User manUal
SUPERIA SERIES
Multi-functional hybrid control units
for intrusion detection systems
1
GENERALS
The SUPERIA / EXCELSA series control units are multi-func-
tional hybrid control units supporting both wired and wire-
less devices.
Control units are compatible with
• all EL.MO. series devices (keypads, readers, power
groups, security fog systems, concentrators and single
detectors) thanks to ULTRABUS interface;
• the first-generation wireless technology using RIVERRF
concentrators and the NG-TRX wireless technology with
connection of GATEWAY2K over serial line.
Optional modules can be installed to improve unit operating
mode.
The control units can be connected to e-Connect.
The SUPERIA / EXCELSA control units are supplied in a metal
housing protected against cover opening and removal from
the wall.
Icons used in this manual
▼ Example of messages on keypad display
Ve01/09/17 09:00
▼ Keys typing
Area 1
▼ Usage example
Manual contents
▼ Keypads usage
operating mode from keypad → cap. 2 p. 2
▼ Proximity keys usage
operating mode from keypad → cap. 3 p. 13
▼ Remote controls usage
operating mode with remote control → cap. 4 p. 15
▼ GSM and phone communications
phone calls and SMS reception → cap. 5 p. 16
▼ Temperature monitoring
use of built-in temperature detector → cap. 6 p. 16
▼
e-Connect usage
Information on e-Connect service → cap. 7 p. 17
▼ Maximum security
maximum security property, arming with maximum
security → cap. 8 p. 17
▼ System test
system test to check system working → cap. 9 p. 19
▼ Anomalies diagnostics
anomalies check → cap. 10 p. 19
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for El.Mo SUPERIA Series
Summary of Contents for El.Mo SUPERIA Series
- Page 1 Control units are compatible with Manual contents • all EL.MO. series devices (keypads, readers, power ▼ Keypads usage groups, security fog systems, concentrators and single operating mode from keypad → cap. 2 p. 2 detectors) thanks to ULTRABUS interface;...
-
Page 2: Keypads Usage
KEYPADS USAGE Sector keys indications may vary according to the distribu- tion of sectors among areas. The SUPERIA control units are multi-area devices capable of managing up to 64 sectors. 16 Areas / 4 sectors mode During unit setup, sectors can be divided into: Each sector key is associated to a sector of the currently •... -
Page 3: Led Indicators
• OFF: no alarm events. STOP To exit a menu/submenu. • ON: alarm in progress (active relay). ↑ ↓ To browse among menu pages and options • Blinking: alarm memories. To reset alarm memories, arm and disarm the system. 4. Tamper LED It indicates tamper status. -
Page 4: Change Of Current Operating Area
2.2.1 Change of current operating area 2.2.3 User code and keypad locked To change the current operating area: The most part of commands from keypad requires a 6-digit user code. Ve01/09/17 09:00 during installation option Enable keypad locking for error code has been enabled, Welcome the keypad will be blocked after the wrong code has been entered for three times. -
Page 5: Check Anomalies Status
2.3.2 Check anomalies status Ve01/09/17 09:00 The yellow LED will blink in case of anomalies. Welcome To check anomalies: – Go to ANOMALIES STATUS. – Press OK to enter the menu item. – Use arrow keys ↑ or ↓ to browse the reports. In case of more than one anomaly, an arrow →... - Page 6 – When finished, press OK to start arming, STOP to cancel Ve01/09/17 09:00 Welcome – If exit time has been set, it will be marked by beep sounds: leave the protected areas within the set time walking through the path set. At the end of exit time, sectors proposed will be armed (sector keys remains lighted unless the option Hide arming state is enabled).
