Installation Preparation
•
We recommend watching our video "iSpring RCCP Series RO System with Booster Pump
DIY Installation | Step by Step" on YouTube for guidance.
•
Choose a suitable location for the system, which must be on a at surface.
•
Must ensure this system is installed on an INDOOR cold-water supply ONLY.
•
Keep this system away from extreme hot/cold weather and direct sunlight.
•
Avoid hitting, dropping, or dragging, as it may cause cracks and leaks.
•
Check the system components list to con rm that all accessories are included in the
package. If any components are missing, contact iSpring customer service.
Required tools:
Additional tools:
• Prepare a multi-speed drill with two bits: 1/4" (for drilling on PVC drainpipe) and 3/4" or
1" hollow diamond (for drilling on the countertop for drinking faucet if needed).
Prepare a 5/8", 9/16" open-end wrench or adjustable wrench and pliers.
•
Quick-Connect Fitting Instruction:
REMOVE
(Optional)
* The quick-connect removal tool can help to disconnect more easily.
The tool should t snugly around the tubing.
10
INSERT
(Optional)
*
PRESS
PULL
Installation
We recommend watching our video
"How to Connect and Disconnect Quick
At Least 1/2" in
LOCK
Connect Fittings | DIY Installation" on
YouTube for your reference.
Cut the tubing end evenly with a utility
knife or scissors. Insert the tubing into
the quick-connect tting for at least 1/2'' .
Twist the tube slightly and apply
pressure to create a seal.
DISCONNECT
