Connection
Front Panel
Rear Panel
Mechanical
Housing
Color
Dimensions
Weight
Power Supply
Power
Consumption
Operating
Temperature
Storage
Temperature
Operating
Humidity
Storage
Humidity
1x Power LED [Green Color]
1x ID LED [Green Color]
2x MIC Phantom Power 48V LED [Green Color]
2x MIC Phantom Power 48V button with backlit LED
[Green Color]
2x Audio In [3-pin XLR, Female]
[LINE audio, Balanced/unbalanced connection, Max
input level 24dBu]
[MIC audio, Balanced/unbalanced connection, Max
input level 50mVRMS, 48V phantom power]
2x Audio Out [3-pin XLR, Male, Analog audio, Balanced/
unbalanced connection, Max output level 18dBu]
1x DANTE [RJ45 connector, PoE] [Digital audio in/out,
PCM 2CH 44.1K-96KHz 16/24Bit]
1x DC/12V [2pin-3.5mm phoenix connector] [12VDC/
500mA]
Aluminum panel + Iron chassis
White panel + Silver chassis
Wall plate: 95mm [W] x 105mm [H] x 41.2mm [D]
Faceplate: 115mm [W] x 115mm [H] x 6mm [D]
Without faceplate: 359g
With faceplate: 452g
1. PoE/PD (Class 1 IEEE 802.3af)
2. DC 12V (for the case that Switch does not support PoE)
3.6W (Max)
32°F ~ 104°F / 0°C ~ 40°C
-4°F ~ 140°F / -20°C ~ 60°C
20% ~ 80% (relative humidity, non-condensing)
10% ~ 90% (relative humidity, non-condensing)
