Wyrestorm TX-35-IWC-KVM Quick Start Manual page 4

Specifications
Audio and Video
Inputs
Outputs
Audio Formats
Video Resolutions (Max)
Maximum Data Rate
USB Bandwidth over HDBaseT
Communication and Control
RS-232
Power
Power Supply
PoH
Environmental
Operating Temperature
Storage Temperature
Dimensions and Weight
Rack Units/Wall Box
Height
Width
Depth
Weight
Regulatory
Safety and Emission
Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice.
Warranty Information
WyreStorm Technologies ProAV Corporation warrants that its products to be free from defects in material and workmanship under normal
use for a period of five (5) years from the date of purchase. Refer to the Product Warranty page on
limited product warranty.
Copyright © 2024 WyreStorm ProAV Corporation | Copyright © 2024 WyreStorm ProAV Corporation |
TX-35-IWC-KVM Quickstart Guide | 241003 TX-35-IWC-KVM Quickstart Guide | 241003
1 x USB Type C Input
1 x USB Type C Power Input (for device charging, will not power TX)
1x HDBT Out: RJ45 Female
Supports multi-channel audio formats, including PCM 2.0/5.1/7.1, Dolby TrueHD, Dolby Atmos,
DTS-HD Master Audio and DTS:X
Video Resolutions
VESA:
800x600 8 , 1024x768 8 , 1024x768 8 , 1280x768
1600x900 8 , 1600x1200 8, 1680x1050
SMPTE:
1280x720P 1,2,3,4,5,6,7,8 , 1920x1080I 6,8
1 = at 23.98 Hz, 2 = at 24 Hz, 3 = at 25 Hz, 4 = at 29.97 Hz, 5 = at 30 Hz, 6 = at 50 Hz, 7 = at 59.94 Hz, 8 = at 60 Hz
NOTE:
4096x2160/3840x2160@50Hz/60Hz is based on chroma sub-sampling 4:2:0 8-bit only
Cat5e or higher: 3840x2160p @30Hz 8bit (100m/328ft)
5Gbps (Per lane)
150Mbps
1x 3-pin Phoenix (Passthrough RS-232 + Update Port)
12V DC 3A (Sold Separately)
Transmitter can be powered by the receiver with PSE module such as RX-500.
0°C to +45°C (32°F to +113°F), 10% to 90%, non-condensing
-20°C to +70°C (-4°F to +158°F), 10% to 90%, non-condensing
1-Gang US Style
105.6mm/4.16in
45mm/1.77in
45.3mm/1.78in
0.21kg/0.46lb
CE | FCC | RoHS | RCM | EAC | UKCA
wyrestorm.com wyrestorm.com
8 , 1280x800 8 , 1280x960
8 , 1920x1200 8
, 1920x1080P 1,2,3,4,5,6,7,8 , 3840x2160
4 of 4
8 , 1280x1024 8 , 1360x768 8 , 1366x768
2,3,5,6,8 , 4096x2160 2,3,5,6,8
wyrestorm.com for more details on our
INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)
8 , 1400x1050 8 , 1440x900 8 ,
