INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
Contact your dealer with questions regarding installation, operation or service.
NOTICE: DO NOT DISCARD THIS MANUAL
TREKKER INSERT PELLET
APPLIANCE
MODEL NUMBERS:
TREKKERI-MBK
TREKKERI-PMH
TREKKERI-TWL
CAUTION
Tested and approved for wood pellets only. Burning of
any other type of fuel voids your warranty.
Installation and service of this appliance should be performed by
qualified personnel. Hearth & Home Technologies recommends
HHT Factory Trained or NFI certified professionals.
1
Owner's Manual
Operation & Care
R
7082-154N
WARNING
If the information in these instructions is
not followed exactly, a fire could result
causing property damage, personal injury,
or death.
•
Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
•
Do not over fire - If appliance or chimney connector
glows, you are over firing. Over firing will void
your warranty.
•
Comply with all minimum clearances to combustibles
as specified.
Failure to comply may cause house fire.
WARNING
HOT SURFACES!
Glass and other surfaces are hot during
operation AND cool down. Hot glass will
cause burns.
•
Do not touch glass until it is cooled
•
NEVER allow children to touch glass
•
Keep children away
•
CAREFULLY SUPERVISE children in same room
as fireplace.
•
Alert children and adults to hazards of
high temperatures
•
High temperatures may ignite clothing or other
flammable materials.
•
Keep clothing, furniture, draperies and other
flammable materials away.
CAUTION
Check building codes prior to installation.
•
Installation MUST comply with local, regional, state
and national codes and regulations.
•
Consult local building, fire officials or authorities
having jurisdiction about restrictions, installation
inspection, and permits.
NOTE: To obtain a French translation of this
manual, please contact your dealer or visit
www.quadrafire.com
REMARQUE : Pour obtenir une traduction française de
ce manuel, s'il vous plaît contacter votre
revendeur ou visitez
This unit has been retired.
Service parts pages within have
been removed.
For replacement parts, please
refer to the individual service parts
list located on the brand website.
www.quadrafire.com
11/21

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TREKKERI-MBK and is the answer not in the manual?

Questions and answers

Related Manuals for Quadra-Fire TREKKERI-MBK

Summary of Contents for Quadra-Fire TREKKERI-MBK

  • Page 1 MODEL NUMBERS: • Do not over fire - If appliance or chimney connector glows, you are over firing. Over firing will void TREKKERI-MBK your warranty. TREKKERI-PMH • Comply with all minimum clearances to combustibles as specified.

  • Page 2: Sample Of Serial Number / Safety Label

    Welcome to the Quadra-Fire Family NOTE: Clearances may only be reduced by means approved by the regulatory authority having jurisdiction A. Sample of Serial Number / Safety Label LOCATION: Behind right cast side panel CAUTION: HOT WHILE IN OPERATION DO NOT TOUCH, KEEP CHILDREN, CLOTHING AND FURNITURE AWAY.

  • Page 3: Table Of Contents

    O. Tuning ........12 P. Frequently Asked Questions....13 Quadra-Fire is a registered trademark of Hearth & Home Technologies. 7082-154N...

  • Page 4: Warranty Policy

    B. Warranty Policy Hearth & Home Technologies LIMITED LIFETIME WARRANTY Hearth & Home Technologies, on behalf of its hearth brands (“HHT”), extends the following warranty for HHT gas, wood, pellet and electric hearth appliances that are purchased from an HHT authorized dealer. WARRANTY COVERAGE: WARRANTY PERIOD: distributor, whichever occurs earlier.

  • Page 5: Warranty Conditions

    WARRANTY CONDITIONS: • This warranty only covers HHT appliances that are purchased through an HHT authorized dealer or distributor. A list of HHT authorized dealers is available on the HHT branded websites. • • This warranty is only valid in the country in which the HHT authorized dealer or distributor that sold the appliance resides. •...

