KE2 LDA Kit Contents - Page 1
Back Label & Side View - Page 1
Installing the KE2 LDA - Page1
Access the Local Dashboard - Page 2
ModBus (Serial) Access - Page 2
Remote Access Setup - Page 2
Manage E-mail Alerts - Page 2
Changing User Name & Password - Pg 2
Advanced Settings - Page 3
Appendix A ModBus Wiring- Page 3
Appendix B ModBus Configuration - Pg 4
KE2 LDA Kit
(pn 21253)
includes the KE2 LDA & Accessories
KE2 LDA
5ft. Ethernet
Cable
KE2 LDA Mounting
(pn 21418) sold separately
Power Plug
USB Cable
Installing the KE2 LDA
see bulletin Q.5.42 for additional options.)
Connection via WiFi
EACH DEVICE MUST HAVE A SEPARATE/UNIQUE
MODBUS ADDRESS
(See Appendix B for instructions)
Plug power cable into the KE2 LDA
and the other end into an electrical outlet.
The unit will power on automatically.
thermsolutions
KE2 Temp
.
Hold for manual defrost
Serial-Modbus Controllers:
KE2 Temp, KE2 Low Temp, KE2 Adaptive Control
© Copyright 2019 KE2 Therm Solutions, Inc., Washington, Missouri 63090
KE2 Local AreaDashboard & Alarms
Condensed Installation and Setup Instructions
Detailed installation instructions are found on our website at:
http://ke2therm.com –OR– scan the QR code at right.
When connected to the same network as KE2 Therm controllers, the KE2 LDA automati-
cally scans and finds all KE2 Therm controllers – Ethernet or Serial-ModBus.
Display a Local Area Dashboard of controllers connected to the customer's network
Connect controllers to KE2 SmartAccess customer portal without controller upgrades
Send alarm notices to multiple e-mail recipients
From webpage, make setpoint changes and receive alerts via e-mail or text message
366-day data logging when used with the KE2 Flash Drive (see bulletin Q.5.48)
KE2 LDA Back Label
Serial Adaptor
Bracket
(Multiple options exist,
Power
B
A
thermsolutions
KE2 Temp
.
Hold for manual defrost
Used to
identify
Unique for
device
each LDA
Reset
USB
OFF
ON
WiFi Switch
KE2 Switch to LAN
Connect Customer Network
LAN
WAN
WiFi to PC/Laptop,
Tablet, Phone
ABC Contracting
(888)555-3358
System Mode
Cool
STATUS
Superheat
Suct Pressure
Suct Temp
0.0 F
96.2 F
87.7 F
Evaporator Fan
All Clear
Off
Connect wirelessly
to the LDA Network
Q.5.69 August 2019
Serial #:
16197-251 Power: 5V-1A
MAC: EF:95:6E:40:87:F3
WIFI ESSID: KE2LDA-4087F3
WIFI PW: 3YzliZmQyZTI4
MGMT LOGIN: ke2admin
MGMT PW: 3YzliZmQyZTI4
http:ke2lda or IP: 192.168.50.1
KE2 LDA Side View
• KE2 Evaporator E ciency, KE2 Evap for
Rack E ciency,
or KE2 Controlled Environment
• DHCP Enabled or set address from
192.168.50.2 to 192.168.50.99
thermsolutions
TM
KE2 EvaporatorEfficiency
• Check IP address from front panel if DHCP
thermsolutions
TM
KE2 EvaporatorEfficiency
.
• Factory assigned 10.10.x.x addresses are
.
ENTER
now visible when connected to the LAN
BACK
ENTER
BACK
port. However, 10.10.x.x controllers can
only be managed by PC, phone, or tablet
when wirelessly connected to the KE2 LDA
or hardwired to the KE2 Switch.
.
thermsolutions
TM
KE2 EvaporatorEfficiency
thermsolutions
TM
KE2 EvaporatorEfficiency
.
.
ENTER
BACK
ENTER
BACK
Ethernet Controllers:
KE2 Evaporator E ciency,
KE2 Evap for Rack E ciency,
KE2 Controlled Environment
NOTE: DHCP or Static IP in Customer Network
QR Code
Links to
Setup Page
