Saluki S3532 Series User Manual

Spectrum analyzer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
S3532/S3533 Series
Spectrum Analyzers
User Manual
（Applies to S3532A、S3532B、S3533A、S3533B）

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S3532 Series and is the answer not in the manual?

Questions and answers

Related Manuals for Saluki S3532 Series

Summary of Contents for Saluki S3532 Series

  • Page 1 S3532/S3533 Series Spectrum Analyzers User Manual （Applies to S3532A、S3532B、S3533A、S3533B）...

  • Page 2: Table Of Contents

    S3532/S3533 Series Spectrum Analyzer User Manual Catalog General Safety Summary ..........................1 Daily care and cleaning ..........................3 Safety Terms and Symbols ......................... 4 Work Environment ............................Temperature ............................5 Relative humidity ..........................5 Altitude ............................... 5 Ventilation and heat dissipation requirements ................... 5 Electrostatic Requirements .........................
  • Page 3 S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.17 SPAN .......................... 35 3. 1.18 Sweep ......................... 36 3.1.19 System ........................37 3.1.20 Trace ........................... 40 3. 1.21 Trig..........................40 3.2 Menu Introduction ........................41 3.3 Menu Description ........................52 3.3. 1 FREQ ......................... 52 3.3.2 SPAN ..........................

  • Page 4: General Safety Summary

    S3532 / S3533 Series Spectrum Analyzer User Manual Security Requirement General Safety Summary Understand the following safety precautions to avoid injury and prevent damage to this product or any products connected to it. To avoid possible danger, be sure to use this product in accordance with regulations.
  • Page 5 S3532 / S3533 Series Spectrum Analyzer User Manual If you suspect that the product is faulty, please contact a maintenance personnel authorized by SALUKI for inspection. Any maintenance, adjustment or parts replacement must be performed by maintenance personnel authorized by SALUKI. Unauthorized disassembly will result in the warranty period being void.

  • Page 6: Daily Care And Cleaning

    S3532 / S3533 Series Spectrum Analyzer User Manual Daily care and cleaning General Maintenance Do not place the instrument in a place exposed to sunlight for a long time. Please store the instrument in a cool and dry place if it is not used for a long time. Be careful Do not allow any corrosive liquid to stick to the instrument to avoid damaging it.

  • Page 7: Safety Terms And Symbols

    S3532 / S3533 Series Spectrum Analyzer User Manual Safety terms and Symbols Terms in this manual. The following terms may appear in this manual Warning Statement identifies conditions and actions that could endanger the life of operators. Notice Statement identifies conditions and actions that could cause damage to the product or loss of data.

  • Page 8: Work Environment

    S3532 / S3533 Series Spectrum Analyzer User Manual Work Environment Temperature  Working ambient temperature:0℃~+40℃  Storage temperature:-30℃~+70℃ Relative humidity  ≥+10℃, humidity ≤95%RH  ≥+30℃, humidity ≤75%RH  ≥+40℃, humidity ≤45%RH Altitude  0～4600 m Note: The above three working environment requirements are only for the instrument operating environment and are not technical indicators.

  • Page 9: Confirm The Power Supply

    S3532 / S3533 Series Spectrum Analyzer User Manual Confirm the power supply Mainland China must meet the following requirements:  Voltage：AC220±10%  Frequency：50～60Hz Preventing mutual interference through power supply To prevent multiple devices, especially instruments and high-power devices, from being connected to the same power grid, it is recommended to use an AC regulated power supply to power the instrument, as the pulse interference generated by the high- power devices may cause the instrument to malfunction or even be damaged.

  • Page 10: Users Must Read

    1. Users must rea Welcome to use the S3532 / S3533 series spectrum analyzer produced by SALUKI! Please check and verify the items in the package according to the following steps after unpacking, and read the "Precautions before Powering on" section of this manual before use, so as to find problems as early as possible and prevent accidents.

  • Page 11: Power Cord Selection

    S3532 / S3533 Series Spectrum Analyzer User Manual when it is working normally. In order to prevent or reduce the mutual interference caused by multiple devices through the power supply, especially the spike pulse interference generated by high- power devices, which may cause damage to the spectrum analyzer hardware, it is best to use a 110V/220V AC regulated power supply.

  • Page 12: Initial Power-Up Of The Spectrum Analyzer

    S3532 / S3533 Series Spectrum Analyzer User Manual Correctly apply anti-static technology to reduce damage to components: 1) Before connecting the coaxial cable to the spectrum analyzer for the first time, briefly touch the inner and outer conductors of the cable to ground. 2) Workers must wear anti-static wrist straps before touching the connector core wires or doing any assembly.

  • Page 13: Quick Start

    S3532 / S3533 Series Spectrum Analyzer User Manual 2. Quick Start This chapter introduces the interface and user interface of the spectrum analyzer, the precautions for first-time use, and demonstrates its usage through a measurement example. 2.1 Front Panel Description ⑪...

