8. NOMENCLATURE

8-1. Part Identification

Part identification is described in this section.
Monitor LEDs
Power terminal block
(M4 screw)
Error clear button
common to Axis-1 and Axis-2
Axis-1 sensor connector
Axis-2 sensor connector
SW1:
Axis-1 function selector switches
SW2:
Axis-2 function selector switches
Front face
Axis-1 pulse number setting switch
Axis-2 pulse number setting switch
I/O connector
Rear face
ON
1
2
3
4
5
6
ON
1
2
4
3
3
4
2
5
1
6
ON
30
SW3:
Common axis function selector switches
