- Page 3 United States. We provide various residential faucets and water filtration systems that deliver pure, healthy, and tasty water to you and your family. At iSpring, we strive to develop products to the highest of standards and aim to make excellent drinking water accessible for all households. With affordable pricing, reliable quality, prompt delivery, and top-notch customer service, we hope to assist in bringing you great water for years to come.
-
Page 4: Table Of Contents
Prior to Installation Read this instruction manual carefully prior to installation. Keep this manual readily available for future reference. Table of Contents User Information ......................3 Component Identification ..................... 4 Product Features ......................5 Product Structure and Size .................... 6 Filter Life Indicator ....................... -
Page 5: User Information
User Information Users must adhere to the installation specifications described in this Product Installation and Operation Manual (hereinafter referred to as the "instruction manual"). iSpring is not responsible for any damage, loss, or injury resulting from neglect, improper maintenance, or unauthorized modification of products. -
Page 6: Component Identification
Component Identification Page 4 www.123filter.com | (678) 261-7611 | support@123filter.com... -
Page 7: Product Features
Product Features 1) Product Scope • For residential use ONLY. • Applicable water quality: municipal. 2) Specifications Item Specification Inlet Water Pressure 15 - 60 psi Working Pressure 60 - 100 psi Working Temperature 41–100°F Production Rate Flow Rate of Purified Water Up to 0.4 gal/min. -
Page 8: Product Structure And Size
Installation 1) Preparation Check the packing list to confirm all accessories are included in the package. Contact iSpring customer service if any components are missing. A. Choose a suitable location for the system. Again, it cannot be mounted and must be placed on a flat surface. -
Page 9: Feed Water Adapter Installation
2) Feed Water Adapter Installation A. Slide the nut onto the 3/8'' PE pipe, then insert the pipe into the male fitting on the feed water adapter and tighten the nut using a spanner wrench. B. Turn off the cold-water supply valve and unscrew the kitchen faucet connector pipe. C. -
Page 10: Filter Installation
d. Use caution when drilling on a Porcelain sink, as it could be easily chipped. Set drill speed to slow. Press the bit downward firmly until breaking through the slippery surface. Some users find it easier to secure the bit by drilling through a piece of wood firmly pressed on the surface. -
Page 11: System Installation And Setup
B. Insert the filters with the handles pointed toward the "unlocked" sign. Swirl the handles clockwise and align the arrow with the mark on the side of the slot until they reach the end. The filters should fit snugly into the system's fittings. Swirl the handles counterclockwise until they reach the end and pull them out to remove the filters. - Page 12 Then install the backplate and tighten the two screws with hex nuts while the tubing remains in the hole. Pull the tubing lightly to verify it is securely in place. Note: The YouTube video ''iSpring RO System Drain Saddle ADS1K DIY Installation'' is a good reference.
-
Page 13: Connect Faucet Power Supply And Main Power Supply
6) Connecting the Power Supply Plug the system into the power supply. Ensure your hands are not wet to avoid risk of electric shock. The completed system connection should be as shown below. www.123filter.com | (678) 261-7611 | support@123filter.com Page 11... -
Page 14: Using The System
Using the System 1) Starting for the First Time A. To start the system, first plug it in and turn on the feed water adapter. Then turn on the faucet. Vibrations can be expected as the pump starts. Turn on the faucet and let it run for at least 30 minutes to flush the system. This should be done each time the filters are changed. -
Page 15: Display And Operating Area
D. Reconnect the water supply. E. Rinse the system by running water for at least 30 minutes after installing a new filter(s). F. Reset the filter status. Please refer to the "Filter Service Life Reset" section for instructions. 4) Display and Operating Area/Indicators A. -
Page 16: Machine Function Description
5) Machine Function Description Function Operation Status Indicator First The buzzer sounds when the System System performs self-inspection. system is powered on. All Start-up lights turn on in proper order. The system performs auto-rinsing for 5 While rinsing, the ''working'' minutes, then the user rinses the system light flashes. -
Page 17: Malfunction Inspection
Malfunction Inspection Malfunction Possible Issue Possible solution 1. PE pipe is cracked. 1. Replace the pipe. 2. PE pipe is not inserted properly into 2. Reinsert the pipe about 1/2'' into the the port. port. Leakage in 3. The tubing end tip is not cut well. 3. -
Page 18: Warranty
Warranty This Limited Warranty extends to the original purchaser of the system only. This Warranty covers all Manufacturer- supplied items only that prove to be defective in material, workmanship, or factory preparation. This Warranty covers parts only; all labor is excluded from this Warranty, including, but not limited to, services related to the removal, replacement, installation, adjustment, maintenance, and/or repair of the unit or its components items. -
Page 19: Warranty Registration
Warranty Registration To register your product for its warranty, visit our website at 123filter.com and go to the "Warranty" tab. We provide a 30-day money-back guarantee, a 1-year manufacturer warranty, and lifetime tech support for all our products. However, we do not have the order information from websites other than 123Filter.com (Amazon, Home Depot, etc.), so please be sure to fill in all relevant information upon registration of your system. - Page 20 Atlanta, GA USA iSpringFilter.com For questions, comments, or technical support, contact us at: support@123Filter.com (678) 261-7611 Monday-Friday 8:30 a.m. - 5:30 p.m. EST...
