ATLASISABD
STPC Atlas ISA/PCMCIA Mode
Evaluation Kit User Manual
For use with ATLASISABD Board Rev A
Issue 1.3
October 15, 2001
Information provided is believed to be accurate and reliable. However, ST Microelectronics assumes no
responsibility for the consequences of use of such information nor for any infringements of patents or other
rights of third parties which may result from its use. Specifications mentioned in this publication are subject
to change without notice. This publication supersedes and replaces all information previously supplied.
®
STMicroelectronics
1/51
®
Issue 1.3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ATLASISABD and is the answer not in the manual?

Questions and answers

Related Manuals for STMicroelectronics ATLASISABD

Summary of Contents for STMicroelectronics ATLASISABD

  • Page 1 ATLASISABD STPC Atlas ISA/PCMCIA Mode Evaluation Kit User Manual For use with ATLASISABD Board Rev A Issue 1.3 October 15, 2001 Information provided is believed to be accurate and reliable. However, ST Microelectronics assumes no responsibility for the consequences of use of such information nor for any infringements of patents or other rights of third parties which may result from its use.
  • Page 2 2/51 ® Issue 1.3...

  • Page 3: Table Of Contents

    1.1 ATLASISABD AT A GLANCE ........7...
  • Page 4 JTAG Facility 23 3.1 INTRODUCTION ......... . . 23 3.2 JTAG CHAIN DESCRIPTION .
  • Page 5 Technical Support 49 5/51 ® Issue 1.3...
  • Page 6 6/51 ® Issue 1.3...

  • Page 7: Motherboard Functional Specification

    Motherboard Functional Specification 1 Motherboard Functional Specification The ATLASISABD system board is a high-performance personal computer system based on the STPC Atlas microprocessor, running with an external 14.31818 MHz quartz crystal oscillator. 1.1 ATLASISABD at a Glance Each physical area of the board, as illustrated in the board layout block diagram...
  • Page 8 Motherboard Functional Specification • I2C bus. • Speaker, Reset button, ATX Power On/Off button. • Display for BIOS POST code (also helpful for software debug). Dimensions: 20 cm x 28.5 cm x four layer PCB. Mounting: Six mounting holes. 8/51 ®...
  • Page 9 Motherboard Functional Specification Not yet available Figure 1-1. Board Layout Block Diagram 9/51 ® Issue 1.3...
  • Page 10 Motherboard Functional Specification Figure 1-2. Board Functional Schematic Block Diagram 10/51 ® Issue 1.3...

  • Page 11: Unified Memory Architecture

    Motherboard Functional Specification 1.2 Unified Memory Architecture The STPC Atlas makes use of a tightly coupled Unified Memory Architecture (UMA), where the same memory array is used for CPU main memory and graphics frame-buffer. This means a reduction in total system memory for system performances that are equal to that of a comparable frame buffer and system memory based system, and generally much better, due to the higher memory bandwidth allowed by attaching the graphics engine directly to the 64-bit processor host interface running at the speed of the processor bus rather than the...

  • Page 12: Memory Interface

    Motherboard Functional Specification - Two Serial Ports - One Parallel Port - 16 General Purpose I/Os - I²C Interface • Integrated Peripheral Controller - DMA Controller - Interrupt Controller - Timer/Counters • Power Management Unit • Watchdog • JTAG IEEE1149.1 1.5 Memory Interface The STPC Atlas handles the memory data bus directly, controlling from 8 MBytes to 128 MBytes.

  • Page 13: Pci Bus Interface

    Motherboard Functional Specification • Buffered DMA & ISA master cycles to reduce bandwidth utilization of the PCI and Host bus. 1.8 PCI Bus Interface The PCI bus is the main data communication link to the STPC Atlas chip. The STPC Atlas translates appropriate host bus I/O and Memory cycles onto the PCI bus.
  • Page 14 Motherboard Functional Specification RAMDAC and reformats it to the TFT format. The height and width of the flat panel are programmable through configuration registers up to a size of 1024 by 1024. By default, lower resolution images cover only a part of the larger TFT panel. The STPC Atlas allows the user to expand the image vertically and horizontally in text mode by inserting programmable blank pixels.

