PR Lighting XR440 BWS User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

XR440 BWS
PR-2462
The user manual contains important information about the safe installation and use of a projector. Please read
and follow these instructions carefully and keep the manual in a safe place for future reference.
PR LIGHTING LTD.
http://www.pr-lighting.com
1/34

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the XR440 BWS and is the answer not in the manual?

Questions and answers

Related Manuals for PR Lighting XR440 BWS

Summary of Contents for PR Lighting XR440 BWS

  • Page 1 XR440 BWS PR-2462 The user manual contains important information about the safe installation and use of a projector. Please read and follow these instructions carefully and keep the manual in a safe place for future reference. PR LIGHTING LTD. http://www.pr-lighting.com...

  • Page 2: Table Of Contents

    INDEX SAFETY AND WARNINGS INSTUCTIONS CLEANING AND MAINTENANCE ● LUBRICATION ● TROUBLESHOOTING ● 3. APPEARANCE 4. INSTALLATION RIGGING ● POWER CONNECTIONS ● DMX CONTROL CONNECTIONs ● DMX TERMINATOR ● ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● GOBO/COLOR FILTER REPLACEMENT ● 5. SETUP AND CONFIGURATION FRONT PANEL OPERATION ●...

  • Page 3: Safety And Warnings

    1. SAFETY AND WARNINGS NOTE Before a projector’s installation, power-on, operation and maintenance, please carefully read the safety information hereinafter! The following safety signs are used in the user manual. User Electrical Goggles Protective High Warning Flames Manual shock Gloves Temperature When unpacking , check if there is transportation damage before using the projector.

  • Page 4: Cleaning And Maintenance

    There are safety cord holes at the bottom of the base of a projector. In view of safety, please run the safety ● cord supplied through the safety cord holes for safety support. Before any installation, maintenance and cleaning work, please ensure the projector is disconnected from ●...

  • Page 5: Appearance

    3. APPEARANCE The projector’s Structure 1. Front Lens 2. Lens Cover 3. Head Cover 4. Tilt Lock 5. Handle 6. Pan Lock 7. Arm Cover While transportation, the head should be locked-Tilt Lock(4) and Pan Lock(6) should be at locking positions. Before the use of the projector, unlock both.

  • Page 6: Power Connections

    Warning please run the safety cord Clamp through the two holes for safety Safety cord Handle Control menu Take 2 clamps and the safety cord out from the package and mount 2 clamps on the underside of fixture with 2 retainers attached to each clamp.

  • Page 7: Dmx Control Connections

    DMX CONTROL CONNECTION: ● Connection between controller and projector and between one projector and another must be made with a twin-screened cable, with each wire having at least a 0.5mm in diameter. Connection to and from the projector is via cannon 5 pin (which are included with the projector) or 5 pin XLR plugs and sockets.

  • Page 8: Alignment/Installation/Replacement Of A Lamp

    ALIGNMENT/INSTALLATION/REPLACEMENT OF A LAMP ● Lock the yoke before fitting/replacingthe lamp. Just as Shown by Figure 1, after Opening the cover at the rear of the projector by loosening 8 fastfit screws, you can open the head. To adjust the lamp as per Figure 2. Take out the lamp as per the figure 3. Before lamp installation, tighten its power wires well.
  • Page 9 Figure3 ： Removal of lamp 2.Remove the cover after its 4 screws are 1.Loosen a tightening screw at the lamp's side loosened by a cross screwdriver 2. Remove the lamp's two wires and push it obliquely for the removal. 4.Connect the lamp wires after a new lamp is in place, and align and tighten the lamp as per figure2 GOBO REPLACEMENT ●...

  • Page 10: Setup And Configuration

    5. SETUP AND CONFIGURATION Front Panel Operation ● W-DMX Projector configuration can be set conveniently via push button and LCD display. Launch the projector and press button ENTER for more than 2 seconds to unlock the panel, the LCD will show the function menu of the projector, each main menu has its submenus and each submenu has a specific function.

