Wyrestorm TX-35-IWC-KVM Quick Start Manual

Usb-c single gang in-wall hdbaset transmitter

Download this manual

USB-C Single Gang In-Wall

HDBaseT Transmitter

TX-35-IWC-KVM

WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the

installation process.

IMPORTANT! Installation

• Read through the

Wiring and Connections

guidelines before creating or choosing premade cables.

• Visit the product pages to download the latest firmware, document version,

additional documentation, and configuration tools.

Basic Wiring Diagram

TX-35-IWC-KVM Quickstart Guide | 241003

section for important wiring

wyrestorm.com

In the Box

1x TX-35-IWC-KVM

1x 2 pin Phoenix Male Connector

1x 3-pin Phoenix Male Connector

1 x Wall Plate Decora Panel (1-Gang US) with Screws

1x 2m USB 3.2 Type-C to Type-C Cable

1x Quickstart Guide (This Document)

INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)

1 of 4

Quickstart Guide

support@wyrestorm.com

Need help?

Do you have a question about the TX-35-IWC-KVM and is the answer not in the manual?

Page 1 USB-C Single Gang In-Wall HDBaseT Transmitter TX-35-IWC-KVM Quickstart Guide WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In the Box IMPORTANT! Installation 1x TX-35-IWC-KVM • Read through the...
Page 2 RS232 DIP Switch • UPDATE: The RS232 port is used to upgrade Valens firmware of transmitter and receiver. Copyright © 2024 WyreStorm ProAV Corporation | Copyright © 2024 WyreStorm ProAV Corporation | wyrestorm.com wyrestorm.com INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)
Page 3 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the transmitter. Read through this section in its entirety before running or terminating any wires to ensure proper operation and to avoid damaging the equipment.
Page 4 Safety and Emission CE | FCC | RoHS | RCM | EAC | UKCA Note: WyreStorm reserves the right to change product specification, appearance or dimensions of this product at any time without prior notice. Warranty Information WyreStorm Technologies ProAV Corporation warrants that its products to be free from defects in material and workmanship under normal use for a period of five (5) years from the date of purchase.