  • Page 15: Hardware Installation

    Hardware Installation 2 Hardware Installation Installing the system board requires the configuration of switches, the setting of jumpers and the attachment of connectors. See Figure 2-1 for jumper location information. 2.1 Jumpers Jumpers on the system board provide information to your system about installed options and system settings.
  • Page 16 Hardware Installation For the S500 DIP switches, the following symbols are used: Push the button to the top side of the DIP switch (ON marking) to set the related entry to logical “0”. Pull the button to the bottom side of the DIP switch to set the related entry to logical “1”...
  • Page 17 Hardware Installation Not yet available Figure 2-1. Jumper Location Diagram 17/51 ® Issue 1.3...

  • Page 18: Default Jumper Setting

    Hardware Installation 2.2 Default Jumper Setting. Table 2-1. Default Jumper Setting Jumper Purpose Setting J508 HCLK/MCLK synchronisation Jumper OFF - default: synchronisation enabled J500 J501 ISA or PCMCIA choice All three jumpers ON J509 - default: ISA J1500 CMOS RAM clean-up Jumper OFF - default: Normal mode J1502...

  • Page 19: Installation

    DIMM SDRAM socket. Soldered SDRAM The ATLASISABD is normally supplied with four 64 Mb (4 M x 16-bit, 54-pin TSOP(ll)) devices soldered to the board. If required, these could be replaced with four 16 Mb (1 M x 16- bit, 50-pin TSOP(ll)) devices or with four 128 Mb (8 M x 16-bit, 54-pin TSOP(ll)) devices.

  • Page 20: Step 4: Setting Stpc Atlas Cpu Speed (S500 - 4, 5 And 6)

    Hardware Installation 2.3.6 Step 4: Setting STPC Atlas CPU Speed (S500 - 4, 5 and 6) Using the S500 DIP switch, set keys 4, 5 and 6 as given in Table 2-2, according to the expected CPU speed. This is validated on reset or Power up. This speed corresponds to HCLK (CPU) clock.

  • Page 21: Step 5: Setting The Pci Clock Speed (S500 - 2 & 3)

    Hardware Installation 2.3.7 Step 5: Setting the PCI Clock Speed (S500 - 2 & 3) Using the S500 DIP switch, set keys 2 and 3 as given in Table 2-3 Table 2-4, according to the STPC Atlas HCLK (CPU) speed setup and the required PCI clock speed. This is validated on reset or Power up.

  • Page 22: 10Step 7: Unused Dip Switch Keys (S500 - 7 & 8)

    Hardware Installation Table 2-6. J500, J501 & J509 Settings Setting J500, J501 & J509 Jumpers OFF PC-Card Jumpers ON 2.3.10 Step 7: Unused DIP Switch keys (S500 - 7 & 8) Those two switches are connected to free pads. They can be either ON or OFF. 2.3.11 Jumper Setting Summary Table 2-7.

  • Page 23: Jtag Facility

    JTAG Facility 3 JTAG Facility 3.1 Introduction The JTAG (Joint Test Action Group) facility complies with the requirements of IEEE1149.1, a common protocol and boundary-scan architecture developed into an industrial standard. It requires the use of special test circuits at the inputs and outputs (boundary-scan) of selected semi-conductor components, together with logic to control these test circuits.

  • Page 24: Jtag Connector Details

    JTAG Facility EPM7064S VPX3226E STPC JTAG Connector Figure 3-2. JTAG Chain Table 3-1. JTAG Configuration Parameters STPC Atlas EPM7064S VPX3226E 0CC15041 070640DD 133500D9 Boundary Scan Length: 1029 Instruction Register Length: 8 bits 10 bits 3 bits 3.3 JTAG Connector Details Table 3-2.

  • Page 25: Motherboard Resources

    Motherboard Resources 4 Motherboard Resources 4.1 System Address Map This section describes the mapping of the CPU memory and IO address spaces. Also covered in this section are the PCI configuration space mapping 4.2 Memory Address Map. Table 4-1. Memory Address Map Address Range (Dec) Address Range (Hex) Size...
  • Page 26 Motherboard Resources Table 4-2. IO Address Map Address Range (Hex) Size (Hex) Description 0170h-0177h 8 Bytes Secondary IDE Channel 01F0h-01F7h 8 Bytes Primary IDE Channel 0278h-027Bh 4 Bytes Parallel Port 2 02F8h-02FFh 8 Bytes Serial Port 2 0378h-037Fh 8 Bytes Parallel Port 1 03B4h, 03B5h, 03BAh 3 bytes...