  • Page 14: Front Panel Function Keys

    S3532 / S3533 Series Spectrum Analyzer User Manual Logo and product Numeric keypad area ⑥ ⑫ model 2.1.1 Front panel function keys Common function keys Cursor test key System function keys Figure 2-2 Front panel function keys Table 2-1 Brief description of function keys Function keys Functional Description Common function keys...
  • Page 15 S3532 / S3533 Series Spectrum Analyzer User Manual Parameter setting keys Set the resolution bandwidth and video bandwidth related parameters of the spectrum analyzer. Sweep Set the sweep mode. Trace Set the trace parameters of the sweep signal. Detector Set the detection method. AUTO Automatically locate the signal in the entire frequency band.
  • Page 16 S3532 / S3533 Series Spectrum Analyzer User Manual 2.1.2 Parameter input interfac Parameter input can be completed through the numeric keyboard, knob and direction keys. 1) Arrow keys Figure 2-3 Arrow keys The function of the direction keys is: when entering parameters, the up and down keys indicate that the parameter value increases or decreases in a certain step.

  • Page 17: Rear Panel Description

    S3532 / S3533 Series Spectrum Analyzer User Manual c) Confirm key: Used in the process of inputting parameters. Clicking this key will end the parameter input and add the default unit value to the parameter. 2.2 Rear Panel Description ① ② ③ ④ ⑦...

  • Page 18: Parameter Input Interface

    S3532 / S3533 Series Spectrum Analyzer User Manual 2.2.2 External 10MHz input The reference clock input is connected via a BNC cable. 2.2.3 Headphone port This port can be used to listen to the audio demodulation supported by the spectrum analyzer. 2.2.4 USB interface The spectrum analyzer can act as a "host device"...

  • Page 19: User Interface

    S3532 / S3533 Series Spectrum Analyzer User Manual 2.3 User Interface ③ ④ ⑦ ⑤ ⑥ ② ① ⑫ ⑪ ⑧ ⑩ ⑨ Figure 2-7 User Interface View...

  • Page 20: Basic Measurements

    S3532 / S3533 Series Spectrum Analyzer User Manual Table 2-4 User interface label description Item Description Display reference level Reference level ① Logarithmic scale display Display data output format logarithmic or linear ② Attenuation value Display RF attenuator value ③ Detection mode Display spectrum curve detection method ④...
  • Page 21 S3532 / S3533 Series Spectrum Analyzer User Manual Notice The input signal amplitude must not exceed +27 dBm (0.5W) to avoid damaging the spectrum analyzer. The measurement steps are as follows： 1) Connecting devices Connect the signal output of the signal generator to the RF input of the spectrum analyzer [RF IN 50Ω].
  • Page 22 S3532 / S3533 Series Spectrum Analyzer User Manual Figure 2-8 Measurement Signal View...

  • Page 23: Menu Description

    S3532 / S3533 Series Spectrum Analyzer User Manual 3. Menu Description This chapter provides a function map of the spectrum analyzer panel buttons and explains the meaning of each menu in detail. 3.1Menu Map This section provides a function map of the menu buttons on the spectrum analyzer panel in alphabetical order from A to Z.

  • Page 24: Ampt

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.1 AMPT AMPT Reference level Attenuator dBuW Automatic Manual Scale/division dBpW Scale type dBmV Linear Logarithmic Reference bias dBuV Reference units▼ Preamplification On Off 3.1.2 BW Resolution bandwidth Bandwidth Automatic Manual On Off Video Bandwidth 1MHz Automatic Manual...

  • Page 25: Demod

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.3 Demod Audio Audio Demod Demodulation Demodulation ▼ On Off Demodulation mode ▼ volume Radio Station ▼ return return Radio1 Radio2 Radio3 Radio4 Radio5 Radio6 return...

  • Page 26: Detector

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.4 Detector Detector Positive peak Negative peak Sampling Average 3.1.5 Display Full Screen Default Display Display Window Scaling WinXP On Off Display Line On Off Amplitude scale On Off Grid On Off Display Style▼...

  • Page 27: File

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.6 File Screen Refresh File image File Type▼ Trace data Home page Previous page Next page Last page Return File Operations▼ Sort▼ By name Delete▼ By time Export▼ By size Load Return Return Delete Select...

  • Page 28: Freq

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.7 FREQ FREQ Center frequency Start frequency End frequency Frequency step Automatic Manual Frequency offset Frequency reference Internal External 3.1.8 Marker Frequency Marker Marker 1 2 3 4 5 Traces 1 2 3 4 5 Normal Difference All Off...

  • Page 29: Marker

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.9 Marker → Frequency Marker marker→Center → frequency Frequency marker→Frequency step Frequency marker→Start frequency Frequency marker→Stop frequency Frequency marker→Reference level Frequency marker△→Sweep width Frequency marker△→ Center frequency 3.1.10 Marker Fctn Marker Function Off Fctn On Off Frequency...

