- Page 1 User manual BAR1810 Please read the instructions carefully before use...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. Safety Instructions……………………………………………………………………………3 Technical Specifications………………………………………………………………………4 Control Menu ……………………………………………………………………………………4-5 DMX Channels …………………………………………………………………………………6 ………………………………………………………………………………………7 Trouble Shooting…………………………………………………………………………………8 Fixture Cleaning………………………………………………………… ………………………8 STATEMENT The product has well capability and intact packing when leave factory. All of the user should comply with warning item and manual, any misuse cause of the damages are not included in our guarantee, and also can not be responsible for any malfunction &... -
Page 3: Safety Instructions
1.Safety Instructions Please keep this User Guide for future consultation. If you sell the unit to another user, be sure that they also receive this instruction booklet. Unpack and check carefully there is no transportation damage before using the unit. •... -
Page 4: Technical Specifications
2.Technical Specifications Voltage: AC100-240V, 50/60Hz Power: 190W Light Source: 18X10W RGBW 4in1 ultra bright LED Lifespan: around 50,000-100,000 hours Control: DMX 512, 5/8 channels Control mode: DMX 512, Auto mode, Master/Slave Mode Display: OLED function menu with 4 buttons Heat dissipation: intelligent temperature control, Silent fan Power connection: Power con connectors input/output Data connection: 3-pin DMX connectors input/output IP Rating: IP20... - Page 5 Display panel operation instruction: Menu Sub-Menu Description DMX Address A.(001-512) DMX address 001-512 Manual Manual Mode DMX1 5CH Mode (default) DMX2 8CH Mode Mode Auto Auto Mode Define Define Mode Green Green Blue Blue Cold Cold White Pink Pink Color Yellow Yellow Cian...
-
Page 6: Dmx Channels
4.DMX Channels 5 Channels Mode Channel Function DMX Value Description Dimmer 0-255 Dimmer,0-100% 0-255 Red dimming,0-100% Green 0-255 Green dimming,0-100% Blue 0-255 Blue dimming,0-100% White 0-255 White dimming,0-100% 8 Channels Mode Channel Function DMX Value Description Dimmer 0-255 Dimmer,0-100% 0-255 Red dimming,0-100% Green 0-255... - Page 7 5. 5.Dimension...
-
Page 8: Trouble Shooting
6.Trouble Shooting Following are a few common problems that may occur during operation. Here are some suggestions for easy troubleshooting: A. The unit does not work, no light and the fan does not work 1. Check the connection of power and main fuse. 2.
