Name
No.
ID LED
5
(green)
Audio IN 1/2
6
knob
Power
7
(green)
Audio OUT
8
1/2 knob
DANTE(PoE)
9
port
10
DC IN port
Function Description
Illuminates to assist in identification of the device
via Dante Controller.
The 5-level sensitivity adjustment knob for analog
audio input channel 1/2. The knob arrows indicate:
1. +24dBu, 2. + 4dBu, 3. 0dBu, 4. -10dBv, 5. -28dBv.
▪ Light on: The device is powered on by PoE or
local 12VDC supply.
▪ Light off: The device is powered off.
The 5-level gain adjustment knob for analog audio
output channel 1/2. The knob arrows indicate:
1. +18dBu, 2. + 4dBu, 3. 0dBu, 4. 0dBv, 5. -10dBv.
100M Dante digital audio input/output port,
®
connected to the Network Switch through RJ45
line, supporting PD power supply.
The green LINK LED is always on after normal
connection.
The yellow DATA LED is flashing when there is
data transmission.
12VDC/500mA power input port.
The device can be powered via two methods:
▪ Local 12VDC/500mA power supply.
▪ PoE from Network Switch. Device acts as PD
mode.
