MULTI-PATH POWER
Circ1ATS Series
High Voltage AC Automatic
Transfer Switches
Models Include:
Circ1ATS
- High Voltage AC Automatic Transfer Switch (Board Only).
Circ1ATSE
- High Voltage AC Automatic Transfer Switch in Enclosure.
Installation Guide
Rev. 021825
Installing Company: _______________ Service Rep. Name: __________________________________
Address: _____________________________________________ Phone #: __________________
MULTI-PATH POWER
More than just power.
TM
Advertisement
Related Manuals for Altronix Circ1ATS Series
Summary of Contents for Altronix Circ1ATS Series
- Page 1 MULTI-PATH POWER MULTI-PATH POWER Circ1ATS Series High Voltage AC Automatic Transfer Switches Models Include: Circ1ATS - High Voltage AC Automatic Transfer Switch (Board Only). Circ1ATSE - High Voltage AC Automatic Transfer Switch in Enclosure. Installation Guide More than just power.
- Page 2 Overview: Altronix Circ1ATS Series are High Voltage Redundant automatic transfer switches that can be added to any Altronix power supply with a high voltage input. Circ1ATS accepts connections from two (2) independent high voltage AC sources (Primary and Secondary) and provides a single redundant High Voltage AC Output. If AC Power is lost on the Primary input, the Circ1ATS automatically transfers to the Secondary AC Power input without delay, ensuring that system security is maintained.
- Page 3 Relay normally energized when AC power is present. Contact rating 1A @ 28VDC. LED Diagnostics: Primary Secondary Power Supply Status Blinking Primary input power source is used. Blinking Secondary input power source is used. Circ1ATS Series Installation Guide - 3 -...
- Page 4 3.55” (90.2mm) 0.1” (2.54mm) 1.5” (38.1mm) Altronix is not responsible for any typographical errors. –––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––––– 140 58th Street, Brooklyn, New York 11220 USA | phone: 718-567-8181 | fax: 718-567-9056 website: www.altronix.com | e-mail: info@altronix.com | Lifetime Warranty IICirc1ATS Series B18Y...
