Summary of Contents for Ispring RO800 Series
- Page 2 At iSpring, we strive to develop products to the highest of standards and aim to make excellent drinking water accessible for all households. With affordable pricing, reliable quality, prompt delivery, and top-notch customer service, we hope to assist in bringing you great water for years to come.
-
Page 3: Table Of Contents
Prior to Installation Read this instruction manual carefully prior to installation. Keep this manual readily available for future reference. Table of Contents Important User Information ..................3 Product Introduction Product Structure Diagram .................... 4 Product Feature ......................5 Product Parameter ......................5 Usage Instruction Warning ......................... -
Page 4: Important User Information
Important User Information The user must adhere to the installation specifications described in this Product Installation and Operation Manual (hereinafter referred to as the "instruction manual"). iSpring is not responsible for damage, loss, or injury resulting from neglect, improper maintenance, or unauthorized modification of products. -
Page 5: Product Introduction
Product Introduction ▪ Product Structure Diagram ① PPC Composite filter ② RO Membrane filter Front Back Side View www.123filter.com | (678) 261-7611 | support@123filter.com Page 4... -
Page 6: Product Feature
▪ Product Features • Instant treated water accessibility – no tank, no wait. Up to 0.6 gallons per minute flow rate.* • Up to 95% rejection rate.* • Easy twist off filters without cutting off the water supply. – Filter changed in seconds. •... -
Page 7: Usage Instruction
Usage Instruction ▪ Warning This instruction includes important product safety information. Please read this manual thoroughly prior to installation. Failure to follow the listed precautions may end up with personal injury or property damage, or both. ▪ Packing list Description Quantity Description Quantity... -
Page 8: System Installation
Check and make sure the package is in good condition and everything in packing list is included in the package. Contact iSpring Customer service if there is any missing part. 2. The system must be installed at a location that has access to power plug, with flat surface that is kept away from direct sun light or freezing environment. -
Page 9: Install The Faucet
▪ Install the faucet Drill a hole on the countertop if there is not one available. 1. Choose a suitable location on the sink or countertop and install the faucet on a flat surface as shown in the image below. You will need to drill an 1" hole (no larger than 1 1/2") if your kitchen sink does not have an existing one. -
Page 10: Connect The System With Power Cable And Pe Water Tubing
g. Once breaking through the smooth surface, swirl the drill a little to apply pressure in a circle evenly. Be patient and deliberate. It can take 20 – 40 minutes to drill through one inch. Place the faucet in the hole and refer to the following image. ▪... - Page 11 a. Cut the WHITE 3/8" PE tubing to the appropriate length using a utility knife based on the system position. b. Insert one end of the tubing into the feed water adapter quick fitting. Make sure at least 1/2" of the tubing is inserted.
- Page 12 f. Connect the other end of the 1/4" BLUE tubing to the previously installed smart faucet. The faucet came with a 1/4" quick fitting. Like other quick fitting installation, make sure at least 1/2" of the tubing is inserted into the faucet fitting. The tubing should not be able to pulled out by hand Secure the connection by inserting the enclosed 1/4"...
-
Page 13: Using The System
Using the system ▪ System Startup a. To start the system, plug it in, turn on the feed water adapter, then turn on the faucet. Vibrations can be expected as the pump starts. b. Turn on the faucet and let it run for at least 30 minutes to rinse the system. This should be done each time the PPC filter is replaced. -
Page 14: Routine Maintenance
Reset filter: Filter life indicating lights remain to be white and started to blink in white when the corresponded filter life has less than 10% remaining, then turn red when the filter needs to be replaced ASAP. Filter life indicator must be reset each time the filters is replaced. To replace the filter, 1. -
Page 15: Malfunction Inspection
Malfunction Inspection ▪ Malfunction Possible Issue Possible solution No water output Is the water inlet valve turned on? Turn on the water supply The filter was not installed correctly Correct assemble the filter The system is not connected to the Check the power power Less water... -
Page 16: Warranty
Warranty This Limited Warranty extends to the original purchaser of the system only. This warranty covers all Manufacturer- supplied items only that prove to be defective in material, workmanship, or factory preparation. This warranty covers parts only; all labor is excluded from this warranty, including, but not limited to, services related to the removal, replacement, installation, adjustment, maintenance, and/or repair of the unit or its components items. -
Page 17: Warranty Registration
Warranty Registration To register your product for the warranty, visit our website at 123filter.com and go to the "Warranty" tab. We provide a 30-day money-back guarantee, a 1-year manufacturer warranty, and lifetime tech support for all of our products. However, we do not have the order information from websites other than 123Filter.com (Amazon, Home Depot, etc.), so please be sure to fill in that information upon registration of your system. - Page 19 Atlanta, GA USA iSpringFilter.com For questions, comments, or technical support, contact us at: support@123Filter.com (678) 261-7611 Monday-Friday 8:30 a.m. - 5:30 p.m. EST...
Need help?
Do you have a question about the RO800 Series and is the answer not in the manual?
Questions and answers
Installed 2 new filters on the RO800 (800GPD). The PPC light is remaining red, as is the ON light. The RO light is white. Although the instructions say to turn off water and disconnect the power source, doesn’t state at what point they are to be turned back on.
If the PPC light is red and the ON light is also red after installing new filters on the iSpring RO800 Series (800GPD), follow these steps:
1. Reset the Filter Life Indicator:
- Press and hold the "reset" button for 3 seconds to enter reset mode.
- The PPC filter indicator should start flashing red with one beep.
2. Select the Filter to Reset:
- Short press "select/flush" to choose the RO filter indicator light.
- Select the filter that needs to be reset.
- Repeat the process for any other filter if needed.
This should reset the filter indicator and clear the red light alerts. If the issue persists, check that the filters are properly installed and locked in place.
This answer is automatically generated
