Using the IQ-200 Optical Test System
Understanding the IQ-200 Software
42
www.valuetronics.com
Using the Front Panel Mouse
The front panel mouse operates as a standard computer mouse.
To drag elements with the front panel mouse,
1. Using the arrow buttons, position the cursor on the selection.
2. Activate the mouse drag function by pressing the
3. Drag the selection to the desired position using the arrow buttons.
4. Press on the left button to drop the selection and deactivate the
mouse drag.
Hold Button
To initiate mouse dragging.
Arrow Buttons
To move the mouse pointer.
Right Button
To display contextual menus.
Left Button
To select elements.
button.
IQ-200