  • Page 6: Quick Start Guide

    8. From the home screen press the outer ring to access the set temperature; rotate clockwise to raise the temperature and counterclockwise to lower the temperature. STANDBY STANDBY NOTE: Refer to the Quadra-Fire Wireless User Interface manual for more information. April 05, 2021 7082-154N 11/21...

  • Page 7: Listing And Code Approvals

    Listing and Code Approvals A. Appliance Safety Certification C. BTU & Efficiency Specifications Model EPA Certification TREKKERI-MBK, TREKKERI-PMH and Number: 98-17 Number: Number: TREKKERI-TWL EPA Certified Emissions: .74 g/hr Laboratory: OMNI Test Laboratories, Inc. Report *LHV Tested Efficiency: 83.2% 061-S-84-2 Number:.

  • Page 8: Glass Specifications

    D. Glass Specifications WARNING This appliance is equipped with 5mm ceramic glass. Replace glass only with 5mm ceramic glass. Please contact your dealer for replacement glass. Fire Risk. Hearth & Home Technologies disclaims any E. Electrical Rating responsibility for, and the warranty will be 115 VAC, 60 Hz, Start 2.9 Amps, Run 2.45 Amps voided by, the following actions: •...

  • Page 9: Operating Instructions

    Operating Instructions C. Combustible Materials WARNING Material made of/or surfaced with any of the following materials: Compressed Paper Wood Plywood/OSB Fire Risk. Sheet Rock (drywall) • Do not operate appliance before reading Plastic and understanding operating instructions. Plant Fibers • Failure to operate appliance properly may Any material that can ignite and burn: flame proofed or cause a house fire.

  • Page 10: Before Your First Fire

    G. User Interface Size • Pellets are either 1/4 inch or 5/16 inch (6-8mm) The appliance comes with a user interface and Bluetooth in diameter key, both need to connected for the appliance to operate. • Length should be no more that 1-1/2 inches (38mm) Reference user interface manual supplied for installation •...

  • Page 11: Firepot Purge

    I. Firepot Purge L. Your Pellet Appliance’s General Operating Purpose: To help remove debris from the firepot and help Parts the unit burn as efficient as possible. The frequency of the purge cycle is once every 30 minutes while the unit is burning. During the firepot purge, the feed is reduced to the lowest setting and the exhaust blower ramps up to a very high setting.

  • Page 12: Clear Space

    N. Clear Space NOTICE: Clearances may only be reduced by means ap proved by the regulatory authority having jurisdiction. Mantel: Avoid placing candles and other heat-sensitive ob jects on mantel or hearth. Heat may damage these objects. WARNING Fire Risk Do NOT operate appliance: •...

  • Page 13: Frequently Asked Questions

    P. Frequently Asked Questions What causes my glass to become dirty? If the glass has white ash build up it is normal and the glass should be cleaned. If it is a black soot build up airflow through the unit may be restricted. The most often cause is overdue maintenance and cleaning. See Maintaining and Servicing on page 14 and/or make adjustments to the trim control.

  • Page 14: Maintenance And Service

    Maintenance and Service When properly maintained, your appliance will give CAUTION you many years of trouble-free service. Contact your dealer to answer questions regarding proper operation, Shock and Smoke Hazard troubleshooting and service for your appliance. Visit • Smoke spillage into room can occur if www.quadrafire.com/owner-resources to view basic appliance is not cool before unplugging.

  • Page 15: General Maintenance And Cleaning

    C. General Maintenance and Cleaning 2. Cleaning Ash Pan • Frequency: Weekly or every 3-5 bags 1. Cleaning Firepot using Lever • By: Homeowner • Frequency: Daily or as needed* a. Locate the ash pan underneath the firepot. • By: Homeowner b.
  • Page 16 5. Cleaning Heat Exchanger & Drop Tube • Frequency: Monthly or every ton of fuel (50 bags). • By: Homeowner NOTE: Heavy duty vacuum cleaners may be obtained, specifically designed for solid fuel appliance cleaning. Tools Needed: A Shop Vacuum and generic micro cleaning kit;...
  • Page 17 8. Cleaning the Glass 6. Ash Removal System Inspection & Cleaning • Frequency: See chart on page 14 • Frequency: Monthly or after burning 50 bags • By: Homeowner • By: Homeowner a. Be sure the appliance is allowed to cool. a.