  • Page 11: Master/Slave Mode

    DMX address can be set at any number within 512. MASTER/SLAVE MODE ● Many projectors can run synchronously in the Master/Slave mode by linking them with each other. First, connect the first fixture’s DMX output to the second fixture’s DMX input using XLR-XLR control cable and then connect the second fixture’s DMX output to the third fixture’s DMX input, and so on until all projector are connected in this way.
  • Page 12 Pass Code Color Positions STEPPED Color Positions Color Positions LINEAR F-Gobo Positions STEPPED F-Gobo Positions F-Gobo Positions LINEAR Pan DMX Invert Pan DMX Invert Pan DMX Invert Tilt DMX Invert Tilt DMX Invert Tilt DMX Invert Option Settings Pan Tilt Swap Pan Tilt Swap Pan Tilt Swap Dimmer Invert...
  • Page 13 Lamp Hours Reset Lamp Hours Are You Sure(UP/DOWN) Total Hours Display Board= Display Board XX℃ Driver Board 1= Driver Board 1 XX℃ Driver Board 2= Driver Board 2 XX℃ Temperature Driver Board 3= Driver Board 3 XX℃ Pan and Tilt= Pan and Tilt XX℃...
  • Page 14 Factory Setup Self Test Self Test Self Test Lamp Status S= X C= X Lamp On Lamp Manual Control Turn Lamp On Turn Lamp Off Wireless Mode Wireless Only Wireless Mode Wireless Mode Wireless Options XLR Only Un-Link Wireless Really Un-Link Enter=Yes Operation Mode Operation Mode=...
  • Page 15 Link To Step XXX（1~200） Shutters Shutters XXX Dimmer Dimmer XXX Slow Dimmer Slow Dimmer XXX CYM Macro CYM Macro XXX Cyan Cyan XXX Yellow Yellow XXX Magenta Magenta XXX Color Wheel Color Wheel XXX Fixed G-Wheel Fixed G-Wheel XXX R Gobo-Wheel R Gobo-Whee XXX R Gobo Rotate R Gobo Rotate XXX...

  • Page 16: Dmx Protocol

    R Prism 2 In Out R Prism 2 In out XXX R Prism 2 Rotate RPrism2RotationXXX Frost Frost XXX Focus Focus XXX Zoom Zoom XXX Diffuser Diffuser XXX Pan XXX Pan Fine Pan Fine XXX Tilt Tilt XXX Tilt Fine Tilt Fine XXX Motors’...
  • Page 17 Magenta 111-128 CYM color mixing from slow to fast 129-255 Cyan Cyan (linear 0~100%) 000-255 Cyan in 16 Bit 000-255 Cyan 16 Bit Yellow Yellow (linear 0~100%) 000-255 Yellow in 16 Bit 000-255 Yellow in 16 Bit Magenta 000-255 Magenta (linear 0~100%) Magenta in 16 Bit 000-255 Magenta in 16 Bit...
  • Page 18 204-210 Shake effect 6 from slow to fast 211-217 Shake effect 7 from slow to fast 218-224 Shake effect 8 from slow to fast 225-231 Shake effect 9 from slow to fast 232-237 Shake effect 10 from slow to fast 238-243 Shake effect 11 from slow to fast 244-249...
  • Page 19 129-191 Rotation(Clockwise from slow to fast) Stop 193-255 Rotation(Anti- Clockwise from slow to fast) Frost Filter Linear Frost 000-255 000-255 Focusing Linear Focusing 000-255 Focusing Fine Focusing in 16 bit precision 000-255 Zoom Linear Zooming 000-255 Zooming Fine Linear Zooming in 16 bit precision 000-255 Diffuser Diffuser...
  • Page 20 Compatible mode Function Description 000-255 Pan(0°~540°) Pan Fine 000-255 Pan in 16 bit precision Tilt 000-255 Tilt(0°~270°) Tilt Fine 000-255 Tilt in 16 bit precision Pan & Tilt Speeds 000-255 Pan & Tilt Speed from Fast to Slow Reserved Reserved 10－14 Reserved 15－19...
  • Page 21 91－100 Orange(linear) 101－109 CTO(linear) 110－118 UV filter(linear) 119－127 White(linear) 128－129 White 130－134 Deep Red 135－138 Deep Blue 139－143 Yellow 144－147 Green 148－152 Magenta 153－157 Azure 158－161 162－166 Dark green 167－171 Amber 172－176 Blue 177－180 Orange 181－185 186－189 UV filter 190－215 Forwards rainbow effect from fast to slow 216－218 No rotation...
  • Page 22 88-95 Shake effect1 96-103 Shake effect2 104-111 Shake effect3 112-119 Shake effect4 120-127 Shake effect5 128-135 Shake effect6 136-143 Shake effect7 144-151 Shake effect8 152-159 Shake effect9 160-167 Shake effect10 168-175 Shake effect11 176-183 Shake effect12 184-191 Shake effect13 192-199 Open white shaking 200-201 Open White...
  • Page 23 92-99 Gobo5 shake from slow to fast 100-107 Gobo6 shake from slow to fast 108-115 Gobo7 shake from slow to fast 116-123 Gobo8 shake from slow to fast 124-129 Gobo9 shake from slow to fast 130-137 Gobo1 shake from slow to fast 138-145 Gobo2 shake from slow to fast 146-153...

