4K UHD HDBaseT 1-Gang In Wall Transmitter
(4K: 35m/115ft | 1080p: 70m/230ft)
TX-35-IW
WyreStorm recommends reading through this document in its entirety to become familiar with the product's features prior to starting the
installation process.
IMPORTANT! Installation Requirements
• Visit the product page to download the latest firmware, document
version, additional documentation, and configuration tools.
• Read through the
guidelines before creating or choosing premade cables.
• While this product supports CEC, WyreStorm cannot guarantee
compatibility with all forms of CEC communication.
Basic Wiring Diagram
Laptop
Copyright © 2020 WyreStorm Technologies |
TX-35-IW Quickstart Guide | 201112
section for important wiring
TS-280-US
TX-35-IW
wyrestorm.com
In the Box
1x 2 pin Phoenix Male Connector
2x 3 pin Phoenix Male Connector
1x 1-Gang Decora Wall Plate
Device powers via PoH (12V 2A DC PSU Sold Separately)
1x Quickstart Guide (This Document)
RX-35-POH
KEY
HDMI
HDBaseT
Control
1 of 4
Quickstart Guide
4K UHD Display
IR Emitter
IR Receiver
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
support@wyrestorm.com
Advertisement
Table of Contents
Related Manuals for Wyrestorm TX-35-IW
Summary of Contents for Wyrestorm TX-35-IW
- Page 1 4K UHD HDBaseT 1-Gang In Wall Transmitter (4K: 35m/115ft | 1080p: 70m/230ft) Quickstart Guide TX-35-IW WyreStorm recommends reading through this document in its entirety to become familiar with the product’s features prior to starting the installation process. In the Box IMPORTANT! Installation Requirements 1x 2 pin Phoenix Male Connector •...
- Page 2 3-pin phoenix for passthrough to RX Link LED Off: No link with receiver or receiver powered Copyright © 2020 WyreStorm Technologies | wyrestorm.com UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973) 2 of 4 TX-35-IW Quickstart Guide | 201112...
- Page 3 Wiring and Connections WyreStorm recommends that all wiring for the installation is run and terminated prior to making connections to the switcher. Read through this section in it’s entirety before running or terminating the wires to ensure proper operation and to avoid damaging equipment.
- Page 4 4096x2160p @60Hz 8bit 4:2:0 5m/16ft 35m/115ft 35m/115ft Note: WyreStorm recommends the use of shielded category cable to minimize signal noise and interference. Supported Standards DCI | RGB | HDR10 | BT.2020 Audio Formats 2ch PCM | Multichannel LPCM | DTS-X and Dolby Atmos...
