Technical Support and E-Warranty Certificate
www.vevor.com/support
VACUUM PUMP
MODEL:RS-1 / RS-1.5 / RS-2 / RS-3 / RS-6
2RS-2 / 2RS-3 / 2RS-4 / VP280
We continue to be committed to provide you tools with competitive price.
"Save Half", "Half Price" or any other similar expressions used by us only represents an
estimate of savings you might benefit from buying certain tools with us compared to the
major top brands and does not necessarily mean to cover all categories of tools offered by
us. You are kindly reminded to verify carefully when you are placing an order with us if you
are actually saving half in comparison with the top major brands.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the RS-1 and is the answer not in the manual?

Questions and answers

Summary of Contents for VEVOR RS-1

  • Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support VACUUM PUMP MODEL:RS-1 / RS-1.5 / RS-2 / RS-3 / RS-6 2RS-2 / 2RS-3 / 2RS-4 / VP280 We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an...
  • Page 3: Vacuum Pump

    VACUUM PUMP MODEL:RS-1 / RS-1.5 / RS-2 / RS-3 / RS-6/2RS-2 / 2RS-3 / 2RS-4 / VP280 NEED HELP? CONTACT US! Have product questions? Need technical support? Please feel free to contact us: Technical Support and E-Warranty Certificate www.vevor.com/support This is the original instruction, please read all manual instructions carefully before operating.
  • Page 4: Safety Instruction

    SAFETY INSTRUCTION Beforeoperatingthisappliance, please read the instructions manual carefully and save these instructions. Basic safety precautions should always be followed, including the following: Warning -To reduce the risk of injury, the user must read the instructions manual carefully.ed Thissymbol, placed before a safety comment, indicates a kind of precaution, warning, or danger.
  • Page 5: Pump Components

    PUMP COMPONENTS OPERATING MANUAL 1.Before using your vacuum pump In all cases, motors are designed for operating voltages plus or minus 1 0 % of the normal rating. Single voltage motors are supplied fully connected and ready to operate. ( 1 ) Check to be sure the voltage and frequency at the outlet match the specifica- tions on the pump motor decal.
  • Page 6: To Maintain Your High Vacuum Pump

    2.To shut down your pump after use To help prolong pump life and promote easy starting. Follow these procedures for shut down. ( 1 ) Close the manifold valve between the pump and the system. ( 2 ) Remove the hose from the pump inlet. ( 3 ) Cap the inlet port to prevent any contamination or loose particles from entering the port.
  • Page 7: Troubleshooting Guide

    TROUBLESHOOTING GUIDE Your pump has been for dependable use and has a long life. If something should go wrong, the following guide will help you get the pump back into service as quickly as possible. If the disassembly of the pump is required, please check your warranty.The warranty may be voided by misuse or customer tampering, which results in the pump being inoperable.
  • Page 8: Common Troubleshooting

    COMMON TROUBLE SHOOTING Failure Description FaultCause Solution Tighten the air inlet cap 1.The air inlet cap on the spare port side of the air inlet port is loose. 2. The rubber ring inside the air Replace the rubber ring inlet cap on the spare port side of the air inlet port is damaged Refuel to the centerline of the oil 3.
  • Page 9: Technical Parameter

    TECHNICAL PARAMETER 3CFM1-3HPZKBOC001V2 3CFMZKB0000000001V3 Model RS-1 Voltage 220-240V 50Hz Free Air Dispalcement 3CFM Ultimate Vacuum Rotating Speed 1440 Power(HP) Oil Capacity(ml) Dimension(mm) 240*110*220 Weight(Kg) QCKTZKB2.5CFM1-4HV2 Model RS-1 Voltage 220-240V 50Hz Free Air Dispalcement 2.5CFM Ultimate Vacuum Rotating Speed 1440 Power(HP)...
  • Page 10 QCKTZKB5CFM1-3HPDV1 Model RS-2 Voltage 120V/60HZ Free Air Dispalcement 5CFM Ultimate Vacuum Rotating Speed 1720 Power(HP) Oil Capacity(ml) Dimension(mm) 290*120*240 Weight(Kg) 7CFM1-2HPZKB00001V1 Model RS-3 Voltage 120V/60HZ Free Air Dispalcement 7CFM Ultimate Vacuum Rotating Speed 1720 Power(HP) Oil Capacity(ml) Dimension(mm) 310*125*255 Weight(Kg) 7CFM1-2HPZKB00001V2 Model RS-3...
  • Page 11 QCKTZKB6CFM1-2HP1V1 Model 2RS-2 Voltage 120V/60HZ Free Air Dispalcement 6CFM Ultimate Vacuum 0.3PA Rotating Speed 1400 Power(HP) Oil Capacity(ml) Dimension(mm) 290*115*225 Weight(Kg) 8CFM1HPZKB0000001V1 Model 2RS-3 Voltage 120V/60HZ Free Air Dispalcement 8CFM Ultimate Vacuum 0.3PA Rotating Speed 3500 Power(HP) Oil Capacity(ml) Dimension(mm) 360*135*275 Weight(Kg)...
  • Page 12 9CF1HPZKBJB000001V3 9CF1HPZKBJB000001V2 Model 2RS-3 Voltage 220-240V 50Hz Free Air Dispalcement 9CFM Ultimate Vacuum 0.3PA Rotating Speed 3500 Power(HP) Oil Capacity(ml) Dimension(mm) 360*135*275 Weight(Kg) VP280ZKB000000001V3 VP280ZKB000000001V2 Model VP280 Voltage 220-240V 50Hz Free Air Dispalcement 10CFM Ultimate Vacuum 0.3PA Rotating Speed 2800 Power(HP)...
  • Page 13 12CFM1HPDJZKB0001V1 Model RS-6 Voltage 120V/60HZ Free Air Dispalcement 12CFM Ultimate Vacuum Rotating Speed 1720 Power(HP) Oil Capacity(ml) Dimension(mm) 430*140*250 Weight(Kg) 16.5 12CFM1HPSJZKB0001V2 Model RS-6 Voltage 220-240V 50Hz Free Air Dispalcement 12CFM Ultimate Vacuum Rotating Speed 1440 Power(HP) Oil Capacity(ml) Dimension(mm) 430*140*250 Weight(Kg)...
  • Page 14: Exploded Drawing

    EXPLODED DRAWING Die-cast aluminum housing Fan cover Sight glass Crossscrew Oil drain Motor cover Oil drain screw O- ring Power supply cords Screw Sealing ring Power switch Washer Screw Rubber foot Bearing Base plate Motor rotor Capacitor box Self-tapping screw Centrifugal switch Back-pump cover Motor stator...
  • Page 16 Technical Support and E-Warranty Certificate www.vevor.com/support Made In China...
