options Description None Flow Control Flow control can prevent data loss from Hardware buffer overflow. When sending data, if RTS/CTS the receiving buffers are full, a 'stop' signal can be sent to stop the data flow. Once the buffers are empty, a 'start' signal can be sent to re-start the flow.
  • Page 54 Feature Options Description Parity None A parity bit can be sent with the data Even bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in Mark the data bits is even. Space Odd: parity bit is 0 if num of 1's in the data bits is odd.
  • Page 55 STC2-AL/KL Series 4.4.19 Advanced > Console Redirection > COM 3 > Con- sole Redirection Settings Feature Options Description Terminal Type VT100 Emulation: VT100Plus ANSI: Extended ASCII character set. VT-UTF8 VT100: ASCII character set. ANSI VT100Plus: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
  • Page 56 Feature Options Description VT-UTF8 Combo Key Disabled Enable VT-UTF8 Combination Key Support Enabled Support for ANSI/VT100 terminals Recorder Mode Disabled With this mode enabled only text will be Enabled sent. This is to capture terminal data. Resolution 100x31 Disabled Enables/Disables extended terminal Enabled resolution VT100...
  • Page 57 STC2-AL/KL Series 4.4.21 Advanced > Trusted Computing > TPM 1.2 Configu- ration Feature Options Description Configuration Info only Security Device Disable Enables or Disables BIOS support for Enable Support security device. OS will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 58 Feature Options Description TCM Owner Status: N/A, reset required 4.4.22 Advanced > TPM 2.0 Configuration Feature Options Description Security Device Disable Enables or Disables BIOS support for Enable Support* security device. OS will not show Security Device. TCG EFI protocol and INT1A interface will not be available.
  • Page 59 STC2-AL/KL Series Feature Options Description TPM 2.0 Select the Communication Interface to InterfaceType TPM 20 Device. Device Select* TPM 1.2 TPM 1.2 will restrict support to TPM 1.2 TPM 2.0 devices, TPM 2.0 will restrict support to Auto TPM 2.0 devices, Auto will support both with the default set to TPM 2.0 devices if not found, TPM 1.2 devices will be enumerated...

  • Page 60: Chipset

    4.5 Chipset 4.5.1 Chipset > North Bridge Feature Options Description Memory Information Info only Total Memory Info only Memory Voltage Info only Memory Slot0 Info only 2 GB Max TOLUD Maximum Value of TOLUD. 2.25 GB 2.5 GB 2.75 GB 3 GB Above 4GB MMIO BIOS Enabled...
  • Page 61 STC2-AL/KL Series Feature Options Description DVMT Pre-Allocated Select DVMT 5.0 Pre-Allocated (Fixed) Graphics Memory size used by the 128M Internal Graphics Device 160M 192M 224M 256M 288M 320M 352M 384M 416M 448M 480M 512M DVMT Total Gfx Mem 128M Select DVMT5.0 Total Graphic Memory 256M size used by the Internal Graphics Device...
  • Page 62 4.5.4 Chipset > South Cluster Configuration > HD-Audio Configuration Feature Options Description HD-Audio Configuration Info Only HD-Audio Support Disable Enable/Disable HD-Audio Support Enable 4.5.5 Chipset > South Cluster Configuration > PCI Express Configuration Feature Options Description PCI Express Root Port 1 ► Sub- Menu PCI Express Root Port 5 ►...
  • Page 63 STC2-AL/KL Series Feature Options Description SATA Port 0 (M.2) Info only Software Preserve Info only Port 0 Disabled Enable or Disable SATA Port Enabled Configured as eSATA Info only Hard SATA Device Type Identify the SATA port is connected to Disk Solid State Drive or Hard Disk Drive Drive...

  • Page 64: Security

    4.5.7 Chipset > South Cluster Configuration > SCC Con- figuration Feature Options Description SCC eMMC Support Disable Enable/Disable SCC eMMC Support (D28:F0) Enable eMMC Max Speed HS400 Select the eMMC max Speed allowed. HS200 DDR50 4.5.8 Chipset > South Cluster Configuration > Miscella- neous Configuration Feature Options Description...