  • Page 30: Meas

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.11 Meas Pass-Fail Meas Measurement off On Off Adjacent channel Field strength power measurement On Off On Off Channel Power On Off On Off Occupied Time spectrum bandwidth On Off On Off Carrier-to-Noise Ratio On Off...
  • Page 31 S3532 / S3533 Series Spectrum Analyzer User Manual Average Measurement number of Exponential Meas Meas times average Setup Adjacent Average state Repeated channel On Off average power Average On Off Mode▶ Channel Main channel Power bandwidth On Off Adjacent Occupied channel bandwidth bandwidth...
  • Page 32 S3532 / S3533 Series Spectrum Analyzer User Manual Average Exponential Meas times Measurement off Meas average Setup Average Adjacent channel Repeated Status power average On Off On Off Channel Power Average On Off Mode▶ Occupied Max Hold bandwidth On Off On Off Carrier-to-Noise Span setting...
  • Page 33 S3532 / S3533 Series Spectrum Analyzer User Manual Measurement off Pass-Fail Meas Meas On Off Adjacent channel Setup power Field strength On Off measurement On Off Channel Power On Off Occupied On Off bandwidth Time On Off spectrum Carrier-to-Noise On Off Ratio On Off Harmonic...
  • Page 34 S3532 / S3533 Series Spectrum Analyzer User Manual Window Window Pass- Fail Measurement measurement ▼ ▼ On Off Area Amplitude line measurement On Off ▼ Frequency Line On Off Amplitude Upper limit Lower limit frequency Start End Window Scan On Off return return Area...
  • Page 35 S3532 / S3533 Series Spectrum Analyzer User Manual Field strength Unit dBuV/m measurement uV/m▼ Antenna uV/m Selection▼ Antenna Factor Cable loss return return OA750 IMPORT DA800 none ANT01-1 ANT01-2 ANT01-3 ANT01-4 return return...

  • Page 36: Peak

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.13 Peak Maximum Peak Search Next Peak Left Peak Right Peak Minimum Search Frequency Marker → Center Frequency Peak Search On Off 3.1.14 Print Setup Print Paper size▼ Setup Print Language Pcl Esc Printer Type Black and White Color...

  • Page 37: Save

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.15 Save Save to Screenshots▼ Save to local Save Local Save to Save to Trace data▼ Flash Flash User Status Clear Parameters▼ Loading parameters▼ Keep return return Parameters▼ 3.1.16 Source Tracking Network Tracking Source source▼...

  • Page 38: Span

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.17 SPAN SPAN Span Full span Zero span Previous span...

  • Page 39: Sweep

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.18 Sweep Scan time Sweep Automatic Manual Single scan Continuous scan Scan points...

  • Page 40: System

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.19 System Chinese System System System Information▼ information English Configuration System log I/O▼ Power on/reset▼ Local Language▼ Date/Time ▼ Backlight adjustment return return Next Page Start User Date/Time calibration Calibration▼ Factory System Time reset Services▼...
  • Page 41 S3532 / S3533 Series Spectrum Analyzer User Manual Configuration network▼ IP address GPIB▼ Subnet Mask Serial Port ▼ Gateway Reset Network return return Baud rate▼ Data bits▼ Stop bits▼ check▼ Flow Control▼ Reset serial port ▼ return...
  • Page 42 S3532 / S3533 Series Spectrum Analyzer User Manual Power Power-on Factory on/reset parameters▼ Reset User parameters▼ return return Factory User return...

  • Page 43: Trace

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.1.20 Trace Traces Trace 1 ←→ 2 1 2 3 4 5 refresh 2-DL→ 2 Maximum 2 ←→ 3 hold Minimum 1 → 3 hold Blanking 2 → 3 Check return Trace operation▼...

  • Page 44: Menu Introduction

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.2Menu Introduction This section briefly describes the functions of the front panel keys and soft keys in a list format according to the menu structure: Table 3-1 Basic Function Description Function keys Access Keys Description ——...
  • Page 45 S3532 / S3533 Series Spectrum Analyzer User Manual [Trace averaging] Turn the trace averaging function on or off. When it is on, a 【BW】 On Off smooth trace is calculated through continuous averaging. [EMI Bandwidth▼] 【BW】 A soft menu about EMI bandwidth measurement pops up. [EMI Bandwidth] [EMI Bandwidth▼] Enable or disable EMI bandwidth measurement.
  • Page 46 S3532 / S3533 Series Spectrum Analyzer User Manual —— Pop up a display-related soft menu. 【Display】 [Full Screen Display the image in full screen mode. 【Display】 Display] [Window Scaling] Select the display line to change its display position. 【Display】 On Off [Display Line] When this menu is on, an adjustable horizontal reference 【Display】...
  • Page 47 S3532 / S3533 Series Spectrum Analyzer User Manual [Delete Selection] [delete▼] Delete only the selected files. [Delete this page] [delete▼] Delete only the files on the current page. [Delete All] [delete▼] Delete all stored files. [Export▼] [File Operations▼] Export files. [choose] [Export▼] Export only the selected files.
  • Page 48 S3532 / S3533 Series Spectrum Analyzer User Manual [Close All] Turn off all currently activated frequency marker functions, 【Marker】 and the frequency marker will no longer be displayed. [Frequency Marker Turn on or off the display of all frequency marker tables. 【Marker】...
  • Page 49 S3532 / S3533 Series Spectrum Analyzer User Manual Table 3-8 Basic Function Description (Continued) Function keys Access Keys Description [Channel Power] Enter the channel power measurement soft menu. 【Meas】 On Off [Occupied Enter the occupied bandwidth measurement soft menu. 【Meas】 bandwidth] On Off [Pass-Fail▼]...

