Ispring RCCP Series Installation Instructions & User Manual page 14

1
Slide the quick-connect tting into the faucet stem, ensure it sits securely on the base, and
then lock it in place by sliding the blue locking C-clip under the collet.
BLUE
2 Insert the
locking C-clip.
Step 3: Installing the Drain Saddle
We recommend watching our video "How to Install
iSpring Drain Saddle (ADS1K) for Reverse Osmosis
(RO) System | DIY Installation" on YouTube for your
reference.
Step 3. a.
Choose an appropriate location on the drainpipe before the P-trap to install the
drain saddle and tubing. Installing the drain saddle before the P-trap is important to avoid
potential microorganism growth.
Step 3. b.
Drill a 1/4" hole in the drainpipe and paste the black sticky pad around the hole.
Step 3. c.
Cut the
in the drainpipe, install the back plate, and tighten the two screws with hex nuts while the
tubing remains in the hole.
Step 3. d. Insert the locking C-clip. Pull the tubing lightly to ensure it is secure.
Step 4: Installing Stages 1, 2, and 3 Filters
Step 4. a.
Ensure that the O-ring is seated inside the groove at the
top of the lter housing. Food-grade silicone grease may help the
O-ring stay in place and seal better.
Step 4. b.
The lter cartridges are covered in shrink wrap. Read the
direction sign on the sticker before removing the wrap.
Step 4. c.
When placing the lter cartridge into its housing, ensure it is centered. The bottom
of the housing should match the dent on the lter.
Step 4. d. Screw the housing with lters attached to the housing caps (the caps are pre-assembled
on the machine head). The cap should also match the dent on the lter cartridge. Then, twist
the housing counterclockwise and use a housing wrench to tighten it up for about 1/4–1/2
turn. Do not overtighten, as this can cause leaks and make it di cult to remove the
housing when replacing lters.
Note: The second stage GAC lter is the only lter that must go in a speci c
direction. Make sure that the end with the rubber washer faces up and attaches
to the housing cap.
14
tubing about 1/2" into the quick-connect tting and secure it with a
BLACK
tubing end to make a 45° angle. Insert the tubing into the 1/4'' hole
O-RING