  • Page 65: Boot

    STC2-AL/KL Series 4.7 Boot 4.7.1 Boot > Boot Configuration Feature Options Description Setup Prompt Timeout 0x0001 Number of seconds to wait for setup activation key in hex. Range: 0x0001-0xFFFF (0 to 65535 seconds, 1 second increments). 0xFFFF (65535 seconds) means indefinite waiting.
  • Page 66 Feature Options Description Hard Disk Boot Option #1 Hard Disk Sets the system NVME boot order。 NVME Boot Option #2 CD/DVD Boot Option #3 CD/DVD Boot Option #4 USB Hard Disk USB CD/DVD USB Hard Disk Boot Option #5 USB Key Boot Option #6 USB CD/DVD USB Floppy...
  • Page 67 STC2-AL/KL Series Feature Options Description UEFI Hard Disk Drive Sub-Menu BBS Priorities ► UEFI CDROM/DVD Sub-Menu Drive BBS Priorities ► UEFI USB Hard Disk Sub-Menu Drive BBS Priorities ► UEFI USB CDROM/ Sub-Menu DVD Drive BBS Priorities ► UEFI USB Key Drive Sub-Menu BBS Priorities ►...

  • Page 68: Save & Exit

    4.8 Save & Exit Feature Options Description Save Changes and Exit Exits system setup after saving the changes. Discard Changes and Exit Exits system setup without saving any changes. Save Changes and Reset Resets the system after saving the changes. Discard Changes and Reset Yes Resets system setup without saving any changes.

  • Page 69: Bios Setup (Stc2-Kl)

    STC2-AL/KL Series BIOS Setup (STC2-KL) The Basic Input/Output System (BIOS) is a program that provides a basic level of communication between the processor and peripherals. In addition, the BIOS also contains codes for various advanced features applied to the STC2-KL. The BIOS setup program includes menus for configuring settings and enabling features of the STC2-KL.
  • Page 70 Menu Selection Bar The Menu Selection Bar is located at the top of the screen. It displays the top level menus available to the user. Main Menu  Advanced Menu  Chipset Menu  Security Menu  Boot Menu  Save &...

  • Page 71: Menu Structure

    STC2-AL/KL Series 5.2 Menu Structure This section presents the six primary menus of the BIOS Setup Utility. Use the following tables as a quick reference for the contents of the BIOS Setup Utility. The remainder of this chapter describe the sub-menus and options for each menu item. The default settings are presented in bold, and the function of each setting is described in the right hand column of the table.
  • Page 72 Boot Save & Exit - Boot Configuration ► - Save Changes and Exit - Discard Changes and Exit - UEFI Hard Disk Drive BBS Priorities ► - Save Changes and Reset - UEFI NVME Drive BBS Priorities ► - Discard Changes and Reset - UEFI CDROM/DVD Drive BBS Priorities ►...

  • Page 73: Main Menu

    STC2-AL/KL Series 5.3 Main Menu This menu provides read-only information about your system and also allows you to set the System Date and Time. Refer to the tables below for details of the sub-menus and settings. 5.3.1 Main > BIOS Information Feature Options Description...
  • Page 74 5.3.3 Main > Board Information Feature Options Description Board Information Info only Board Information Serial Number Info only Serial Number Manufacturing Date Info only Manufacturing Date Last Repair Date Info only Last Repair Date Runtime Statistics Info only Runtime Statistics Total Runtime Info only Total Runtime...