  • Page 50: Number Of Copies

    S3532 / S3533 Series Spectrum Analyzer User Manual [Frequency Count] [Frequency Count ]Turn the frequency counter on or off (activate a frequency On Off marker). When the counter is on, the counting result is displayed. [Resolution [Frequency Count ]Set the counting resolution. bandwidth] Place the frequency marker at the highest point of the trace, 【PEAK】...
  • Page 51 S3532 / S3533 Series Spectrum Analyzer User Manual Table 3-11 Basic Function Description (Continued) Function keys Access Keys Description [Print Screen] Print all information on the screen. 【PrintSetup】 Pop up a soft menu related to saving the current interface 【Save】 ——...
  • Page 52 S3532 / S3533 Series Spectrum Analyzer User Manual [Normalization] [Network Network measurement user on-site normalization calibration. Measurement▼] [Signal source▼] Pop-up soft menu about signal source. 【Source】 [Signal source] [Signal Source▼] Turn on or off signal source output. On Off [Output frequency] [Signal Source▼] Set signal source output frequency. [Output power] [Signal Source▼] Set signal source output power.
  • Page 53 S3532 / S3533 Series Spectrum Analyzer User Manual [GPIB▼] [Configuration Pop up the soft menu for GPIB port settings. I/O▼] [Serial port▼] [Configuration Pop up the soft menu for serial port settings. I/O▼] [Baud rate▼] [Serial port▼] Pop up the soft menu for baud rate settings. [Data bit▼] [Serial port▼] Pop up the soft menu for baud rate settings.
  • Page 54 S3532 / S3533 Series Spectrum Analyzer User Manual On Off Pop up a soft menu related to trace and detection. 【Trace】 —— [Traces] Select the currently operable trace register. 【Trace】 1 2 3 4 5 [Refresh] Refresh the current curve. 【Trace】...

  • Page 55: Menu Description

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3Menu Description 3.3.1 FREQ Set various frequency parameters of the spectrum analyzer. The spectrum analyzer performs frequency sweep within the set frequency range. Whenever the frequency parameters are changed, the frequency sweep is restarted. There are two ways to indicate the frequency range of the current channel of the spectrum analyzer: start frequency/end frequency, center frequency/span.
  • Page 56 S3532 / S3533 Series Spectrum Analyzer User Manual In zero span mode, the start frequency, center frequency, and stop frequency have the same  value and will be modified together. You can use the numeric keys, knob, and arrow keys to modify this parameter. ...

  • Page 57: Frequency Offset

    S3532 / S3533 Series Spectrum Analyzer User Manual This function is very useful for quickly adjusting the center frequency to the harmonic of the input signal. For example: Observe the harmonics of a 300MHz input signal, set [Frequency Step Automatic Manual] to Manual, and enter 300MHz. If the center frequency is 300MHz at this time, press the step increment key to change the center frequency to 600MHz, which is equal to the second harmonic.

  • Page 58: Ampt

    S3532 / S3533 Series Spectrum Analyzer User Manual When changing the span in non-zero span mode, if the frequency step and RBW are i  automatic mode, the frequency step and RBW will be automatically modified, and the modification of RBW will cause the change of VBW (in automatic mode). Changing any one of the span, RBW and VBW will cause the change of sweep time.
  • Page 59 S3532 / S3533 Series Spectrum Analyzer User Manual You can use the numeric keys, knob, and arrow keys to modify this parameter.  The reference level corresponds to the top of the coordinate grid. The accuracy of measuring signals close to the reference level is relatively good, but the input signal amplitude cannot be greater than the reference level during the measurement process;...
  • Page 60 S3532 / S3533 Series Spectrum Analyzer User Manual △ Notice The minimum setting value of the input attenuator in the "auto coupling" state is 10dB; if the user input power is less than -10dBm and the reference level is set less than or equal to - 10dBm (preamplifier off), the input attenuator value can be set to 0dB in "manual mode".
  • Page 61 S3532 / S3533 Series Spectrum Analyzer User Manual Key points  This value does not change the position of the curve, but only modifies the reference level and the amplitude reading of the cursor.  You can modify this parameter with the numeric keys. ...

  • Page 62: Auto

    S3532 / S3533 Series Spectrum Analyzer User Manual Warning When measuring high-power signals or unknown signal power, please turn off the preamplifier, otherwise the preamplifier or mixer may be burned out. 3.3.4 AUTO Automatically search for signals in the entire frequency band and adjust the frequency and amplitude parameters to the optimal state, realizing signal search and automatic parameter setting with one click.

  • Page 63: Sweep

    S3532 / S3533 Series Spectrum Analyzer User Manual Key points:  Reducing the video bandwidth can make the spectrum smoother, thus highlighting the small signal buried in the noise, but it will also cause the sweep time to be longer (when the sweep time is automatic, it is affected by the resolution bandwidth and video bandwidth together).

