Wyrestorm Synergy SW-120-TX3-US Quick Start Manual

Synergy™ 2-Input 4K60Hz HDBaseT™ 3.0 In-Wall Transmitter
SW-120-TX3-US | SW-120-TX3-UK
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior
to starting the installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
• Read through the Wiring and Connections
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
Basic Wiring Diagram
SYN-KEY10
Tablet
BYOD
SYN-TOUCH10
LAN
SW-120-TX3-US
Network Switch
Sygma Cloud Management
Dante Network Switch
Copyright © 2023 WyreStorm ProAV Corporation |
SW-120-TX3-Ux Quickstart Guide | 231101
section for important wiring
Personal
Computer
SW-120-TX3-US
UC Codec
Document
Camera
Laptop
Local Monitor
Keyboard and Mouse
wyrestorm.com
In the Box
1x SW-120-TX3-US/SW-120-TX3-UK In-Wall Transmitter
1x 1.8m USB2.0 Type-B to Type-A cable
1x 2m USB-C to USB-C Cable with Locking Connector (5Gbps)
1x 3-pin Terminal Block
1x 2-pin Terminal Block
1x Wall Plate (2-gang US) - (US model only)
4x Mounting Screws
1x Quickstart Guide (This Document)
*20v 6a PSU Sold Separately
RX3-100
Short Throw
Projector
ROOM 2
NHD-500-TX
NHD-500-RX
CAM-210-PTZ
Boundary
Mics
Capture
Card PIR Sensor
1 of 4
Quickstart Guide
Amplifier
KEY
USB Camera
Laptop
Display Device
Network Switch
Ceiling Speakers
Ceiling Speakers
RX3-100
Projector
Display Device
INT: +44 (0) 1793 230 343 | US: 844.280.WYRE (9973)
HDMI/USB-C
HDBaseT
RS-232
Analog Audio
USB
RX3-100