  • Page 75: Advanced Menu

    STC2-AL/KL Series 5.4 Advanced Menu This menu contains the settings for most of the user interfaces in the system. 5.4.1 Advanced > CPU Configuration Feature Options Description CPU Signature Info only Displays the CPU Signature Microcode Patch Info only Displays the Microcode Patch Max CPU Speed Info only...
  • Page 76 Feature Options Description Turbo Mode Disabled, Enabled Enable/Disable processor Turbo Mode (requires EMTTM enabled too). AUTO means enabled, unless max turbo ratio is bigger than 16 - SKL A0 W/A Enabled, Disabled C states Enable/Disable CPU Power Management. Allows CPU to go to C states when it's not 100% utilized.
  • Page 77 STC2-AL/KL Series 5.4.2 Advanced > Graphics Configuration Feature Options Description LVDS Info Only eDP/LVDS Disabled Enable/Disable eDP/ Enabled LVDS Data format and Color Auto Data format and Color Depth VESA 24 bpp Depth select JEIDA 24 bpp JEIDA/vesa 18 bpp Auto LVDS Output Mode Single/Dual mode select...
  • Page 78 Feature Options Description LFP Panel Type Auto Select LFP panel used by 640x480 Internal Graphics Device 800x600 by selecting the 1024x768 appropriate setup item. 1280x1024 1400x1050 LVDS1 1400x1050 LVDS2 1600x1200 1366x768 1680x1050 1920x1200 1440x900 1600x900 1280x800 1920x1080 2048x1536 5.4.3 Advanced > Power Management Feature Options Description...
  • Page 79 STC2-AL/KL Series Feature Options Description Disabled RTC Wake system from Enable or disable System Fixed Time wake on alarm event. Dynamic Time FixedTime: system will wake on the hr::min::sec specified. Select DynamicTime: system will wake on the current time + Increase minute(s) 0x00 Wake up hour...
  • Page 80 5.4.4 Advanced > Power Management > Power Con- sumption Feature Options Description Power Consumption Info only Current Input Current Info only Current Input Current Current Input Power Info only Current Input Power CPU-Vcore Info only CPU-Vcore VGFX Info only VGFX VCCIO Info only VCCIO...
  • Page 81 STC2-AL/KL Series 5.4.6 Advanced > System Management > SEMA Fea- tures Feature Options Description SEMA Features Info only SEMA Supported Features Info only SEMA Supported Features • Uptime & Power Cycles Info only • Uptime & Power Cycles Counter Counter •...
  • Page 82 5.4.7 Advanced > System Management > Flags Feature Options Description BMC Flags Info only BMC Flags BIOS Select Info only BIOS Select ATX/AT-Mode Info only ATX/AT-Mode Exception Code Info only Exception Code 5.4.8 Advanced > System Management > SEMA > Tem- perature Feature Options...
  • Page 83 STC2-AL/KL Series Feature Options Description Passive Cooling Trip Point Disabled This value is the temperature 60 C threshold of the Passive Cooling Trip 70 C Point. 80 C...
  • Page 84 5.4.9 Advanced > Watchdog Timer Feature Options Description Power-Up Watchdog Disabled Enbles/Disables the Watchdog Timer Enabled 0xFFFF Timeout Time Power Up Watchdog should wait until it resets the system in hex. Range 0x018-0xFFFF (18-65535 minutes, 1 min increments) ATTENTION: Pressing F12 during start up disables the Power Up Watchdog. 5.4.10 Advanced >...
  • Page 85 STC2-AL/KL Series Feature Options Description Storage Do not Controls the execution of UEFI and Legacy Storage launch OpROM UEFI Legacy Video Do not Controls the execution of UEFI and Legacy Video launch OpROM UEFI Legacy Other PCI Do not Determines OpROM execution policy for devices devices launch other than Network, Storage, or Video...