  • Page 18: Soot Or Creosote Fire Awareness

    10. Cleaning Exhaust System 13. Soot and Fly-ash: Formation & Need for Removal in (Requires No Lubrication) Exhaust Venting System. • Frequency: See chart on page 14 • Frequency: See chart on page 14 • By: Homeowner • By: Qualified Service Technician and/or Homeowner a.

  • Page 19: High Ash Fuel Content Maintenance

    E. High Ash Fuel Content Maintenance • Frequency: Daily • By: Homeowner Baffle If the ash build-up exceeds the half way point in the firepot or if clinkers are adhering to the sides of the firepot, the firepot floor is not being cycled enough. WARNING Risk of Fire and Smoke! •...

  • Page 20: Convection Blower Replacement

    H. Convection Blower Replacement I. Combustion/Exhaust Blower Replacement 1. Follow the proper shut down procedures. 1. Follow the proper shut down procedures. 2. Remove the left side panel by loosening the 2 2. Remove the right side panel by loosening the 2 screws using a Phillips head screw driver or wrench screws using a Phillips head screw driver or wrench (Figure 20.1).

  • Page 21: Troubleshooting Guide

    Troubleshooting Guide A. General Appliance Troubleshooting With proper installation, operation, and maintenance your appliance will provide years of trouble-free service. If you do experience a problem, this troubleshooting guide will assist a qualified service person in the diagnosis of a problem and the corrective action to be taken.
  • Page 22 SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Area where the user interface is placed Check thermostat proximity to doors and windows affects temperature. Appliance starts and User interface located in tight stops frequently Inspect user interface location and make sure it is not spaces effecting the on/off cycling of close to a surface that heats and cools quickly.

  • Page 23: User Interface Display Troubleshooting

    SYMPTOM POSSIBLE CAUSE CORRECTIVE ACTION Clean unit including the firepot, exhaust path, and Dirty appliance or venting venting system Poor fuel quality, high ash content. Purge old fuel and use higher quality / or brand of fuel Large, lazy flame (orange color) with black ash / soot buildup Incorrect air-fuel adjustment Adjust the trim (see trim adjustment section)

  • Page 24: User Interface Alarm Troubleshooting

    C. User Interface Alarm Troubleshooting Following correction of any alarm, the user interface will turn to OFF. Turn user interface back ON and back to desired setting. ALARM POSSIBLE CAUSE CORRECTIVE ACTION Hopper empty Fill the hopper Auger jam Inspect the feed tube for jams Make sure firebox door is shut, vacuum hose is connected to switch and drop tube, wire connectors Vacuum switch not closing...

  • Page 25: Reference Materials

    Reference Materials When describing the location of a component, it is always AS YOU FACE THE FRONT OF THE APPLIANCE. A. Component Functions 1. Exhaust Blower The combustion (exhaust) blower is mounted in the bottom right rear of appliance. The blower is designed to pull the exhaust from the appliance and push it out through the venting system.

  • Page 26: Exhaust Temperature

    12. Exhaust Probe - Exhaust Blower The exhaust probe is a temperature-sensing device attached to the exhaust blower housing via screw and clamp. It provides sympathetic exhaust temperature feedback to the control board. In turn, the control board uses this information to adjust its heat-output systems for best performance.

  • Page 27: Service And Maintenance Log

    B. Service and Maintenance Log Date of Service Performed By Description of Service 7082-154N 11/21...
  • Page 28 7082-154N 11/21...
  • Page 29 7082-154N 11/21...

  • Page 30: Contact Information

    Hearth & Home Technologies 352 Mountain House Road Halifax, PA 17032 Division of HNI INDUSTRIES Please contact your Quadra-Fire dealer with any questions or concerns. For the number of your nearest Quadra-Fire dealer log onto www.quadrafi re.com CAUTION DO NOT DISCARD THIS MANUAL •...