  • Page 27: Interrupts And Dma Channels

    Motherboard Resources 4.4 Interrupts and DMA Channels Table 4-3. IRQ Channels System Resource Parity Error Reserved, Interval Timer Reserved, Keyboard Buffer Full Reserved, Cascade Interrupt from Interrupt Controller 2 Serial Port 2 Serial Port 1 User available User available Parallel Port 1 Real Time Clock User available (Video) User available...
  • Page 28 Motherboard Resources 28/51 ® Issue 1.3...

  • Page 29: Motherboard Hardware Specification

    Motherboard Hardware Specification 5 Motherboard Hardware Specification 5.1 Connectors The following table (Table 5-1) contains a full list of the connectors implemented on the board. Refer to the numbered Table given for pin connection details. Table 5-1. Connectors List Identification Table No.

  • Page 30: Connector Pin Connection Definitions

    Motherboard Hardware Specification 5.2 Connector Pin Connection Definitions 5.2.1 ISA Connectors Table 5-2. ISA Connector (P1300 - P1301) Signal Name Signal Name IOCHCK# RSTDRV IRQ9 DRQ2 -12V +12V IOCHRDY SMEMW# SMEMR# SA19 IOW# SA18 IOR# SA17 DACK3# SA16 DREQ3 SA15 DACK1# SA14 DRQ1...
  • Page 31 Motherboard Hardware Specification Table 5-2. ISA Connector (P1300 - P1301) Signal Name Signal Name IOCS16# LA23 IRQ10 LA22 IRQ11 LA21 IRQ12 LA20 IRQ15 LA19 IRQ14 LA18 DACK0# LA17 DRQ0 MEMR# DACK5# MEMW# DRQ5 DACK6# DRQ6 SD10 DACK7# SD11 DRQ7 SD12 SD13 MASTER# SD14...

  • Page 32: Vga Connector

    Motherboard Hardware Specification 5.2.2 VGA Connector Table 5-3. Standard VGA Connector (P2701) Signal Name Green Blue VCC Fuse DDCDAT DDCCLK 5.2.3 Mouse Connector Table 5-4. Mouse Connector (P2511 upper side) Signal Name MData MVCC MClk 32/51 ® Issue 1.3...

  • Page 33: Keyboard Connector

    Motherboard Hardware Specification 5.2.4 Keyboard Connector Table 5-5. Keyboard Connector (P2511 lower side) Signal Name KBData KBVCC KBClk 5.2.5 Parallel Port Connector Table 5-6. Parallel Connector (P2500) Signal Name Signal Name STROBE#1 AFD#1 DP1_0 ERROR#1 DP1_1 INIT#1 DP1_2 SLCT IN#1 DP1_3 DP1_4 DP1_5...

  • Page 34: Cvbs Video Connectors

    Motherboard Hardware Specification 5.2.6 CVBS Video Connectors Table 5-7. CVBS Video Connector (P3100) Signal Name COMPOSITE VIDEO Table 5-8. CVBS Video Connector (J3100) Signal Name COMPOSITE VIDEO 34/51 ® Issue 1.3...

  • Page 35: S-Vhs Video Connector

    Motherboard Hardware Specification 5.2.7 S-VHS Video Connector Table 5-9. S-VHS Video Connector (P3109) Signal Name Y_IN C_IN 5.2.8 Digital Video Input Connector Table 5-10. Digital Video Input Port (P3102) Signal Name VIP_D0 VIP_D1 VIP_D2 Not Connected VIP_D3 Not Connected VIP_D4 Not Connected VIP_D5 VIP_SCL...

  • Page 36: Pci Connectors

    Motherboard Hardware Specification 5.2.9 PCI Connectors Table 5-11. PCI Connectors (P900 - P901) Signal Name Signal Name -12V +12V see next 3 tables see next 3 tables see next 3 tables see next 3 tables Reserved Reserved Reserved Reserved Reserved RESET# PCICLK see next 3 tables...
  • Page 37 Motherboard Hardware Specification Table 5-11. PCI Connectors (P900 - P901) Signal Name Signal Name TRDY# 3.3V DEVSEL# STOP# 3.3V PCILOCK# SDONE PERR# SBO# 3.3V SERR# 3.3V AD15 CBE1# 3.3V AD14 AD13 AD11 AD12 AD10 CBE0# 3.3V 3.3V Table 5-12. PCI Connector (P901) Signal Name Signal Name PCI_INT1#...