  • Page 86 5.4.12 Advanced > Super IO Configuration > Serial Port 1 Configuration Feature Options Description Serial Port Disabled Enables/Disables the serial Enabled port (COM) Device Settings IO=3F8h; IRQ=4 Change Settings Auto Selects optimal settings for IO=3F8h; IRQ=4 Super IO Device IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2F8h;...
  • Page 87 STC2-AL/KL Series Feature Options Description COM2 Control RS232 Sets COM2 mode as RS- RS422 232, RS-422 or RS-485 RS485 5.4.14 Advanced > Super IO Configuration > Serial Port 3 Configuration Feature Options Description Serial Port Disabled Enables/Disables the serial Enabled port (COM) Device Settings Reset Required...
  • Page 88 Feature Options Description Change Settings Auto Selects optimal settings for IO=3E8h; IRQ=7; Super IO Device IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 IO=220h; IRQ=3,4,5,6,7,9,10,11,12 IO=228h; IRQ=3,4,5,6,7,9,10,11,12...
  • Page 89 STC2-AL/KL Series 5.4.16 Advanced > Serial Console Redirection Feature Options Description COM0 Console Redirection Disabled Enables/Disables console redirection on Enabled COM0 port. Console Redirection Sub-Menu Settings ► COM1 Console Redirection Disabled Enables/Disables console redirection on Enabled COM1 port. Console Redirection Sub-Menu Settings ►...
  • Page 90 Feature Options Description Parity None A parity bit can be sent with the data Even bits to detect some transmission errors. Even: parity bit is 0 if the num of 1's in Mark the data bits is even. Space Odd: parity bit is 0 if num of 1's in the data bits is odd Mark: Parity bit is always 1.
  • Page 91 STC2-AL/KL Series 5.4.18 Advanced > Console Redirection > COM 1 > Con- sole Redirection Settings Feature Options Description Terminal Type VT100 Emulation: VT100Plus ANSI: Extended ASCII character set. VT-UTF8 VT100: ASCII character set. ANSI VT100Plus: Extends VT100 to support color, function keys, etc. VT-UTF8: Uses UTF8 encoding to map Unicode chars onto 1 or more bytes.
  • Page 92 Feature Options Description VT-UTF8 Combo Key Disabled Enable VT-UTF8 Combination Key Support Enabled Support for ANSI/VT100 terminals Recorder Mode Disabled With this mode enabled only text will be Enabled sent. This is to capture terminal data. Resolution 100x31 Disabled Enables/Disables extended terminal Enabled resolution VT100...
  • Page 93 STC2-AL/KL Series 5.4.20 Advanced > Miscellaneous > Network Stack Config- uration Feature Options Description Network Stack Disabled Enables/Disables UEFI Network Stack Enabled IPv4 PXE Support Disabled Enables/Disables IPv4 PXE boot support. If Enabled disabled, IPv4 PXE boot support will not be available.
  • Page 94 Feature Options Description TCM State Disabled Enable/Disable Security Device. NOTE: Enabled Your Computer will reboot during restart in order to change State of the Device. None Pending operation* Schedule an Operation for the Security TPM Clear Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device.
  • Page 95 STC2-AL/KL Series Feature Options Description Disabled SHA512 PCR Bank Enable or Disable SHA512 PCR Bank Enabled SM3_256 PCR Bank Disabled Enable or Disable SM3_256 PCR Bank Enabled Pending operation None Schedule an Operation for the Security TPM Clear Device. NOTE: Your Computer will reboot during restart in order to change State of Security Device.
  • Page 96 Feature Options Description USB transfer time-out 1 sec The time-out value for Control, Bulk, and 5 sec Interrupt transfers. 10 sec 20 sec Device reset time-out 10 sec USB mass storage device Start Unit 20 sec command time-out. 30 sec 40 sec Device power-up Auto...

