Rotenso CONTROL SETU User Manual page 8

Remote control - Setu
EN
1
Breeze Away indicator (selected models)
Active cleaning indicator (selected
models)
Air ionisation indicator
Sleep mode indicator
Follow me indicator
Wi-Fi control indicator
Low battery indicator (if ashing)
2
Auto mode
Cooling mode
Drying mode
3
ECO indicator (selected models)
Displays when eco function is
activated
GEAR indicator (selected models)
Displays when gear function is
activated
LOCK indicator
Displays when the remote control
button lock is on
4
Horizontal blind fan indicator

Indicator for automatic vertical blind
fanning
Turbo mode indicator (selected
models)
Not available on this model
Not available on this model
8 User manual
Heating mode
Ventilation
mode
   
5
Fan speed indicator
Quiet
Low
Average
High
Auto
The fan speed cannot be adjusted in
automatic or drying mode.
Note: [*]
Not all models display fan speeds between
AU-100%.
6
Temperature/Timer/Fan speed
Displays the set temperature, fan speed or
Timer setting when using the Timer ON/OFF
function.
Temperature range:
16-30°C/60-86°F/(20-28°C/68-82°F)
(Depends on the model)
Timer time range: 0-24 hours
Fan speed range: AU -100%
This display is blank when operating in
ventilation mode (FAN).
7
Transmission indicator
Lights up when the remote control
sends a signal to the indoor unit
Timer setting indicator ON
Timer setting indicator OFF
Mute indicator (selected models)
1% *
2%-20%
21%-40% *
41%-60% *
61%-80% *
81%-100% *