  • Page 64: Continuous Scan

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.6.2 [Single scan] Set the scan to single scan. 3.3.6.3 [Continuous Scan] Set the scan to continuous scan. 3.3.6.4 [Scan Points] Set the number of points obtained in each scan, that is, the number of points of the current trace.

  • Page 65: Trace

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.7. [Rising edge] Set the trigger to external rising edge trigger. 3.3.7.5 [Falling edge] Set the trigger to external falling edge trigger. 3.3.8 Trace The sweep signal is displayed on the screen as a trace. This menu can be used to set the trace- related parameters.
  • Page 66 S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.8. [Blanking] Clear the trace on the screen. But the content in the trace register remains the same and is not refreshed. 3.3.8.6 [Check] Displays the contents of the current trace without refreshing it for easier observation and reading. 3.3.8.7 [Trace operation▼] A soft menu related to trace operation pops up.

  • Page 67: Detector

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.8.12 [2 → 3] Move the contents of trace register 2 into trace register 3 and put trace 3 into display mode. 3.3.9 Detector When displaying a larger span, one pixel contains the spectrum information of a relatively large sub-segment, that is, multiple sampling points will fall on one pixel.

  • Page 68: Display

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.9.3 [Positive peak] Select the positive peak detection mode. In this mode, the detector selects the maximum value in the sampled data segment and displays it on the corresponding pixel point. The positive peak detector is selected when [Max Hold] is selected.

  • Page 69: Meas And Meas Setup

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.10.5 [Grid On Off] Set the screen grid to on or off. 3.3.10.6 [Display Style▼] Set the display style to default or WinXP mode. 3.3.10.7 [Tags On Off] Enable or disable the on-screen grid. 3.3.11 Meas and Meas Setup Provides a variety of advanced measurement functions, including: time spectrum, adjacent channel power, channel bandwidth and occupied bandwidth.
  • Page 70 S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.11.4 [Channel Power On Off Turn on or off the channel power measurement. Press [Measurement Settings] to pop up the parameter setting soft menu of channel power measurement. Channel power is used to measure the transmitter channel power.
  • Page 71 S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.11.11 [Amplitude Upper limit Lower limit] Set the upper and lower limits of the amplitude line. 3.3.11.12 [Frequency Start Stop] Set the start and end values of the frequency line. 3.3.11.13 [Window Scan On Off] Turn window scanning on or off.

  • Page 72: Marker

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.11.19 [Online Edit▼ Upper line editing is used to edit the control line above the trace according to the specific situation of the trace. 3.3.11.20 [Offline Edit▼] Upper line editing is used to edit the control line below the trace according to the specific situation of the trace.
  • Page 73 S3532 / S3533 Series Spectrum Analyzer User Manual If there is already a frequency marker, this command will not produce any action. If there are already two frequency markers (e.g. in [Frequency Marker Difference] mode), [Frequency Marker] changes the active frequency marker to the new single frequency marker. Amplitude and frequency information (time information when the span is 0Hz) are available from the frequency marker, and these values are displayed in the active function area and in the upper right corner of the screen.

  • Page 74: Marker Fctn

    S3532 / S3533 Series Spectrum Analyzer User Manual Key points ：  If there is an active cursor, a reference cursor is activated at the current cursor, otherwise both the reference cursor and the difference cursor are activated at the center frequency.

  • Page 75: Marker

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.13.2 [NdB On Off] Enable the NdB bandwidth measurement function. NdB bandwidth refers to the frequency difference between two points with a drop (N<0) or increase (N>0) of N dB to the left and right of the current cursor frequency point.
  • Page 76 S3532 / S3533 Series Spectrum Analyzer User Manual When the "Frequency Marker Difference" cursor is selected, the center frequency step is  set to the frequency at the difference cursor.  This function is invalid in zero span. 3.3.14.3 [Frequency marker → start frequency] Set the start frequency of the spectrum analyzer according to the frequency at the current cursor.

  • Page 77: Peak

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.15 Pea Open the peak search setup menu and execute the peak search function. Key points： When "Maximum" is selected in the peak search option, the maximum value on the trace is ...

  • Page 78: File

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.15.6 [Frequency Marker → Center Frequency] Set the center frequency to be equal to the frequency marker frequency. This function can quickly move the signal to the center of the screen. 3.3.15.7 [Peak Search On Off] Set the peak search mode, the default is off.

  • Page 79: System

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.18 System System-related operations: system information, I/O configuration, power on/reset, local language, date and time, backlight adjustment, user calibration, and system services, etc. 3.3.18.1 [System Information▼] View system information or recent messages. 3.3.18.2 [System Information] System information includes the following information: serial number, device model, software version, firmware version, temperature, local network, IP address, subnet mask, gateway,...

  • Page 80: Power-On Reset

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.18.8 [Gateway Used to set the gateway address parameters. 3.3.18.9 [Reset Network] Used to reset the network settings. 3.3.18.10 [GPIB] Pop up the GPIB settings soft menu. 3.3.18.11 [Serial Port▼] Pop up the serial port settings soft menu, including baud rate, data bit, stop bit, check, flow control, and reset serial port.