  • Page 97: Chipset

    STC2-AL/KL Series 5.5 Chipset This menu contains chipset configuration information. 5.5.1 Chipset > System Agent (SA) Configuration Feature Options Description System Agent (SA) Configuration VT-d Supported Memory Configuration ► Sub-menu Graphics Configuration ► Sub-menu VT-d* Disabled VT-d capability Enabled Above 4GB MMIO BIOS Enabled Enable/Disable above 4GB Disabled...
  • Page 98 Feature Options Description Maximum Memory Auto Maximum Memory Frequency 1067 Frequency 1200 Selections in Mhz. 1333 1400 1600 1800 1867 2000 2133 2200 2400 2600 2667 2800 2933 3000 3100 3200 3467 3733 4000 4133 Max TOLUD Dynamic Maximum Value of 1 GB TOLUD.
  • Page 99 STC2-AL/KL Series 5.5.3 Chipset > System Agent (SA) Configuration > Graphics Configuration Feature Options Description Graphics Info only Graphics Configuration Configuration Disabled Skip Scaning of If Enabled, system will not scan for External Gfx Card Enabled External Gfx Card on PEG and PCH PCIE Ports Primary Display Auto...
  • Page 100 Feature Options Description DVMT Pre- Select DVMT 5.0 Pre-Allocated Allocated (Fixed) Graphics Memory size used by the Internal Graphics Device. 32M/F7 DVMT Total Gfx 256M Select DVMT5.0 Total Graphic 128M Memory size used by the Internal Graphics Device. Gfx Low Power Enabled This option is applicable for SFF only.
  • Page 101 STC2-AL/KL Series Feature Options Description SCS Configuration ► SCS Configuration Menu 5.5.5 Chipset > PCH-IO Configuration > PCI Express Configuration Feature Options Description PCI Express Configuration Info Only PCI Express Root Port 1 ► Sub Menu PCI Express Root Port 6 ► Sub Menu PCI Express Root Port 9 ►...
  • Page 102 Feature Options Description Hot Plug Disabled Designates this port as Enabled Hot Pluggable. Configured as eSATA Hot Plug supported DITO Value 0x0271 DITO value in hex. Range: 0x0000-0x03FF in increments of 1. DM Value 0x0F DM value in hex. Range: 0x0F-0x00 in increments of 1.
  • Page 103 STC2-AL/KL Series Feature Options Description State After G3 S0 State Specify what state to go to when S5 State power is re-applied after a power failure (G3 state). 5.5.8 Chipset > PCH-IO Configuration > HD Audio Con- figuration Feature Options Description HD Audio Subsystem Info Only...

  • Page 104: Security

    5.6 Security Feature Options Description Minimum length Password length for both user and administrator passwords. Maximum length...

  • Page 105: Boot

    STC2-AL/KL Series 5.7 Boot 5.7.1 Boot > Boot Configuration Feature Options Description Setup Prompt Timeout 0x0001 Number of seconds to wait for setup activation key in hex. Range: 0x0001-0xFFFF (0 to 65535 seconds, 1 second increments). 0xFFFF (65535 seconds) means indefinite waiting.
  • Page 106 Feature Options Description Hard Disk Boot Option #1 Hard Disk Sets the system NVME boot order CD/DVD Boot Option #2 CD/DVD Boot Option #3 USB Hard Disk:UEFI: USB Hard Disk Sandisk USB CD/DVD Boot Option #4 Partition 1 USB Key USB Floppy USB CD/DVD Boot Option #5...
  • Page 107 STC2-AL/KL Series Feature Options Description UEFI Hard Disk Drive Sub-Menu BBS Priorities ► UEFI CDROM/DVD Sub-Menu Drive BBS Priorities ► UEFI USB Hard Disk Sub-Menu Drive BBS Priorities ► UEFI USB CDROM/ Sub-Menu DVD Drive BBS Priorities ► UEFI USB Key Drive Sub-Menu BBS Priorities ►...

  • Page 108: Save & Exit

    5.8 Save & Exit Feature Options Description Save Changes and Exit Exits system setup after saving the changes. Discard Changes and Exit Exits system setup without saving any changes. Save Changes and Reset Resets the system after saving the changes. Discard Changes and Reset Yes Resets system setup without saving any changes.

  • Page 109: Driver & Application Installation

    STC2-AL/KL Series Driver & Application Installation After installing the operating system, all related drivers must be installed for the system to function properly. This section describes the drivers needed for Windows operating systems and the proce- dures to install them. For other operating system support, contact ADLINK for further information.

