4-input 4K UHD Switching HDBaseT Transmitter
with USB host/device (4K: 100m/328ft)
SW-510-TX
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features before beginning the
installation process.

IMPORTANT! Installation Requirements

• Read through the
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
• Visit the product page to download the latest firmware, document version,
additional documentation, and configuration tools.

Information and Parts Required for Installation

This transmitter requires connection via RS-232 in order to configure
functions such as EDID. Ensure that the following items are on hand before
proceeding with the installation.
• PC or Mac
• Terminal software such as
PuTTY
• USB COM Port Adapter (Not Included)
• WyreStorm Part: CAB-USB-3PIN
• Latest version of the
SW-510-TX API
not covered in this document.
Note: IP control is only possible when the SW-510-TX and SW-515-
RX are used as a kit. The web server exists only in the RX.

Basic Wiring Diagram

Personal Computer
USB
Mic/Speaker
Deskplate
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
SW-510-TX Quickstart Guide | 200817
section for important wiring
for advanced configuration
Laptop
Local Monitor

In the Box

1x SW-510-TX Transmitter
1x 12V 2A DC Power Supply (US/UK/EU/AU)
1x IR Receiver
2x Mounting Brackets
1x 3-pin Screw Down Phoenix Connector
1x 4-pin Screw Down Phoenix Connector
1x Quickstart Guide (This Document)
12V DC 2A
Power Supply
SW-515-RX
1 of 4
Quickstart Guide
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
support@wyrestorm.com
KEY
HDMI/DisplayPort/USB-C
HDBaseT/Ethernet
RS-232/Relay
Analog Audio
Analog Video
USB 2.0