  • Page 81: Date Settings

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.18.16 [Date/Time▼] Used to set the instrument date, time, and date and time format. 3.3.18.17 [Date Settings] Set the date displayed on the spectrum analyzer. The date input format is: YYYYMMDD. For example, October 1, 2009 is marked as: 20091001.

  • Page 82: Print Setup

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.18.23 [75Ω Impedance Compensation On Off] Turn on or off the 75Ω impedance compensation function according to test needs. 3.3.19 Print Setup Set relevant parameters for printing. The spectrum analyzer supports HP printers. 3.3.19.1 [Paper size▼] Used to select the paper size for printing, including A4, A3, B5, C5, and envelopes.

  • Page 83: Source

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.20 Sourc Pop up the soft menu related to the tracking source measurement. 3.3.20.1 [Tracking Source On Off] The RF output and spectrum reception are completely synchronized in the frequency sweep, and the tracking source frequency cannot be set separately. 3.3.20.2 [Output Power] The tracking source power output range is 0 dBm to -30 dBm.

  • Page 84: Signal Source

    S3532 / S3533 Series Spectrum Analyzer User Manual 3.3.20.8 [Signal Source▼] Pop up the soft menu of signal source settings. 3.3.21 Demod Enter the demodulation settings. This spectrum analyzer supports AM, FM and FWM, which are off by default. 3.3.21.1 [Audio Demodulation▼] Pop up the audio demodulation soft menu.

  • Page 85: Measurement Applications

    S3532 / S3533 Series Spectrum Analyzer User Manual 4. Measurement Applications This chapter introduces the functions and usage of spectrum analyzers through examples. The contents of this chapter are as follows: Continuous wave signal measurement  Using resolution bandwidth to resolve closely spaced signals ...
  • Page 86 S3532 / S3533 Series Spectrum Analyzer User Manual b) Setting parameters  Press the [FREQ] key,  Press [Center Frequency], enter 1GHz;  Press the [SPAN] key,  Press [Span], enter 2MHz; c) Using cursors to measure frequency and amplitude ...

  • Page 87: Using Resolution Bandwidth To Resolve Closely Spaced Signals

    S3532 / S3533 Series Spectrum Analyzer User Manual 4.2 Using resolution bandwidth to resolve closely spaced signals Resolution bandwidth description: The signal resolution is determined by the bandwidth of the intermediate frequency (IF) filter, i.e., the resolution bandwidth. When a signal passes through the IF filter, the spectrum analyzer uses the signal to scan the bandpass shape of the IF filter.
  • Page 88 S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-2 1kHz resolution bandwidth 3) Measurement results a) Reduce the resolution bandwidth to 500Hz.  Press the [BW] key,  Press [Resolution Bandwidth Auto Manual], set the resolution bandwidth to manual, and enter 500Hz.

  • Page 89: Measurement Steps To Distinguish Two Unequal Amplitude Signals

    S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-3 100Hz resolution bandwidth 4.2.2 Measurement steps to distinguish two unequal amplitude signals This example is to distinguish two unequal amplitude signals with a frequency difference of 50kHz and an amplitude difference of about 40dB. To distinguish two unequal amplitude signals, the resolution bandwidth must be smaller than the frequency interval of the two signals (the same as distinguishing two equal amplitude signals).
  • Page 90 S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-4 Bandwidth and rectangular coefficient 1) Device Connection Connect the RF input port of the spectrum analyzer to two signal sources through a combiner. Set the frequency of one source to 1800MHz and the amplitude to -10dBm; the frequency of the other source to 1800.005MHz and the signal output amplitude to -40dBm, and turn on the RF output of both signal sources.
  • Page 91 S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-5 Test with 50kHz resolution bandwidth setting a) Reduce the resolution bandwidth and observe the submerged small signal.  Press the [BW] key,  Press [Resolution bandwidth Auto Manual], set the resolution bandwidth to manual, and enter 500Hz;...

  • Page 92: N Db Bandwidth Measurement

    S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-6 Test with 1kHz resolution bandwidth setting 4.3 N dB Bandwidth measurement The following example uses a signal generator (Agilent N5183B) to output a 500MHz, -10dBm continuous wave signal as the measured signal. Operation steps: 1) Equipment connection Connect the signal output of the signal generator to the RF input on the front panel of the...
  • Page 93 S3532 / S3533 Series Spectrum Analyzer User Manual b) Set parameters  Press [FREQ] key,  Press [Center Frequency] and enter 500MHz;  Press [SPAN] key,  Press [Span] and enter 1 MHz;  Press [BW] key,  Press [Resolution bandwidth Auto Manual], set the resolution bandwidth to manual, and enter 30kHz.

  • Page 94: Adjacent Channel Power Measurement

    S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-7 N(3)dB bandwidth measurement results 4.4 Adjacent channel power measurement In the following example, a signal generator (Agilent N5183B) is used to output a 1 GHz, -10 dBm continuous wave signal as the measured signal. Operation steps: 1) Equipment connection Connect the signal output of the signal generator to the RF input on the front panel of the...

