- Page 1 SAVE VTR 700 Installation instructions Document in original language | 333565 · v1.1...
- Page 2 This also applies to products already ordered, as long as it does not affect the previously agreed specifications. Systemair is not liable or bound by warranty if these instructions are not adhered to during installation or service. 333565 | v1.1...
-
Page 3: Table Of Contents
Contents Overview ............1 12 EU Declaration of Conformity ......14 General Description ........1 Warranty ..........1 Type label..........1 Important Safety Information ......1 Intended Use.........1 Admonitions .........2 Technical Data ..........2 Dimensions and Weight ......3 Connections Left and Right models.....5 Installation recommendation regarding condensation ........5 3.3.1 Condensation inside of the... -
Page 5: Overview
For the assertion of warranty claims, the products must be correctly connected and operated, and used in accordance with the data sheets. Further prerequisites are a completed maintenance plan with no gaps and a commissioning re- port. Systemair will require these in the case of a warranty claim. Type label Before calling your service representative, make a note of the specification and production number from the type label, which can be found next to the external connections and inside of the unit. -
Page 6: Admonitions
| Technical Data • The system should operate continuously, and only be stopped for maintenance/service. • Do not connect tumble dryers to the ventilation system. • Make sure that filters are mounted before starting the unit. Admonitions Danger • Make sure that the mains supply to the unit is disconnected before performing any maintenance or electrical work! •... -
Page 7: Dimensions And Weight
Technical Data | Dimensions and Weight Fig. 2 Dimensions and weight, L model 333565 | v1.1... - Page 8 | Technical Data Fig. 3 Dimensions and weight, R model * Water coil connections. ** Drainage. *** Height with mounting bracket. The unit weight is 188 kg. 333565 | v1.1...
-
Page 9: Connections Left And Right Models
Technical Data | Connections Left and Right models Position Description Right hand model (Supply air connection is situated on the right hand side of the unit viewed from the front) Left hand model (Supply air connection panel is situated on the left hand side of the unit viewed from the front) Symbol Description... -
Page 10: Condensation Outside Of The Unit
Transport and storage The SAVE VTR 700 should be stored and transported in such a way that it is protected against physical damage. It should be covered so dust, rain and snow cannot enter and damage the unit and its components. -
Page 11: Location And Space Requirements
Location and Space Requirements The SAVE VTR 700 should preferably be installed in a separate room (e.g. storeroom, laundry room or similar.). When choosing the location it should be kept in mind that the unit requires maintenance regularly and that the inspec- tion door should be easily accessible. -
Page 12: Installation Procedure
Make sure to use correct drain trap. The height (H) must be at least 60 mm. Drain traps are not included on delivery and can not be obtained from Systemair. Note: Remove caps from the drainage holes inside the unit. -
Page 13: Installation And Configuration Of Accessories
The electrical connection box can be found behind a cover plate (pos. 1). The main circuit board (pos. 2) can easily be taken out from the unit. Fig. 6 Main circuit board position Main circuit board layout The SAVE VTR 700 is equipped with built-in regulation and internal wiring. 333565 | v1.1... -
Page 14: External Connections (Connection Board)
| Electrical connections Fig. 7 Main circuit board connections Position Description Connection to the external connection box Terminals for a heater Terminals for a TRIAC Terminals for the mains power supply Terminals for power supply of extract air fan Terminals for power supply of supply air fan Terminals for internal relative humidity/temperature sensor Analog input 1 —... -
Page 15: Before Starting The System
Before Starting the System | Fig. 8 External connection box and board Position Description Connection to the main circuit board Connection for external control panel (HMI) or Internet access module (IAM) Modbus RS485 connection AI6–7 Freely configurable Analog input. None/Input type selection in HMI. DO1–4 Freely configurable digital output. -
Page 16: Concluding Routines
| Concluding Routines Note: If the SAVE LIGHT control panel is used, the start-up wizard is skipped and the factory settings are used. Select language, set the time and choose airflow control type. Select revolutions per minute as the type of airflow con- trol only if these values are included with the device. -
Page 17: Disposal And Recycling
Disposal and recycling | Disposal and recycling This product is compliant with the European WEEE Directive and related national waste legislation. When disposing the unit, follow your local rules and regulations. This product packing materials are recyclable and can be reused. Do not dispose in household waste. - Page 18 Degrees of protection provided by enclosures (IP Code). The manufacturer hereby confirms that EN 62233 SAVE VTR 700 Measurement methods for electromagnetic fields of household appliances and similar apparatus with regard comply with all applicable requirements in the following to human exposure.
- Page 19 333565 | v1.1...
- Page 20 Systemair UAB Linų st. 101 LT–20174 Ukmergė, LITHUANIA Phone +370 340 60165 Fax +370 340 60166 www.systemair.com...