-
Page 7: Fast Arming - 4 Sectors Per Area Mode
be activated. Area 1 Ins: 123--67- – Press sector key of the sector to be armed (the sector can be armed if it is authorised at least to one user). The key will start blinking. when you press key 8 also sector 8 will be proposed for arming (as long as it is authorised for the user): Settore S1.A1 Area 1... -
Page 8: Euro" Mode
Ve01/09/17 09:00 The pressed sector keys will switch off and the related sec- Inserita S 1234 tors will be disarmed. If during pre-disarming a sector key corresponding to a dis- armed sector is pressed, this sector will be armed when the time expires. -
Page 9: Enter User Menu On Keypad
User menu items allow users to manage basic maintenance. GUASTO INS.FORZATO? The user can access the menu only if authorised by the installer (with Basic Maintenance option). – Press OK within 15 seconds to start forced arming, STOP To enter user menu: to cancel it. -
Page 10: Zones Bypass
→ OVERTIME REQUEST - § 2.5.5 p. 11 ▼ NONE Access denied. → CLOCK SETUP - § 2.5.6 p. 11 → WEEKLY PROGR. - § 2.5.7 p. 11 ▼ PERMANENT Access granted. → MANAGE USERS - § 2.5.8 p. 11 → PHONE NUMBERS - § 2.5.10 p. 12 Image Installer →... -
Page 11: Change Day Type
2.5.6 Date and time setup assigned "Manual control" option. – Use arrow keys ↑ or ↓ to go to OUTPUT CONTROL – Use arrow keys ↑ or ↓ to go to CLOCK SETUP option. option. – Press OK to enter the menu. –... -
Page 12: System Test
2.5.10 Change phone numbers displayed. – Press OK to go to the next output to test. Repeat for each Numbers on phone numbers list can be modified. output. – Use arrow keys ↑ or ↓ to go to PHONE NUMBERS option. –... -
Page 13: Events Log
Stopping the test MAINTENANCE EMER.DOOR TEST Zones to test Warehouse door Stop EMER.DOOR TEST (OK = Execute) Test started (# = Stop) – Use arrow keys ↑ or ↓ to go to EMER. DOOR TEST option. – Press OK to enter the menu. –... -
Page 14: Proximity Keys Usage
For LEDs indications, please see paragraph 2.1.3 p. 3 . reader or keypad). IZENITH – The pre-arming time will start (around 5s): if there are sector keys, users can modify sectors proposed for arm- ing. Please see paragraph 2.4.3 p. 5 . –... -
Page 15: System Forced Arming
4.2.1 System arming system disarming, a duress alarm related to the user that disarmed will be created. To arm the system, press one of the following keys: • "Total arming" (A): arms all sectors authorised for the 3.2.4 System forced arming user If the option Activate Arming Lock in BrowserOne is active, •... -
Page 16: Panic Event
This function is available in Users menu in BrowserOne. mote control key previously selected. TEMPERATURE MONITORING Bypassed detectors will not cause system lock. SUPERIA series units are equipped with a temperature de- GSM AND PHONE tector measuring the temperature inside the housing. COMMUNICATIONS... -
Page 17: A-B Temperatures Management
• via weekly programmer • by the installer via software. Arming with Max Security To arm with Max Security property: e-Connect is a supervision software for EL.MO. intrusion de- tection systems. e-Connect allows users to control and manage their systems... -
Page 18: Notes On Max Security
In detail, if a sector is armed in Weekly Programmer Ve01/09/17 09:00 Max Security mode and a user with max security prop- Welcome erty performs a disarm, the Weekly Programmer Max Security property remains active. Therefore, at the next control unit arming it will be armed with Max Se- curity property, even if the arming is performed by a user without the Max Security property. -
Page 19: System Test
functioning of detectors connected to zones, control of Disarming made by weekly programmer idle and alarm conditions with Max Security • outputs: temporary activation of programmable relay Reset Max Security by weekly (when activated for general or tamper alarm), external programmer siren, sirens on serial line or radio sirens Reset Max Security by weekly... -
Page 20: Emergency Light
GSM automatic switch off Installers can also configure GSM module so that it turns off automatically after the inactive time intervalset. Emergency light Keypad display can be set to remain active for a defined time interval in case of mains failure (Emergency Light Time). When the interval expires, the display will blink for 30 secs to indicate imminent deactivation. -
Page 21: Notes
NOTES... -
Page 22: Notes
NOTES... -
Page 23: Table Of Contents
Table of contents GENERALS ......P. 1 Calls reception ......p. 16 5.2 Receiving SMS from control units . -
Page 24: Eu Declaration Of Conformity
The information and product features herein are not binding and may be changed without prior notice. EL.MO. Spa - Via Pontarola, 70 - 35011 Campodarsego (PD) - Italy Ph. +39 049.9203333 - Fax +39 049.9200306 - Help Desk +39 049.9200426 - www.elmospa.com - international@elmospa.com...