  • Page 95: Channel Power Measurement

    S3532 / S3533 Series Spectrum Analyzer User Manual b) Set parameters  Press the [FREQ] key,  Press [Center Frequency] and enter 1 GHz;  Press the [Meas] key,  Press [Adjacent Channel Power On Off] to set the adjacent channel power on. 3) Read the measurement result The measurement results are displayed in the lower half of the split screen window, as shown in Figure 4-8.
  • Page 96 S3532 / S3533 Series Spectrum Analyzer User Manual Operation steps: 1) Equipment connection Connect the signal output of the signal generator to the RF input of the spectrum analyzer panel. 2) Use channel power to measure signal power a) Reset the instrument ...

  • Page 97: Occupied Bandwidth Measurement

    S3532 / S3533 Series Spectrum Analyzer User Manual 4.6 Occupied bandwidth measurement In the following example, a signal generator (Agilent N5183B) is used to output a 500 MHz, - 10dBm continuous wave signal as the measured signal. Operation steps: 1) Equipment connection Connect the signal output of the signal generator to the RF input on the front panel of the spectrum analyzer.

  • Page 98: Using A Preamplifier For Small Signal Measurements

    S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-10 Occupied bandwidth measurement results 4.7 Using a preamplifier for small signal measurements In the following example, a signal generator (Agilent N5183B) is used to output a 500 MHz, - 120 dBm continuous wave signal as the measured signal. Operation steps: 1) Equipment connection Connect the signal output of the signal generator to the RF input on the front panel of the...
  • Page 99 S3532 / S3533 Series Spectrum Analyzer User Manual b) Set parameters  Press [FREQ] key,  Press [Center Frequency], enter 500 MHz;  Press [SPAN] key,  Press [Span], enter 1KHz;  Press [AMPT] key,  Press [Reference Level], enter -120dBm. ...

  • Page 100: Harmonic Distortion Measurements

    S3532 / S3533 Series Spectrum Analyzer User Manual 4.8 Harmonic distortion measurements In the following example, a signal generator (Agilent N5183B) is used to output a 500 MHz, 0 dBm continuous wave signal as the measured signal. Operation steps: 1) Equipment connection Connect the signal output of the signal generator to the RF input on the front panel of the spectrum analyzer.

  • Page 101: Am Modulated Signal Measurement

    S3532 / S3533 Series Spectrum Analyzer User Manual 4.9 AM Modulated signal measurement The demodulation function of the spectrum analyzer can be used to T h eAM modulated signal is demodulated from the carrier signal and is displayed on the screen.

  • Page 102: Signal Frequency Measurement Using A Frequency Counter

    S3532 / S3533 Series Spectrum Analyzer User Manual  according to [Difference];  Press 【 Peak 】 key,  according to [Next Peak]; you can also press [ Peak key [Right Peak] or [Left peak], check Find the peak on the right or left; read the frequency value of the cursor, which is the frequency of the modulating signal.
  • Page 103 S3532 / S3533 Series Spectrum Analyzer User Manual 4.10 Signal frequency measurement using a frequency counter In order to measure the signal frequency more accurately, the spectrum analyzer provides a frequency counter function. Compared with cursor measurement, It can measure the signal frequency more accurately. In the following example, a signal generator (Agilent E 4421B ) Output 500 MHz , -10 dBm The continuous wave signal is taken as the measured signal.

  • Page 104: Third-Order Intermodulation Distortion Measurement

    S3532 / S3533 Series Spectrum Analyzer User Manual  according to [Frequency Count On/Off] key, set the frequency count to on. The frequency of the signal is displayed in the area and the upper right corner of the screen. Users can set the frequency counter as needed.
  • Page 105 S3532 / S3533 Series Spectrum Analyzer User Manual The signal generator 1 The output signal of the signal generator 2 is connected to the front of the spectrum analyzer through a combiner. RF input terminal of the panel. 2) Using the cursor function to measure frequency and amplitude e) Reset the instrument ...
  • Page 106 S3532 / S3533 Series Spectrum Analyzer User Manual Figure 4-15 Third-order intermodulation distortion measurement...

  • Page 107: Remote Control

    Instruments ) For detailed instructions on commands and programming, refer to the "Programming Manual". Users can also use the host computer software provided by SALUKI SA Remote Control , Send commands to remotely control the spectrum analyzer. This spectrum analyzer can LAN Interface and PC This chapter will...

  • Page 108: Troubleshooting And Repair

    S3532 / S3533 Series Spectrum Analyzer User Manual 6. Troubleshooting and repair This chapter lists the common faults that may occur during the use of the spectrum analyzer and their troubleshooting methods. The content is as follows:  The spectrum analyzer screen remains black after powering on. ...

  • Page 109: Fault Diagnosis And Troubleshooting

    S3532 / S3533 Series Spectrum Analyzer User Manual 6.1 Fault diagnosis and troubleshooting 6.1.1 The spectrum analyzer screen remains black after powering on: 1) Check if the fan is spinning: a) If the fan is spinning normally, the display cable may be loose. b) If the fan does not rotate, the machine did not start properly.

