2-1 FRONT PANEL
o ο 0 0 O
© TUNING CONTROL
- Changes the operating frequency. (p. 12)
- Changes the memory channel. (p. 22)
- Changes contents of the SET mode
display. (p. 10)
© TONE SWITCH [T/T SOL]
- Turns ON and OFF the subaudible tone
encoder. (p. 18)
- Selects the optional UT-40 functions.
(pgs. 35, 36)
Q SET SWITCH [SET]
Selects SET mode and advances the SET
mode displays. (p. 10)
PUSH
f£ ———
MAIN oiSPLAY -—— — ——À
[—————— SUB οιδριαν---------
Y?
mc rnin
ir ee EE
a
VOL -® SQL
PUSH-ON
POWER
PANEL DESCRIPTIO
nnn
445.289
+ SUB VOL -® SOL
ο
ICOM IC-2400A
VHF/UHF ο — o0
DUAL BAND FM TRANSCEIVER
O c 0
©
. o ο (©)
SUB
PRIO
HI/LO
YY |
2 2 = eae en
| |
© MAIN BAND CALL CHANNEL
SWITCH [CALL M] (IC-2400A/E)
Selects a MAIN band call channel.
(p. 24)
Θ SUB BAND VOLUME [SUB VOL]
- Opens the MAIN band squelch while
being pushed. (p. 15)
© MICROPHONE CONNECTOR
Connects the supplied microphone or
another suitable microphone. (p. 5)