  • Page 24: Led Indication

    0-255 Focus Continuous adjustment from far to near Focus - fine Focus –fine 0-255 0-31 Close strobe 32-63 Open strobe Strobe-effect from slow to fast 64-95 Shutter open 96-127 Opening pulse in sequences from slow to fast Strobe 128-143 Closing pulse in sequences from fast to slow 144-159 Shutter open 160-191...

  • Page 25: Technical Data

    Error Display Error Display Corrections Sensor Err S1-M4 check the wiring and the motor if it works or not CYM-Cyan (1# drive board motor 4) error Sensor Err S1-M5 check the wiring and the motor if it works or not CYM-Yellow (1# drive board motor 5) error check the wiring and the motor if it works or not Sensor Err S1-M6...
  • Page 26 Color Temperature 7000K Manufacturers Rated Lamp Life 1500hours COLORS 1 color wheel: 13colors(plus 1CTO)+ Open, rainbow effect with bi-directional and variable speeds, Stepping/linear color changin Wave Code No. Colors Length 090071050 Deep Red λ=628±5nm 090071053 Deep Blue λ=503±5nm 090071052 Yellow λ=531±5nm 090071055 Green...
  • Page 27 CMY linear color mixing with macros linear color mixing with macros FIXED GOBO WHEEL 1 fixed gobo wheel: 13 gobos +open, P/N 060020413, Diameterφ120 *0.8mm thick bi-directionally rotatable, and shakable at variable speeds directionally rotatable, and shakable at variable speeds Big Circle Small Circle Small Circle...
  • Page 28 FROST FILTER: 1pc frost filter FOCUSING: DMX linear Focusing ZOOMING: DMX linear Zooming DIMMER/STROBE: 0-100% linearly adjustable/ Double shutter blades, 0.3~25 F.P.S HEAD MOVEMENT: Pan 540º, Tilt 270º with auto position correction BEAM ANGLE: Beam: 2.3°-- 10°, Linear Adjustment Spot 5°-- 22°Linear Adjustment Wash 5°-- 40°Linear Adjustment...
  • Page 29 SIZES: LIGHT OUTPUT: 5100 20300 9060 2200 10° Lux 81500 3300 2.3°Lux 158200 89000 39500 1424000 356060 56900 10° 2.3° Distance (m) 1.25 Min Diameter (m) 0.21 1.04 0.42 0.62 0.83 Max Diameter (m) 5.14 0.86 4.28 1.71 2.57 3.43 29/34...
  • Page 30 3500 1570 22° Lux 14100 5°Lux 26000 14600 6500 234500 58600 9300 2.3° 22° Distance (m) Min D iameter(m) 0.49 2.43 2.91 0.97 1.46 1.94 Max D iameter(m) 11.99 2.00 9.99 4.00 6.00 8.00 40° Lux 2155 5°Lux 3100 1750 7009 28000 1120...

  • Page 31: Circuit Diagram And Pcb Connections

    11. CIRCUIT DIAGRAM AND PCB CONNECTIONS CIRCUIT DIAGRAM ● 31/34...

  • Page 32: Pcb Connections

    PCB CONNECTIONS ● 1.SLAVE1：P/N230060430 Signal Output #5 Turbo Fan2(CYM) Signal Input#4 Turbo Fan1 HALL1-6 Magnet Sensor 24V Power Input HALL1-5 Magnet Sensor M1-1 Motor HALL1-4 Magnet Sensor M1-2 Motor M1-3 Motor M1-4 Motor M1-5 Motor Temperature Sensor #2 M1-6 Motor 2.SLAVE2：P/N230060431 Ballast Fan Signal Input#6...

  • Page 33: Component Order Codes

    12. COMPONENT ORDER CODES NAME PART NO. QUANTITY REMARK PAN MOTOR 030040233A TILT MOTOR 030040233A DIMMER/STROBE MOTORS 030040121 CYM MOTOR 030040114A ROTATING GOBO WHEEL MOTOR 030040213A FIXED GOBO MOTOR 030040224A COLOR WHEEL MOTOR 030040214 DIFFUSER MOTOR 030040214 GOBO ROTATION MOTOR 030040224A FOCUS MOTOR 030040213A...
  • Page 34 1582 Xingye Avenue, Nancun Panyu Guangzhou, 511442 China TEL: +86-20-3995 2888 PR lighting will try its best to offer accurate and overall information about a product’s technical data. Any changes won’t be notified if necessary. Patented Products. Counterfeiting Will be Prosecuted! P/N: 320020367...
