Technical Support and E-Warranty Certificate
www.vevor.com/support
SEWAGE PUMPS
USER'S GUIDE
MODEL: Q400191M、Q600212、Q750191M
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the major
top brands and does not necessarily mean to cover all categories of tools offered by us. You
are kindly reminded to verify carefully when you are placing an order with us if you are
actually saving half in comparison with the top major brands.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for VEVOR Q400191M
Summary of Contents for VEVOR Q400191M
- Page 1 SEWAGE PUMPS USER'S GUIDE MODEL: Q400191M、Q600212、Q750191M We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and does not necessarily mean to cover all categories of tools offered by us.
- Page 2 This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
-
Page 3: Introduction And Safety
Warning-To reduce the risk of injury, user must read instructions manual carefully. This Pump Has Been Evaluated for Use With Water Only WARNING -“Risk of electric shock - This pump is supplied with a grounding conductor and grounding type attachment plug. - Page 4 7.The pump must be connected with a current type leakage current breaker which carries a rated leakage current of no more than 30 MA. 8.Check the connection of the plug before running. If the wire is damaged, it must be replaced by the manufacturer, the agent or the relevant technical personnel to avoid any danger.
-
Page 5: Installation And Commissioning
INSTALLATION AND COMMISSIONING Long enough and strong ropes should be attached to the handle before the first use. When the pump is immersed into the liquid, the rope along with a handle can be used to balance the pump. Installation - 4 -... - Page 6 The equipment requires an area of at least 60x60cm. Depth of equipment immersed in technical parameters.When installing the equipment, make sure the open will not the suction opening will not be blocked by foreign objects to keep the equipment stable. - 5 -...
-
Page 7: Operation
OPERATION Connecting pressure pipe - screw the pressure pipe onto the pressure connector. All joint connections must be sealed with a threaded sealing stripe. -When using the hose, screw the right hose adapter into the pressure connector. -Secure the hose firmly to the hose adapter and secure it with a hose clamp. - Page 8 FAULT ANALYSIS In most cases, you will be able to troubleshoot problems easily by yourself. Before you contact us, please refer to the following table for technical support. This will help you save a lot of work and possible expenses. Questions Analysis of causes Countermeasure...
- Page 9 CLEAN Clean the equipment from the outside. Flush with clean water. Use brush and detergent to remove stubborn pollution. Immerse the pump into a container with clean water, open it for running a while, and flush it in the pump. Storage If there is a risk of frost, remove equipment and accessories, and clean and store it a place protected from frost.
-
Page 10: Circuit Diagram
Disposal packaging The packing is made of cardboard and corresponding marking plastic. These materials can be recycled. CIRCUIT DIAGRAM connector assembly Blue Blue Wire assembly Wire Nut White Black White connector assembly Wire assembly Ground wire Wire Nut Wire Nut assembly Float Switch Blac... -
Page 11: Technical Data
TECHNICAL DATA Model Q400191M Q600212 Q750191M Voltage and frequency AC120V 60Hz AC120V 60Hz AC120V 60Hz Maximum horsepower 0.5HP 0.75HP 1.0HP Maximum flow rate 4188GPH 5000GPH 5770GPH Maximum lift 24ft 28ft 34ft Interface size NPT1-1/2 NPT1-1/2 NPT1-1/2 - 10 -... - Page 12 Technical Support and E-Warranty Certificate www.vevor.com/support...
