Vivo MOUNT-TVCL1 Instruction Manual

Vivo MOUNT-TVCL1 Instruction Manual

Exposed column pneumatic arm tv mount
Hide thumbs

Advertisement

Table of Contents

Exposed Column Pneumatic
Arm TV Mount
SKU: MOUNT-TVCL1
Instruction Manual
Assembly Video & Product Info
www.vivo-us.com/products/mount-tvcl1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MOUNT-TVCL1 and is the answer not in the manual?

Questions and answers

Related Manuals for Vivo MOUNT-TVCL1

Summary of Contents for Vivo MOUNT-TVCL1

  • Page 1 Exposed Column Pneumatic Arm TV Mount SKU: MOUNT-TVCL1 Instruction Manual Assembly Video & Product Info www.vivo-us.com/products/mount-tvcl1...
  • Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Improper installation may cause damage or serious injury. Do not use this product for any purpose that is not explicitly specified in this manual.

  • Page 3: Package Contents

    Package Contents B (x2) A (x1) C (x2) Cover Mount VESA Adapter D (x2) F (x2) E (x1) VESA Adapte Mounting Plate G (x2) Ratchet Strap Included Hardware & Tools S-A (x8) S-B (x4) M-A (x4) M-B (x4) M-C (x4) M6x8mm Screw M6 Nut M6x14mm Screw...

  • Page 4: Assembly Steps

    Tools Needed: Weight Capacity: 17-66 lbs (8-30 kg) Phillips Screwdriver ASSEMBLY STEPS STEP 1 Remove the protective film from Pads (F) and apply them to the ends of Mounting Plate (E).
  • Page 5 STEP 2 Feed the Ratchet Straps (G) through the slots on Mounting Plate (E) as shown. NOTE Ensure the red circles on the Ratchet Straps are facing up when feeding through.
  • Page 6 STEP 3 Hold the Mounting Plate (E) onto the column and feed the strap around the column and through the ratcheting mechanism. WARNING Ensure the Ratchet Straps are not twisted before inserting into ratcheting mechanism. Mounting Plate can be set on the ground for easier assembly.
  • Page 7 STEP 3 - Cont’d While holding the Mounting Plate (E) up to your desired position, articulate the handle on the Ratchet Strap (G) forward and backwards. NOTE Apply tension to the strap Handle while tightening. Locked Full Open Strap Handle Lever Need to Loosen the Strap? Pull the Lever near the Handle...
  • Page 8 STEP 4 Remove the lower two Pre-installed Nuts (A1) on the Mount (A) using Wrench (T-C). Loosen the upper two nuts on the Mount using the Wrench (T-C). Remove VESA Plate (A2) by lifting up and away from Arm (A).
  • Page 9 STEP 5 Slide Arm (A) over the Threaded Studs on the Mounting Plate (E). Use Level (T-D) to ensure the Arm is level on the wall. Threaded Stud Secure Arm (A) to the Mounting Plate (E) using M6 Nuts (S-B) and Wrench (T-C).
  • Page 10 STEP 6 Press Covers (B) onto the Base of the Arm (A). STEP 7 ** PLEASE READ ** VESA Plate Assembly Options See pages 11-13 for Options VESA Adapters (C,D) can be assembled to VESA Plate in three different variations. Select an assembly option from pages 11-13 that matches your screen’s VESA pattern.
  • Page 11 VESA Pattern Option 1 300mm x 300mm or 400mm x 400mm Securing VESA Adapters: Secure VESA Adapters (C,D) to VESA Plate (A2) as shown below using M6x8mm Screws (S-A) and a Phillips screwdriver. Proceed to STEP 8 on Page 14 Note: Addtional options on pages 12-13...
  • Page 12 VESA Pattern Option 2 400mm x 200mm Securing VESA Adapters: Secure VESA Adapters (C,D) to VESA Plate (A2) as shown below using M6x8mm Screws (S-A) and a Phillips screwdriver. Proceed to STEP 8 on Page 14...
  • Page 13 VESA Pattern Option 3 300mm x 200mm Securing VESA Adapters: Secure VESA Adapters (C,D) to VESA Plate (A2) as shown below using M6x8mm Screws (S-A) and a Phillips screwdriver. Proceed to STEP 8 on Page 14...
  • Page 14 STEP 8 Option 1: Flat Monitor Attach the VESA Plate assembly to the back of your monitor using appropriate Screws (M-A,M-B), M8 Washers (M-E) and a Phillips screwdriver. Option 2: Curved Monitor Attach the VESA Plate assembly to the back of your monitor using appropriate Screws (M-C,M-D), M8 Washers (M-E) and Spacers (M-F,M-G).
  • Page 15 STEP 9 Attach VESA Plate (A2) with monitor to the Arm (A) using previously loosened nuts. Secure VESA Plate (A2) to the Arm (A) using previously removed Nuts (A1). Level the monitor using Level (T-D) and tighten all four Nuts using Wrench (T-C).
  • Page 16 STEP 10 Adjusting Monitor Height Position Mount Arm Turn 10-20x to Set Monitor Height Position the arm horizontally, as shown above, and firmly hold in Turn 6mm Allen Wrench (T-B) 10-20 times place. to obtain proper support for your monitor. Use the guide below to adjust the tension according to the amount of counterbalance Insert 6mm Allen Wrench (T-B)
  • Page 17 Height Adjustment Troubleshooting Follow the steps below if you are experiencing issues with the pneumatic height adjustment. Mount is Making a Popping Sound When Adjusting If Mount (A) is making a popping noise while adjusting, tighten the socket set screw on top of the adjustment screw using a large flat-head screwdriver.
  • Page 18 STEP 11 Organize cables using the built-in cable management clips. STEP 12 Adjust the tilt using 4mm Allen Wrench (T-A).
  • Page 19 Adjusting as Desired...

  • Page 20: Last Updated

    LAST UPDATED: 7/3/24 REV2 v1.0 Need Help? Get In Touch Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com www.vivo-us.com 309-278-5303 Chat live with an agent! FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us...
