Remote control - Setu
EN
4. BUTTONS AND FUNCTIONS
Before using your air conditioner, familiarise yourself with its remote control. The following is a brief introduction
to the remote control itself. For instructions on how to operate the air conditioner, refer to the section „How to
use the basic functions" in this manual.
1
2
3
4
5
6
SETU
6
User manual
1. ON/OFF
Switches the unit on or o
2. Button
Increases the temperature in 1°C (1°F) increments. The maximum
temperature is 30°C (86°F).
Note: Pressing the
seconds will switch the displayed temperature between °C and °F.
3. SET button
Scroll through the operational functions as follows:
7
Breeze Away function ( )
8
function ( )
The selected symbol will start ashing in the display area, press
9
the OK button to con rm.
10
4. Button
Reduces the temperature in 1°C (1°F) increments. The minimum
temperature is 60°F (16°C).
11
5. Fan speed button
12
Selects fan speeds in the following order:
13
AU 20%
14
Press or o decrease/increase the fan speed in 1% steps.
6. SWING blind fan button
Starts and stops the horizontal movement of the blind. Hold down
for 2 seconds to activate the function.
7. MODE MODE button
Scrolls through the operating modes of the unit as follows: AUTO
COOL (cooling)
FAN (ventilation)
Note: Heating mode (HEAT) is not supported by cooling-only units
(without built-in heat pump).
8. ECO/GEAR button (selected models)
Press this button to enter the energy-saving mode in the
following order:
ECO GEAR (75%)
9. OK
Used to con rm selected functions.
and buttons together at the same time for 3
Sleep function (
AP mode ( Breeze Away function ( )
)
40% 60% 80%
DRY (dehumidi cation)
GEAR (50%)
Follow Me
)
100%.
HEAT (heating)
