- Page 1 PLASTIC STAPLER/WELDER KIT MODEL NO: PSW2 PART NO: 3400772 USER INSTRUCTIONS GC10/24 ORIGINAL INSTRUCTIONS...
- Page 2 CLARKE dealer. The PSW2 Stapler is ideal for plastic crack repairs and reinforcement with different staples used in various situations. Staples are supplied in different sizes (see page 12) and after implanting, the exposed staple parts can be easily broken off after the plastic parts are melted.
-
Page 3: Specification
SPECIFICATIONS Item Specification Dimensions (L x D x H) 255 x 59 x 36 mm - product 260 x 205 x 75mm - storage case Weight 267 g (device only) Operating voltage DC5V - 2A Rated power (charger) 10 W Ingress protection IP20 Power cable length... -
Page 4: General Safety Warnings
GENERAL SAFETY WARNINGS WARNING: READ ALL SAFETY WARNINGS AND ALL INSTRUCTIONS. FAILURE TO FOLLOW THE WARNINGS AND INSTRUCTIONS MAY RESULT IN ELECTRIC SHOCK, FIRE AND/OR INJURY. WORK AREA SAFETY 1. Keep the work area clean and well lit. Cluttered or dark areas invite accidents. 2. - Page 5 3. The staples used with this device are made of special materials, not ordinary steel wire. When the staples are used up, please contact your CLARKE dealer, otherwise any malfunction caused by the use of staples of other materials will not be covered by the warranty.
-
Page 6: Safety Symbols
SAFETY SYMBOLS The following safety symbols may be found on this product packaging. Read instruction manual WEEE Symbol (lithium ion before use batteries) Do not immerse battery Do not Incinerate in water. Harmful to batteries aquatic life. Indoor use only Hot surfaces Wear protective gloves Class II product without... -
Page 7: Controls And Display
CONTROLS & DISPLAY Green light Green light on - standby Blue light Blue light comes on - Normal operation Large LED light Green light flashing - unit is charging Green light continuously on - unit is on Red light Red light flashes quickly. Overheating protection -The device will recover automatically. - Page 8 The stapler should not be operated while using the charger. NOTE: If the battery requires replacement take the unit to your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 9: Operation
OPERATION 1. Push fit the welding tip onto the heating elements. 2. Toggle the POWER switch to the ON position. The green LED status indicator will come on. 3. According to the shape of the damage to be repaired, select the corresponding staple from the selection on page 12 and insert into the welding tips of the device. - Page 10 10. Use a straight staple when repairing along the edge of the workpiece. 11. Cut off the exposed part of the staple or rock it back and forth with your hands until it breaks off. • A pair of end cutting pliers may be very useful for this.
-
Page 11: Care And Maintenance
5. Check the charger power cable to ensure it is sound and free from cracks, bare wires etc. 6. Refer to your CLARKE dealer if any repairs are required. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 12 0.8 mm flat staples for repairing flat plastic surfaces Part No;-1800212 8 mm Wave staples for repairing flat plastic surfaces that need extra reinforcement Part No;-1800214 Please re-order from your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 13: Component Parts
Locator plate Main PCB Ball plunger Battery Wire guide 2 Power cable Switch bracket X-head screw Spring Consumable items listed on page 12 are available from your Clarke dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 14 DECLARATION OF CONFORMITY-UK Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 15: Declaration Of Conformity (Ce)
DECLARATION OF CONFORMITY-CE Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
