Normal Sweep Display - Tektronix 2337 Instruction Manual

Table 4
Calibration Standard-amplitude accuracy, +0.25%;
Generator signal amplitude, 2 mV to 50 V; output
signal, 1-kHz square wave. Fast-rise
repetition rate, 1 to 100 kHz; rise time,
1 ns or less; signal amplitude, 100 mV to
Dual-Input Connectors, bne female-to-dual-bne male.
Cable Impedance, 50 2; length, 42 in.;
(2 required) connectors, bne.
Adapter Connectors, bne female-to-bne female.
Termination | Impedance, 50 22; connectors, bne.
NORMAL SWEEP DISPLAY
First obtain a Normal Sweep Display (baseline trace),
using the following procedure.
1. Preset the instrument front-panel controls as follows:
Display
INTEN Fully counterclockwise
Midrange
Midrange
AC-GND-DC.
VOLTS/DIV
VOLTS/DIV VAR
VERTICAL MODE
BW LIMIT
2337 Operators
AC
Calibrated detent (fully
Select CH 1
Not limited (push button
