Summary of Contents for SystemAir SAVE VSC 300
- Page 1 SAVE VSC 200/300 Installation instructions Document in original language | 333551 · v1.1...
- Page 2 This also applies to products already ordered, as long as it does not affect the previously agreed specifications. Systemair is not liable or bound by warranty if these instructions are not adhered to during installation or service. 333551 | v1.1...
-
Page 3: Table Of Contents
Important Safety Information ......1 Intended Use.........1 Admonitions .........2 Technical Data ..........2 Dimensions and Weight ......2 3.1.1 SAVE VSC 200 ......2 3.1.2 SAVE VSC 300 ......3 Duct connections........3 Installation recommendation regarding condensation ........3 3.3.1 Condensation inside of the unit .........3 3.3.2 Condensation outside of the unit .........4... -
Page 5: Overview
For the assertion of warranty claims, the products must be correctly connected and operated, and used in accordance with the data sheets. Further prerequisites are a completed maintenance plan with no gaps and a commissioning re- port. Systemair will require these in the case of a warranty claim. Type label Before calling your service representative, make a note of the specification and production number from the type label, which can be found next to the external connections and inside of the unit. -
Page 6: Admonitions
| Technical Data • The system should operate continuously, and only be stopped for maintenance/service. • Do not connect tumble dryers to the ventilation system. • Make sure that filters are mounted before starting the unit. Admonitions Danger • Make sure that the mains supply to the unit is disconnected before performing any maintenance or electrical work! •... -
Page 7: Save Vsc 300
Technical Data | 3.1.2 SAVE VSC 300 1140 173.5 1491 115.4 1365 Fig. 3 Dimensions The unit weight is 80 kg. Duct connections Symbol Description Symbol Description Supply air Outdoor air Extract air Exhaust air Installation recommendation regarding condensation 3.3.1 Condensation inside of the unit The unit should run continuously. -
Page 8: Condensation Outside Of The Unit
• Check completeness of the delivery. Verify that all ordered equipment is delivered before starting the installation. Any discrepancies from the ordered equipment must be reported to the supplier of Systemair products. Warning When opening the transport packaging, there is a risk of damage from sharp edges, nails, staples, splinters etc. -
Page 9: Prerequisites For Installation
Prerequisites for Installation | Prerequisites for Installation SAVE VSC 200/300 is designed for ceiling installation. Left and right connections are possible. Location and Space Requirements The SAVE VSC 200/300 should preferably be installed in a separate room (e.g. storeroom, laundry room or similar.). Note: SAVE VSC 200/300 must be installed in a heated area. -
Page 10: Installation
| Installation Installation Important • The device may only be installed by qualified, instructed and trained personnel. The persons must know the relevant safety directives in order to recognise and to avoid risks. Ø12, 34mm 1400 Make sure that the surface is flat and that it supports the weight of the unit. Perform the installation in accordance with local rules and regulations. -
Page 11: Ventilation Duct Connection And Insulation
Connect the condensate drainage to the 2 drain plugs in the bottom of the unit. Make sure to use correct drain traps on both connections. The height (H) must be at least 60 mm. Drain traps are not included on delivery and can not be ob- tained from Systemair. Ventilation Duct Connection and Insulation Important •... -
Page 12: Electrical Connections
| Electrical connections Electrical connections Main circuit board layout The SAVE VSC 200/300 is equipped with built-in regulation and internal wiring. Fig. 4 Main circuit board connections Position Description Connection to the external connection box Terminals for a heater Terminals for a TRIAC Terminals for the mains power supply Terminals for power supply of extract air fan Terminals for power supply of supply air fan... -
Page 13: External Connections (Connection Board)
Before Starting the System | Position Description Terminals for speed control of extract air fan Terminals for speed control of supply air fan External connections (Connection board) External connections to the main circuit board are done via connection board situated inside of the unit. Fig. -
Page 14: Commissioning
| Commissioning • The unit is correctly wired Commissioning Follow the first startup instructions and fill in the Commissioning record as you go through the settings. The Startup Wizard cannot be skipped. Note: If the SAVE LIGHT control panel is used, the start-up wizard is skipped and the factory settings are used. Select language, set the time and choose airflow control type. -
Page 15: Disposal And Recycling
Disposal and recycling | 3. Make sure that the Commissioning record is complete. 4. Collect all tools. 5. Inform the appropriate person that work is finished. 6. Follow the procedures for the return and disposal of replacement parts and the disposal of packing. Disposal and recycling This product is compliant with the European WEEE Directive and related national waste legislation. -
Page 16: Eu Declaration Of Conformity
Degrees of protection provided by enclosures (IP Code). The manufacturer hereby confirms that EN 62233 SAVE VSC 200, SAVE VSC 300 Measurement methods for electromagnetic fields of household appliances and similar apparatus with regard comply with all applicable requirements in the following to human exposure. - Page 17 333551 | v1.1...
- Page 18 Systemair UAB Linų st. 101 LT–20174 Ukmergė, LITHUANIA Phone +370 340 60165 Fax +370 340 60166 www.systemair.com...
