Summary of Contents for Emerson RMM-X
- Page 1 RMM-X Installation and User Guide for ThermoKing MP4000 Units Item no: 8500-160 (Version 1.3)
-
Page 2: Table Of Contents
INSTALLATION ............................. 9 INSTALLATION DETAILS ............................ 9 INSTALLATION OF THE ANTENNA (ALL UNITS) ....................9 INSTALLATION OF THE RMM-X UNIT ......................11 RMM-X USER INTERFACE ON MP-4000 DISPLAY ..............12 DOCUMENT REVISION RECORD ....................13 © Emerson Climate Technologies Copyright... -
Page 3: General Warning
Always keep the product with minimum safety distance of 20cm or more from human body. • Emerson reserves the right to modify this manual without prior notice. • This manual is part of the product and must always be kept near the device for easy and quick reference. -
Page 4: Product Disposal Wee
Emerson. All software utilized and/or distributed by producer is subject to copyright protection. All rights are reserved. No party may use or copy such software in any manner or format, except to the extent that producer grants them a license to do so. -
Page 5: Fcc Rules
RMM-X Installation and User Guide for Thermo King MP4000 Units The device is not stand-alone and can only work when connected to the controller unit. The product is not available via retail or order by email to average consumer. Operators of the unit should be aware of the regulations and standards in their industry/country for the operation of this unit. -
Page 6: Ratings And Requirements
20 cm (7.8 inches) during normal operation. CE Declaration Hereby, Emerson declares that the radio equipment type GSM, LTE, BLE is in compliance with Directive 2014/53/EU. The full text of the EU declaration of conformity is available, please contact our support ( coldchain.technicalservices@emerson.com... - Page 7 RMM-X Installation and User Guide for Thermo King MP4000 Units Disconnect Device • The installation of this product requires a disconnected reefer. Warning • This product is for intended use only in a restricted access location. Access can only be gained by SERVICE PERSONS or by USERS who have been instructed...
-
Page 8: Required Tools
6. Permanent Marker Vacuum cleaner (to clean e.g. control box from slivers) RMM-X ACCESSORIES (MP4000 UNIT) A complete RMM-X accessory kit includes the RMM-X unit and one of the two antennas showed below: RMM-X unit OTS Antenna (PN: 2625-028) Dull Antenna (PN: 2625-055) -
Page 9: Installation
RMM-X Installation and User Guide for Thermo King MP4000 Units INSTALLATION INSTALLATION DETAILS Range of ambient temperature: 0 – 40°C INSTALLATION OF THE ANTENNA (ALL UNITS) 1. Antenna has to be fitted at the valve cover next to the “V” frame. - Page 10 RMM-X Installation and User Guide for Thermo King MP4000 Units 8. Mark the 33 mm hole before drilling (check available space at the bottom of the controller enclosure – protect cables). Use a step drill to drill the hole. Remove all burrs after drilling 9.
-
Page 11: Installation Of The Rmm-X Unit
Connect the plugs for the antenna by matching the colors Reconnect power and turn on the unit. The LED on the RMM-X will light up when the appropriate signal is detected. See matrix on next page for verification. Check the MP4000 controller display to view device details and communication status. -
Page 12: Rmm-X User Interface On Mp-4000 Display
Thermo King MP4000 Units RMM-X USER INTERFACE ON MP-4000 DISPLAY Turn on the reefer and read or verify functionality of the RMM-X device. On MP4000 Display Main Menu one or more of the following symbols are shown at upper right... -
Page 13: Document Revision Record
RMM-X Installation and User Guide for Thermo King MP4000 Units DOCUMENT REVISION RECORD Rev. Date Author Brief description of change Pages affected 220901 Original Issue 230131 Added section “General Warning”, general update 230310 230314 Added FCC specs and other approvals requirements...