  • Page 110: The Amplitude Of The Signal Is Not Displayed Accurately

    S3532 / S3533 Series Spectrum Analyzer User Manual 6.1.5 The amplitude of the signal is not displayed accurately: If the signal amplitude is not displayed accurately, please check it as follows: 1) Check whether the input signal amplitude is correct. If so, refer to step (2) or (3) for processing.

  • Page 111: Performance Indicators

    S3532 / S3533 Series Spectrum Analyzer User Manual 7. Performance Indicators This chapter lists the technical specifications and general technical specifications of the spectrum analyzer . Technical Index The following conditions apply:  The instrument has been preheated before use30 minutes. ...
  • Page 112 S3532 / S3533 Series Spectrum Analyzer User Manual Frequency Deviation 100kHz -100dBc/Hz Frequency Deviation 1MHz -115dBc/Hz Note: Typical fc=500MHz, sampling detection, trace averaging times ≥10 Scan time Non-zero span 3ms to 3000s Zero span 1ms to 3000s Scan Mode Continuous, Single trigger Trigger source Free, Video, External...
  • Page 113 S3532 / S3533 Series Spectrum Analyzer User Manual 10/100 Base-T, RJ-45 Connectors RS232 9 Pinout D-SUB (male) Reference Input/Output 10MHz, BNC Vulva Input Power 0dBm to +10dBm Output Power 0dBm±2dB 800*600, 60Hz, 15 Pinout D-SUB (female) External trigger input 5 V TTL Level (±10V, 100 mA maximum) FM/AM Audio Headphone jack Demodulation...
  • Page 114 S3532 / S3533 Series Spectrum Analyzer User Manual 10 MHz to 2 GHz <-133 dBm 2 GHz to 3.4 GHz <-130 dBm 3.4 GHz to 5 GHz <-133 dBm 5 GHz to 7.5 GHz <-127 dBm 100kHz to 1MHz <-110dBm-3×(f/100kHz)dB 1MHz to 10MHz <-140dBm Preamp On 10 MHz to 2 GHz <-148 dBm...
  • Page 115 S3532 / S3533 Series Spectrum Analyzer User Manual TOI (Third Order >30MHz +10dBm Distortion) SHI (Second Order +40dBm Distortion) >10MHz Input Related Spurious <-60dBc Signals Remaining Responses <-85dBm Tracking signal generator (option) Frequency range 100kHz to 3.2GHz Output Power -30dBm to 0dBm 1dB Stepping Output flatness Tracking Generator (100kHz to 3.2GHz) ±3dB Input/Output...
  • Page 116 S3532 / S3533 Series Spectrum Analyzer User Manual (10MHz) High stability time Aging rate: <0.2ppm/year, Temperature drift: <0.1ppm (15℃ to 35℃) base option Resolution Bandwidth (RBW) scope 1Hz to 5MHz, 1, 3, 5 Stepping Selectivity (60dB/3dB) RBW≤1MHz <5:1 typical (digital implementation, close to Gaussian shape) Accuracy <10% (<5% typical) Video Bandwidth (VBW)
  • Page 117 S3532 / S3533 Series Spectrum Analyzer User Manual 10MHz Maximum safe input Average +27dBm level continuous power Maximum DC input 50Vdc voltage Input attenuator range 0 to 30dB, step size 1dB Spurious and Residual Responses TOI (Third Order >30MHz +7dBm Distortion) SHI (Second Order +40dBm...
  • Page 118 S3532 / S3533 Series Spectrum Analyzer User Manual S3533B Technical Specifications Applicable conditionsThe given technical indicators apply to the following conditions: Warm-up 30 minutes while the instrument is in the calibration cycle model S3533B Frequency range 9kHz~20GHz Frequency reading ±(frequency marker reading × frequency reference accuracy + 1% × span + 10% × accuracy RBW + 0.5 ×...
  • Page 119 S3532 / S3533 Series Spectrum Analyzer User Manual Note: Typical fc=1GHz, sampling detection, trace averaging times ≥10 Scan time Non-zero span 5ms to 3000s Zero span 20us to 3000s Scan Mode Continuous, Single Trigger Trigger source Free, Video, External External trigger level 5V TTL level, nominal value Frequency Counter Counting resolution...
  • Page 120 S3532 / S3533 Series Spectrum Analyzer User Manual FM/AM Audio Headphone jack Demodulation Common parameters monitor led Backlight, 8.4 inch TFT-LCD, 800×600 Maximum weight Dimensions (excluding 390 (W) × 182 (H) ×230 (D) mm feet) Operating temperature 0℃ to 40℃ Storage temperature -30°C to +70°C power supply...

  • Page 121: Appendix: Ordering Information

    S3532 / S3533 Series Spectrum Analyzer User Manual Appendix : Ordering Information Configuration describe Order Number Spectrum Analyzer Host 9kHz to 3.6GHz S3532A 9kHz to 7.5GHz S3532B 5kHz to 8GHz S3533A 9kHz to 20GHz S3533B Standard CD-ROM (User Manual, Programming Manual) Power cord (AC input) Optional 100kHz to 1.5GHz Tracking Source...

This manual is also suitable for:

S3533 seriesS3532aS3532bS3533aS3533b

Table of Contents