  • Page 38: 10Usb Port Connectors

    Motherboard Hardware Specification Table 5-13. PCI Connector (P900) Signal Name Signal Name PCI_INT0# PCI_INT2# PCI_INT1# PCI_INT3# PCI_GNT0# PCI_REQ0# IDSELA (AD30) 5.2.10 USB Port Connectors Table 5-14. Dual USB Connector (P2300) Signal Name Data0- Data0+ Data1- Data1+ VCC Fuse 38/51 ® Issue 1.3...

  • Page 39: 11Com (Serial Port) Connectors

    Motherboard Hardware Specification 5.2.11 COM (Serial Port) Connectors Table 5-15. COM (Serial Port) Connectors (P2506, P2507) Signal Name Pin (SubD P2506) Pin (Header P2507) HDCD# HRxD HTxD HDTR# HDSR# HRTS# HCTS# HRI# 39/51 ® Issue 1.3...

  • Page 40: 12Ide Connectors

    Motherboard Hardware Specification 5.2.12 IDE Connectors Table 5-16. IDE Connectors (P2100, P2101) Signal Name Signal Name RST# HD10 HD11 HD12 HD13 HD14 HD15 DREQ DIOW# DIOR# IOCHRDY DACK# IOCS16# HCS#0 HCS#1 Activity 40/51 ® Issue 1.3...

  • Page 41: 13Atx Power Supply Connector

    Motherboard Hardware Specification 5.2.13 ATX Power Supply Connector Table 5-17. ATX Power Supply Connector (P3300) Signal Name Signal Name +3.3V +3.3V -12V +3.3V ON# / OFF POWER GOOD +5V Supply Backup +12V 41/51 ® Issue 1.3...

  • Page 42: 14Pc-Card Slot

    Motherboard Hardware Specification 5.2.14 PC-Card Slot Table 5-18. PC-Card Slot Connector (P2510) Signal Name Signal Name D[3] CD1# D[4] D[11] D[5] D[12] D[6] D[13] D[7] D[14] CE1# D[15] A[10] CE2# OE#/TCw VS1# A[11] IORD# A[9] IOWR# A[8] A[17] A[13] A[18] A[14] A[19] WE#/TCr...

  • Page 43: 15Tft Screen Output

    Motherboard Hardware Specification 5.2.15 TFT Screen Output Table 5-19. TFT Screen Output Connector (P3800) Signal Name DCLK FPLINE FPFRAME TFTVCC TFTVCC 43/51 ® Issue 1.3...

  • Page 44: 16Tft Backlight Power Connector

    Motherboard Hardware Specification 5.2.16 TFT Backlight Power Connector Table 5-20. TFT Backlight Power Connector (P3801) Signal Name TFT_ENVDD12V TFT_ENVDD5V TFT_PWM TFT_VCC Variable voltage 44/51 ® Issue 1.3...

  • Page 45: 17Jtag Connector

    Motherboard Hardware Specification 5.2.17 JTAG Connector Table 5-21. JTAG Connector (P4000) Signal Name TRST TCLK No Connection 5.2.18 GPIO Connector Table 5-22. GPIO Connector (P3700) Signal Name GPIO_0 GPIO_1 GPIO_13 GPIO_2 GPIO_3 GPIO_14 GPIO_4 GPIO_5 GPIO_15 GPIO_6 GPIO_7 GPIO_8 GPIO_9 GPIO_10 45/51 ®...

  • Page 46: 19I2C Connector

    Motherboard Hardware Specification Table 5-22. GPIO Connector (P3700) Signal Name GPIO_11 GPIO_12 5.2.19 I2C Connector Table 5-23. I2C Connector (P4400) Signal Name 46/51 ® Issue 1.3...

  • Page 47: Electrical Specifications

    Motherboard Hardware Specification 5.3 Electrical Specifications The Power Supply used to power this board must have the following characteristics. Table 5-24. Power Supply Characteristics Voltage Precision +5 V +/- 250 mV +12 V +/- 600 mV -5 V +/-500 mV -12 V +/- 1.2 V +3.3 V...
  • Page 48 Motherboard Hardware Specification 48/51 ® Issue 1.3...

  • Page 49: Technical Support

    A dedicated STPC section is available, providing up to date hardware documentation and software tools. Any updated versions of this ATLASISABD User Manual will be found in this section. Technical questions regarding the ATLASISABD Evaluation Kit or any other STPC related product should be addressed to your nearest ST Microelectronics Sales Office.
  • Page 50 Technical Support 50/51 ® Issue 1.3...
  • Page 51 No license is granted by implication or otherwise under any patent or patent rights of STMicroelectronics. Specifications mentioned in this publication are subject to change without notice.