  • Page 110: Chipset Driver Installation

    6.2 Chipset Driver Installation The chipset driver directs the operating system to configure the Intel® chipset components in order to ensure that the following features function properly: SATA Storage Support  USB Support  Identification of Intel® Chipset Components in the Device ...

  • Page 111: Graphics Driver Installation

    STC2-AL/KL Series 6.3 Graphics Driver Installation The STC2-AL/KL is equipped with the Intel® Graphics Media Accelerator Driver package, which supports Windows 10 IoT Enterprise. To install the graphics driver: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the STC2-AL/KL.

  • Page 112: Ethernet Driver Installation

    6.4 Ethernet Driver Installation To install the driver for the Intel I225 Gigabit Ethernet controller: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the STC2-AL/KL. 3. Execute Setup.exe and follow the on-screen instructions to complete the installation.

  • Page 113: Serial I/O Driver Installation

    STC2-AL/KL Series 6.6 Serial I/O Driver Installation To install the driver for the serial I/O controller: 1. Close any running applications. 2. From ADLINK's website, download Windows 10 IoT Enterprise drivers for the STC2-AL/KL. 3. Execute Setup.exe and follow the on-screen instructions to complete the installation.
  • Page 114 This page intentionally left blank.

  • Page 115: Important Safety Instructions

    STC2-AL/KL Series Important Safety Instructions For user safety, please read and follow all instructions, Warnings, Cautions, and Notes marked in this manual and on the associated device before handling/operating the device, to avoid injury or damage. Read these safety instructions carefully. ...
  • Page 116 A Lithium-type battery may be provided for uninterrupted  backup or emergency power. Risk of explosion if battery is replaced with one of an incorrect type; please dispose of used batteries appropriately. CAUTION: The device must be serviced by authorized technicians when: ...

  • Page 117: Consignes De Sécurité Importante

    STC2-AL/KL Series Consignes de Sécurité Importante Pour la sécurité de l'utilisateur, veuillez lire et suivre toutes les instructions, avertissements, mises en garde et notes marqués dans ce manuel et sur l'appareil associé avant de manipuler/d'uti- liser l'appareil, afin d'éviter toute blessure ou tout dommage. Lisez attentivement ces consignes de sécurité...
  • Page 118 Installez/fixez et utilisez l'appareil uniquement sur des  surfaces stables et/ou sur les fixations recommandées. L'ordinateur Smart Touch est alimenté par un adaptateur  ou une source CC. Veuillez vous assurer que l'adapta- teur ou la source CC doit conserver la connexion à la terre s'il est doté...
  • Page 119 STC2-AL/KL Series Il est recommandé d'installer l'appareil uniquement dans une  salle de serveurs ou une salle informatique où l'accès est: Réservé au personnel de service qualifié ou aux utilisa-  teurs familiarisés avec les restrictions appliquées à l'emplacement, aux raisons de ces restrictions et toutes les précautions requises Uniquement autorisé...

  • Page 120: Emc Compliance

    EMC Compliance CE Warning This is a Class B product. In a domestic environment, this product may cause radio interference, in which case the user may be required to take adequate measures. FCC Warning This equipment has been tested and found to comply with the lim- its for a Class B digital device, pursuant to part 15 of the FCC Rules.

  • Page 121: Getting Service

    San Jose, CA 95119-1208, USA Tel: +1-408-360-0200 Toll Free: +1-800-966-5200 (USA only) Fax: +1-408-600-1189 Email: info@adlinktech.com ADLINK Technology (China) Co., Ltd. 300 Fang Chun Rd., Zhangjiang Hi-Tech Park Pudong New Area, Shanghai, 201203 China Tel: +86-21-5132-8988 Fax: +86-21-5132-3588 Email: market@adlinktech.com ADLINK Technology GmbH Hans-Thoma-Straße 11...
